3Com LSBM1SRP1M1 Manuel utilisateur

H3C S9500 Series Routing Switches

Installation Manual

Hangzhou H3C Technologies Co., Ltd.

http://www.h3c.com

Manual Version: T2-08048T-20071015-C-1.24

Product Version: S9500-CMW310-R1632P03

No part of this manual may be reproduced or transmitted in any form or by any means

without prior written consent of Hangzhou H3C Technologies Co., Ltd.

Trademarks

H3C, , Aolynk, , H3Care,

, TOP G, , IRF, NetPilot,

Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath, Comware, Secware,

Storware, NQA, VVG, V2G, VnG, PSPT, XGbus, N-Bus, TiGem, InnoVision and

HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd.

All other trademarks that may be mentioned in this manual are the property of their

respective owners.

Notice

The information in this document is subject to change without notice. Every effort has

been made in the preparation of this document to ensure accuracy of the contents, but

all statements, information, and recommendations in this document do not constitute

the warranty of any kind, express or implied.

To obtain the latest information, please access:

http://www. h3c.com

Technical Support

customer_service@h3c.com

http://www. h3c.com

About This Manual

Related Documentation

The related manuals are listed in the following table.

Manual Description

H3C S9500 Series Routing

Switches Operation Manual

It provides an operation guide. It consists of access

volume, IP service volume, IP routing volume, IP

multicast volume, MPLS/VPN volume, QoS/ACL

volume, security volume, system volume, and

acronyms.

H3C S9500 Series Routing

Switches Command Manual

It explains all commands available in the S9500

series and provides a list of commands the S9500

series do not support. It consists of the same

modules as the operation manual.

Organization

H3C S9500 Series Routing Switches Installation Manual is organized as follows:

Chapter Contents

1 Product Overview Introduces the appearance, architecture

and system features of the S9500

series.

2 Installation Preparations Lists the preparations and precautions

for the installation.

3 Switch Installation Details the installation of the chassis,

PSUs, boards and cable connection for

the S9500 series.

4 System Commissioning Concentrates on the initial power-on and

booting of the S9500 series.

5 Switch Monitoring and Maintenance Presents the hardware and software

upgrade.

6 Appendix A Cable Management Introduces how to bind cables.

7 Appendix B Engineering Labels for

Cables Introduces the use of engineering labels.

Chapter Contents

8 Appendix C Installation of Lightning

Arrester for AC Power

Introduces the installation of lightning

arrester for AC power of S9500 series

routing switches.

Conventions

The manual uses the following conventions:

I. Command conventions

Convention Description

Boldface The keywords of a command line are in Boldface.

italic Command arguments are in italic.

[ ] Items (keywords or arguments) in square brackets [ ] are

optional.

{ x | y | ... }

Alternative items are grouped in braces and separated by

vertical bars. One is selected.

[ x | y | ... ]

Optional alternative items are grouped in square brackets

and separated by vertical bars. One or none is selected.

{ x | y | ... } *

Alternative items are grouped in braces and separated by

vertical bars. A minimum of one or a maximum of all can be

selected.

[ x | y | ... ] *

Optional alternative items are grouped in square brackets

and separated by vertical bars. Many or none can be

selected.

&<1-n> The argument(s) before the ampersand (&) sign can be

entered 1 to n times.

# A line starting with the # sign is comments.

II. GUI conventions

Convention Description

< > Button names are inside angle brackets. For example, click

<OK>.

[ ] Window names, menu items, data table and field names

are inside square brackets. For example, pop up the [New

User] window.

/ Multi-level menus are separated by forward slashes. For

example, [File/Create/Folder].

III. Symbols

Convention Description

Warning Means reader be extremely careful. Improper operation

may cause bodily injury.

Caution Means reader be careful. Improper operation may cause

data loss or damage to equipment.

Note Means a complementary description.

Environmental Protection

This product has been designed to comply with the requirements on environmental

protection. For the proper storage, use and disposal of this product, national laws and

regulations must be observed.

Installation Manual

H3C S9500 Series Routing Switches Table of Contents

Table of Contents

Chapter 1 Product Overview ........................................................................................................1-1

1.1 Introduction........................................................................................................................1-1

1.2 Physical Structure..............................................................................................................1-1

1.2.1 Chassis and Slots ...................................................................................................1-2

1.2.2 Backplane................................................................................................................1-6

1.2.3 Power System.........................................................................................................1-7

1.2.4 PoE Power Supply..................................................................................................1-9

1.2.5 Fan Tray................................................................................................................1-12

1.3 Switching and Routing Processing Unit...........................................................................1-13

1.4 Line Processing Unit........................................................................................................1-14

1.5 Service Board ..................................................................................................................1-16

1.6 System Specifications......................................................................................................1-16

Installation Manual

H3C S9500 Series Routing Switches Chapter 1 Product Overview

1-1

Chapter 1 Product Overview

1.1 Introduction

The S9500 Series Routing Switches (hereinafter referred to as the S9500 series) are

developed by Hangzhou H3C Technologies Co., Ltd. (hereinafter referred to as H3C)

for use on business-oriented enterprise networks, the distribution layer of large MANs,

the core layer of small MANs, and the backbone of large enterprise networks and

campus networks. They can serve as switching cores and convergence centers.

Currently, the S9500 series consist of the following models:

zS9502: This model provides a switching capacity of up to 240 Gbps. It allows for

the concurrent wire-speed forwarding on 96 GE ports, or 8 × 10 GE ports, or 144

FE electrical ports, or 60 FE optical ports.

zS9505: This model provides a switching capacity of up to 600 Gbps. It allows for

the concurrent wire-speed forwarding on 240 GE ports, 20 × 10GE ports, 240 FE

electrical ports, or 100 FE optical ports.

zS9508: This model provides a switching capacity of up to 960 Gbps. It allows for

the concurrent wire-speed forwarding on 384 GE ports, 32 × 10GE ports, 384 FE

electrical ports, or 160 FE optical ports.

zS9508V: This model provides a switching capacity of up to 960 Gbps. It allow for

the concurrent wire-speed forwarding on 384 GE ports, 32 × 10GE ports, 384 FE

electrical ports, or 160 FE optical ports. This model adopts upright slots.

zS9512: This model provides a switching capacity of up to 1.44 Tbps. It allows for

the concurrent wire-speed forwarding on 576 GE ports, 48 × 10GE ports, 576 FE

electrical ports, or 240 FE optical ports.

Note:

Unless otherwise specified in this document, the S9508V and the S9508 have the

same configuration.

1.2 Physical Structure

The S9500 series use integrated chassis, which consists of a power area, board area,

backplane, and fan area.

Installation Manual

H3C S9500 Series Routing Switches Chapter 1 Product Overview

1-2

Note:

zTwo switching and routing processor units (SRPUs) can be installed on the S9500

series to support active-standby switchover.

zTwo power supply units (PSUs) can be installed on the S9500 series to provide

hot-standby 1+1 redundancy.

zThe S9500 series support PoE and an external PoE power supply is optional.

zBoards, fan tray, and AC/DC PSUs are hot-swappable.

1.2.1 Chassis and Slots

I. S9502

(1) SRPU slot (2) SRPU/LPU slot (3) LPU slots

(4) PSUs (5) Fan tray

Figure 1-1 Front view of the S9502

zThe S9502 chassis provides four slots in its board area: from up to down, the first

one accommodates an SRPU, the second one accommodates an SRPU or a line

processing unit (LPU), and the remaining two slots accommodate LPUs or service

boards.

zAt the bottom of the chassis is the power area that contains two power supply units

(PSUs). The switch supports both AC and DC power inputs. So you can select AC

or DC PSUs as needed. A PoE filter at the rear of the chassis is used to receive

power from an external PoE power supply.

zOn the right of the chassis is the fan area that contains a vertical fan tray. The fans

draw air in from the left and exhausts air from the right.

Installation Manual

H3C S9500 Series Routing Switches Chapter 1 Product Overview

1-3

II. S9505

(1) SRPU slots (2) LPU slots (3) Cable management bracket

(4) PSUs (5) PoE power entry module (6) Fan tray

Figure 1-2 Front view of the S9505

zThe S9505 chassis provides seven slots in its board area: The top two

accommodate SRPUs, which can operate in 1+1 redundancy mode; the remaining

five accommodate LPUs/service boards.

zAt the bottom of the chassis is the power area that contains one PoE entry module

and two PSUs. The two PSUs arehot-swappable; they can operate in 1+1

redundancy mode. The switchsupports both AC and DC power inputs. So you can

select AC or DC PSUs as needed.

zOn the right of the chassis is the fan area that contains one vertical fan tray. The

fans draw air in from the left and exhausts air from the right.

Installation Manual

H3C S9500 Series Routing Switches Chapter 1 Product Overview

1-4

III. S9508

(1) LPU slots (2) SRPU slots (3) PSUs

(4) PoE power entry module (5) Fan tray

Figure 1-3 Front view of the S9508

zThe S9508 chassis provides ten slots in its board area: The middle two

accommodate SRPU modules; the remaining eight accommodate LPUs/service

boards.

zAt the bottom of the chassis is the power area that contains one PoE power entry

module and two PSUs. The switch supports both ACand DC power inputs. So you

can select AC or DC PSUs as needed.

zOn the right of the chassis is the fan area that contains one vertical fan tray. The

fans draw air in from the left and exhausts air from the right.
