Aaeon FWS-2160 Manuel utilisateur
Network Appliance FWS-2160
FWS-2160
Desktop
Network Appliance Platform
1 2.5” Internal Disk Drive bay
2 SATA II
6 LAN Ports
2 Type A USB 2.0 Ports
FWS-2160 Manual 1st Ed
December 2013
Network Appliance FWS-2160
Copyright Notice
This document is copyrighted, 2013. All rights are reserved. The
original manufacturer reserves the right to make improvements
to the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated,
or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information
provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third
parties that may result from its use.
The material in this document is for product information only
and is subject to change without notice. While reasonable
efforts have been made in the preparation of this document to
assure its accuracy, AAEON assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.
i
Network Appliance FWS-2160
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
zAward is a trademark of Award Software International, Inc.
zCompactFlash™ is a trademark of the Compact Flash
Association.
zVIA is a trademark of VIA Technologies, Inc.
zMicrosoft Windows®is a registered trademark of Microsoft Corp.
All other product names or trademarks are properties of their
respective owners.
ii
Network Appliance FWS-2160
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
zFWS-2160
zCD-ROM for User Manual (in PDF format) and drivers
zRubber Foots
z60W Power Adapter
z2.5” IDE Hard Disk Driver Cable
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
Note:
Serial ATA Cables are optional accessories. Please purchase
those cables according to the following item numbers.
1702151201 SATA Power Cable
1709070050 SATA Cable
iii
Network Appliance FWS-2160
Contents
Chapter 1 General Information
1.1 Introduction..........................................................1-2
1.2 Features..............................................................1-3
1.3 Specifications......................................................1-4
1.4 General System Information ...............................1-7
Chapter 2 Quick Installation Guide
2.1 Safety Precautions..............................................2-2
2.2 Location of Connectors .......................................2-3
2.3 Mechanical Drawing............................................2-5
2.4 List of Jumpers....................................................2-7
2.5 List of Connectors ...............................................2-8
2.6 Setting Jumpers ..................................................2-10
2.7 CMOS Setting Selection (CN13).........................2-11
2.8 Auto PWRBTN Selection (CN3)..........................2-11
2.9 CF POWER Selection (CN20) ............................2-11
2.10 Front Panel Connector (CN5) ...........................2-11
2.11 BOX Header (USB1.2.3)...................................2-11
2.12 RS232 Pin Header (COM2) ..............................2-12
2.13 SATA Power Connector (CN6.7.8.9) ................2-12
2.14 4 pin ATX Power Connector (CN16).................2-12
2.15 SATA Connector (SATA 1.2.3.4) ......................2-12
2.16 CF-SATA Connector (CN2)...............................2-13
iv
Network Appliance FWS-2160
2.17 LAN LED Connector (CN4)...............................2-14
2.18 LAN Bypass LED Connector (BPLED1) ...........2-14
2.19 Installing the Hard Disk Drive............................2-15
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization .............................3-2
3.2 Award BIOS Setup..............................................3-3
Chapter 4 Driver Installation
4.1 Installation...........................................................4-3
Appendix A Programming the Watchdog Timer
A.1 Watchdog Timer Initial Program.....................A-2
Appendix B I/O Information
B.1 I/O Address Map.............................................B-2
B.2 Memory Address Map.....................................B-5
B.3 IRQ Mapping Chart.........................................B-7
B.4 DMA Channel Assignments..........................B-12
Appendix C Standard Firewall Platform Setting
C.1 Standard Firewall Platform Setting.................C-2
C.2 Status LED Sample Code...............................C-2
C.3 LAN Bypass Mode Sample Code...................C-5
C.4 Console Redirection .......................................C-6
Appendix D AHCI Settings
D.1 Setting AHCI...................................................D-2
v
Network Appliance FWS-2160
Chapter 1 General Information 1- 1
Chapter
General
1
Information
Network Appliance FWS-2160
1.1 Introduction
FWS-2160 adopts the AMD G-series T24L Processor and
combines with AMD A50M FCH chipset. The system memory
features two 240-pin DDR3 1066MHz DIMM socket total up to 8GB.
It deploys six LAN ports that consist of six 10/100/1000Base-TX
Ethernet ports with 2 pair LAN bypass function. FWS-2160’s
condensed appearance features desktop form factor that fits nicely
into a space-limited environment.
This compact FWS-2160 is equipped with two SATA II and
CompactFlashTM Type II connector with ATA mode. In addition,
it offers flexible expansion with network products and features
two Mini-PCIe expansion socket, two USB2.0 ports and one
RS-232 console port on the rear panel. The console port deploys
console re-direction that increases the network security via
remote control. All of these designs provide for a more
user-friendly solution.
Chapter 1 General Information 1- 2
Network Appliance FWS-2160
1.2 Features
zDesktop 6 LAN Ports Network Appliance Platform
zOnboard AMD G-series T24L 1 GHz Processor
zAMD A50M Chipset
z2 x 240-pin single channel DDRIII 1066MHz DIMM,
up to 8GB
z6 x 10/100/1000Base-TX ethernet port with 2 pair
LAN bypass function
z1 x 2.5" SATA HDD and 1 x CF-SATA socket
zUSB2.0 Port x 2 & RS-232 Console x 1 in the Real
Panel
zDC 12V power input requirement
zWatchdog Function 1~255 Sec.
zMini-PCIe slot x 2
Chapter 1 General Information 1- 3
Network Appliance FWS-2160
1.3 Specifications
System
Form Factor
Processor
Desktop 6 LAN ports Network Appliance
Onboard AMD G-series T24L 1 GHz
Processor
System Memory
Chipset
2 x 240-pin DDR3 1066MHz DIMM up to
8GB
AMD A50M Chipset
LAN
BIOS
IDE
SATA Interface
Realtek RTL8111E controller, Gigabit
Ethernet x 6
AMI BIOS ROM
N/A
1 x SATA II port on board (Optional extra
2nd SATAII port)
Expansion Interface
Watchdog Timer
RTC
2 x Mini-PCIe slot
1~255 step by software programmable
Internal RTC
Storage 2.5” SATA HDD x 1 and CompactFlash™
socket
FAN Cooling
Front I/O Panel
1 x Cooling Fan
1 x Power LED
1 x Status Led
1 x HDD Active LED
12 X LAN LEDs
Chapter 1 General Information 1- 4
