3J USB-B2K Manuel utilisateur
1. Instruction
1.1 Summary
USB Adaptor is analog telephone adaptor with one USB interface
to PC, 1 FXS for regular phone and 1FXO for PSTN call relays.
All cordless phones and regular phones can be used to make and
receive Skype call. Phone can be used to make regular call at the
same time. Phone rings for all incoming skype and PSTN calls.
Skype or PSTN calls is switched by pressing phone key(*).
1.2 Features
1. Supporting DECT, 2.4G, 900M and any other wireless phones
2. Make/Receive both Skype calls and regular PSTN calls
3. Auto-detection and auto-switching to Skype or PSTN calls
4. Phone rings for all incoming Skype and PSTN calls
5. Skype or PSTN calls switched by pressing phone key(*)
6. Using the phone keypads to dial.
1.3 System Requirements
1. Macintosh computer with G3, G4 or G5 processor
2. Mac OS X v10.3
3. Free USB1.1 or USB2.0 port
4. 128MB RAM and 20MB free disk space
5. Any broadband connection or minimum 33.6 Kbps dialup
1
1.4 Package Contents
1. One USB Adaptor
2. One USB Cable
3. One Telephone Line
4. One User Manual
5. One Installation CD
2. Connect USB Adaptor to PC
Connect to PC’s USB port
Connect to PSTN line Connect to phone
(1) Connect USB Adaptor to PC, POWER indicator will be on.
(2) Plug PSTN line in "LINE" port.
(3) Connect Phone to "TEL” port.
3. USB Adaptor Installation
3.1 Install the Skype Software
Note: If you have previously installed the Skype software,
proceed to 3.2
Download Skype software and install it (www.skype.com).
The version must be 1.3.0.17 or higher.
Create a Skype account following the on-screen instructions.
3.2 Install SkypeMate Software
Download SkypeMate software and install it.
Double click the SkypeMate icon on the desktop, you will
be prompted that another program wants to use Skype.
Select Allow this program to use Skype and click OK.
3.3 Channel Switch
You can press * to switch between USB and PSTN.
2 3
4. Basic Function
4.1 Call another Skype user (PC to PC)
Rename your contacts begin with digit number, for
example, 11, 12, and so on. It shows as above.
Press “11” on the normal phone, and press “#”, the first
contact begins with “11” will be called out.
e.g.: If you want call the contact “bbc456”, you just need
to press “11” on the normal phone, and press “#” to call
out.
4.2 Call to regular phone
Pressing "00"+"country number"+"phone number"+"#" can start
the SkypeOut.
Example: call to China, beijing, press 00861012345678, then
press “#”.
0086 10 12345678
---------------- ---------- --------------------
country code city code destination number
Note: If you want to use this function, you should buy SkypeOut
Credit first.
4.3 Make calls through PSTN (Phone to Phone)
Check the PSTN indicator is on, then press the wanted phone
number, and press “#” to call out. If the PSTN indicator is off,
press “*” key to make it on.
Example: call to China beijing 00861012345678
Operation: Input the number 00861012345678, then press “#” to
call out.
4.4 Answer a call
When a call comes in, the phone will be ringing. Pick up handset
or press handfree key to answer the call.
4 5
5. FAQ
Problem 1
I can’t hear other party or other party can’t hear me while in
talking?
Resolution
Go to “Skype->Preferences->Audio”, set Audio output and
Audio input to USB Audio Device, it shows as below:
Problem 2
There is no voice comes out when play music?
Resolution
Go to “System Preferences->Sound”, set the Output and
Input sound device to your Built-in Audio, it shows as below:
Problem 3
I can’t play music through the USB Adaptor?
Resolution
Go to “System Preferences->Sound”, set the Output and
Input sound device to USB Audio Device. Off hook, press * to
switch to USB channel, press any key to cancel the dial tone.
Make sue you didn’t mute the Output volume.
USB Adaptor Ver.1.0
2006-6-28
6 7
