3rd Eye AWT07MLEDT Manuel utilisateur
WARNING
Failure to follow all instructions and safety precautions in this
manual, in the vehicle and body manufacturers' manuals and
on the safety decals attached to the vehicle, body and this
product could result in serious injury or death to operators,
service technicians or bystanders and/or damage to property.
DO NOT operate the vehicle or install this product before you
READ and UNDERSTAND the vehicle Operation Manual, this
manual and other applicable manufacturers' manuals, and all
safety decals. This product must be installed by certified
technicians/installers familiar with the vehicles on which they
will be making the installation.
AWT07MLEDT HD
Monitor
USER MANUAL
ISSUED OCTOBER 2018
© 2018 3rd Eye 3E-AWT07MLEDT-UM-1018
TABLE OF CONTENTS
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Table of Contents
Monitor
........................................................................................................................................................................................3AWT07MLEDT
...................................................................................................................................................................................4FeaturesFeaturesFeatures
...................................................................................................................................................................................5Package ContentsPackage ContentsPackage Contents
...................................................................................................................................................................................6TFT InstallationTFT InstallationTFT Installation
...................................................................................................................................................................................7Signal Cable DescriptionSignal Cable DescriptionSignal Cable Description
...................................................................................................................................................................................9Control Cable DescriptionControl Cable DescriptionControl Cable Description
...................................................................................................................................................................................12Front Panel ControlFront Panel ControlFront Panel Control
...................................................................................................................................................................................12OSD Menu
...................................................................................................................................................................................12Screen Menu
...................................................................................................................................................................................12Display
...................................................................................................................................................................................12Camera
...................................................................................................................................................................................12Information
...................................................................................................................................................................................27Vehicle InstallationVehicle InstallationVehicle Installation
...................................................................................................................................................................................29SpecificationsSpecificationsSpecifications
...................................................................................................................................................................................31MountingMountingMounting
...................................................................................................................................................................................33Cable ConnectionsCable ConnectionsCable Connections
...................................................................................................................................................................... 34
Index
1
USER MANUAL
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
SAFETY PRECAUTIONS
Federal Communications Commission (FCC) Statement
This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
·
Reorient or relocate the receiving antenna.
·
Increase the separation between the equipment and receiver.
·
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
·
Consult the dealer or an experienced radio / TV technician for help.
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void
your authority to operate the equipment.
NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference and,
2. This device must accept any interference received, including interference that may cause undesired operation
2
USER MANUAL
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
PRODUCT DOCUMENTATION UPDATES
Thank you for purchasing our product. Please read this User Manual before using the product. All product documentation is
subject to change without notice. Please go to www.3rdeyecam.com to get the most current documentation for your 3rd Eye
products.
3
USER MANUAL
AWT07MLEDT
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
AWT07MLEDT HD MONITOR
7" Q TFT LCD MONITOR (LED BACKLIGHTED)
USER MANUAL
ISSUED OCTOBER 2018
3E-AWT07MLEDT-UM-1018
4
USER MANUAL
AWT07MLEDT
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Features
FEATURES
This heavy duty 4 port monitor is designed to withstand shock and vibrations of up to 10G, repel water intrusion, salt and
handle extreme temperatures.
Split, Tri and Quad screen viewing is available on this 7" screen. The AWT07MLEDT is a rugged, robust monitor protected by
die cast aluminum housing with the highest military specs suitable for the toughest known environments.
1. Advanced OSD Menu for easy use
2. Supports up to 4 CCD Camera inputs (Mini DIN connector)
3. Extra RCA input for multimedia while parking (VCD, DVD, Game device)
4. Provide 2 Video / 1 Audio Signal Output (Live Out)
5. Support Single / Dual / Triple / Quad Screen (Cam Out)
6. Signal Trigger for Side / Rear View
7. Auto Day & Night Control via Photo Diode Sensor
8. Auto Detection for NTSC / PAL System
9. OSD Control for Individual Normal / Mirror Camera Image for every camera
10.Auto power on when users are making left turn or right turn even reverse
11.Able to select CAM A / B/C / R’s monitoring screen
12.Supported 9.6V~32V Car power system working
13.Professional Metal Case with Anti Shocking Design
5
USER MANUAL
AWT07MLEDT
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Package Contents
PACKAGE CONTENTS
ITEM
QTY
1. 7” LCD Monitor
1
2. Sun-Hood
1
3. Mounting Bracket
1
4. Accessories
1
5. Control Cable
1
6. User Manual
1
6
USER MANUAL
AWT07MLEDT
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
TFT Installation
TFT INSTALLATION
STEP 1
Check the package and
make sure all parts are
included.
STEP 5
Adjust the monitor to an
appropriate / comfortable
viewing angle before
tightening the screws.
STEP 2
Clip the sun-hood on to the
monitor.
STEP 6
Connect the control cable
included to the power
socket which located at rear
side of monitor.
STEP 3
Make sure it is installed
properly.
STEP 7
Monitor installation is now
completed. Each control
cable wire is attached with a
sticker to indicate its signal
function. Referred to the
identification sticker for
further installation.
STEP 4
Install the monitor on to the
bracket.
7
USER MANUAL
AWT07MLEDT
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Signal Cable Description
SIGNAL CABLE DESCRIPTION
1. CAM R (Mini DIN) (NTSC/PAL system presume by this car
rear CCD)
For 1st camera connection
2. CAM A (Mini DIN)
For 2nd camera connection
3. CAM B (Mini DIN)
For 3rd camera connection
4. CAM C (Mini DIN)
For 4th camera connection
5. LIVE VIDEO OUT (White Color RCA Jack)
On screen video loop out (for recording, second monitor or
other device)
6. LIVE AUDIO OUT (Black Color RCA Jack)
On screen audio loop out (for recording, second monitor or
other device)
7. AV VIDEO IN (Yellow Color RCA Jack)
Connection for any Video signal (DVD, VCD, Game)
8. AV AUDIO IN (Red Color RCA Jack)
Connection for any Audio signal (such as DVD, VCD, Game)
9. CAM OUT (Green Color RCA Jack)
Video loop out (for recording, second monitor or other
device
8
USER MANUAL
AWT07MLEDT
Copyright 2018, 3rd Eye
Printed in U.S.A.
Issued October 2018
Signal Cable Description
SIGNAL CABLE DESCRIPTION (CONTINUED)
Mini Din Pin
Assignment
* Type 1 (Standard):
1. Video
2. -------
3. Audio
4. +12V
5. GND
6. -------
Function of the Audio
Cam A
Audio from Cam A
Cam B
Audio from Cam B
Cam C
Audio from Cam C
Cam R
Audio from Cam R
Cam A + Cam B
Audio from Cam A
Cam C+ Cam R
Audio from Cam R
Cam A+ Cam R
Audio from Cam R
Cam R+ Cam B
Audio from Cam R
Cam A + Cam C
Audio from Cam A
Cam C+ Cam B
Audio from Cam C
Cam R / Cam AB
Audio from Cam R
Quad
Audio from Cam R
AV
Audio from AV
1. Cam Out: Composite video loop out signal to recorder, monitor or other device.
2. Live Video/Audio Out: On screen video/audio signal loop out to recorder, monitor or other device.
