3Com 5000/6000 Manuel utilisateur

www.3Com.com

Part Number: 10016467 Rev. AA

Published: October 2007

3COM ROUTER 5000/6000 FAMILY

QUICK REFERENCE GUIDE

Overview

This Command Reference applies to the following Router 5000/6000 models running software version 3.0.

About the Command Line Interface

To use and navigate the command line interface of your unit, please refer to the following points for assistance:

■When initially accessing the command line interface, press Enter when prompted. The User View menu for the unit

displays. This is indicated by the chevron brackets around the name of the unit at the prompt, for example,

<router5000-xx> (where xx is either EI or SI).

■When in the System View menu, square brackets appear around the name of the unit at the prompt, for example,

[router5000-xx].

■You must be in the System View menu to access the configurable CLI commands.

■Some commands can be entered directly at any prompt from anywhere in the interface.

■If you enter part of a command followed by a ? (with no space between), the CLI will show you all the commands

that begin in that way.

■The term ‘view’ may be used interchangeably with the term ‘menu’.

■The undo command is placed before the command you wish to undo, for example, undo setauthentication password.

■<CTRL-A> places the cursor back to the start of the command line.

■Enter the first few characters of a command and press TAB to enter the full command without having to input the

entire command (where there is only one command that starts with the entered characters).

■Use the Up Arrow key at the prompt to repeat the previous command string.

■Use the Delete key to delete the character after the cursor; the Backspace key deletes the character before the cursor.

■When entering physical port numbers, Enter the port number as x/0/z, where x is the unit number and z is the

physical port number.

Router 5012 (3C13701)

Router 5232 (3C13751)

Router 5642 (3C13755)

Router 5682 (3C13701)

Router 6040 (3C13840)

Router 6080 (3C13880)

23Com Router 5000/6000 Family

Command Reference

Displaying Command Parameters

At the prompt, enter the name of the command followed by a space and ?. For example:

<router5000-xx>boot ?

The following parameters are displayed:

attribute-switch Exchange the file main-attribute and backup-attribute.

boot-loader Select a file to boot at the next time

bootrom Update Bootrom

web-package Set web resource package

To specify boot loader, enter the command as follows:

<router5000-xx>boot boot-loader ?

You only need to enter ? if parameters exist for the command.

Displaying Parent Menus

At the prompt, enter quit.

Displaying the User View Menu

Press <CTRL-Z>.

Obtaining Help

At the prompt, enter ?.

Further Information

For further information about how to use the command line interface, refer to the Command Reference Guide and

the Configuration Guide, which are both available as PDF documents on the CD that accompanied the unit.

Commands

l2tp-auto-client enable

Use the l2tp-auto-client enable command to enable the LAC client to set up L2TP tunnel. Virtual Template Interface view

l2tp enable

Use the l2tp enable command to enable the L2TP function. System view

l2tp-group

Use the l2tp-group command to create an L2TP group. System view

l2tpmoreexam enable

Use the l2tpmoreexam enable command to enable the multi-instance function of L2TP. System view

l2vpn-family

Use the l2vpn-family command to create or enter an L2VPN address family view. BGP view

aaa-client

Use the aaa-client command to enter Voice AAA view. Voice view

3Com Router 5000/6000 Family 3

Command Reference

abr-summary

Use the abr-summary command to configure the route aggregation on the area border router (ABR). OSPF Area view

access-limit

Use the access-limit command to configure a limit to the amount of supplicants in the current ISP domain. ISP Domain view

acl-reflect timeout

Use the acl-reflect timeout command to set the global aging time of reflexive ACLs. System view

acl

Use the acl command to create an access control list and enter ACL view. System View

acl

Use the acl command to reference an ACL to control call-in and call-out of VTY (Telnet and SSH) users. User Interface view

accounting

Use the accounting command to configure an accounting scheme for the current ISP domain. ISP Domain view

accounting

Use the accounting command to set the IP address, port number and shared key for the primary and

secondary RADIUS accounting servers. RADIUS Scheme view

accounting

Use the accounting command to set the IP address, port number and shared key for the primary and

secondary RADIUS accounting servers. RADIUS Scheme view

accounting

Use the accounting command to set the IP address, port number and shared key for the primary and

secondary TACACS+ accounting servers. TACACS+ view

accounting commands

Use the accounting commands command to enable the system to start per-command accounting for

terminal users logged into the user interface. User Interface view

accounting domain

Use the accounting domain command to enable DHCP server accounting for addresses from the global

DHCP address pools and configure a domain for DHCP accounting. DHCP Address Pool view

accounting-on

Use the accounting-on enable command to enable the user re-authentication at reboot function. RADIUS view

accounting optional

Use the accounting optional command to enable optional accounting. ISP Domain view

RADIUS view

activate

Use the activate command to activate the ADSL interface. ATM (ADSL) Interface view

activate

Use the activate command to enable the G.SHDSL interface. ATM (G.SHDSL) Interface view

activation-key

Use the activation-key command to define a shortcut key or key combination for starting a terminal

session. User Interface view

address

Use the address command to configure the voice routing policy to the peer voice gateway. Voice Entity view

43Com Router 5000/6000 Family

Command Reference

address

Use the address command to configure a route to the peer voice gateway or assign an X.121 address for

a destination host. Voice Entity view

address sip

Use the address sip command to set routing policy for reaching the remote voice gateway (VG) to SIP. Voice Entity view

adsl standard

Use the adsl standard command to set the standard applied to the ADSL interface. ATM (ADSL) Interface view

adsl tx_attenuation

Use the adsl tx_attenuation command to set attenuation value for ADSL transmit power. ATM (ADSL) Interface view

adv-factor

Use the adv-factor command to configure the advantage factor which is used to count Mos and ICPIF

value in a jitter voice test. HWPing Test Group view

aggregate

Use the aggregate command to establish an aggregated record in the BGP routing table. BGP view

aggregate

Use the aggregate command to create a multicast aggregated record in the BGP routing table.

Use the aggregate command without parameters to create one local aggregated route and set atomic

aggregation attributes. IPv4 Multicast Subaddress Family view

aging-time

Usetheaging-time commandtoconfigure SYN status waitingtimeoutvalueandFINstatuswaitingtimeout

value of TCP, session entry idle timeout value of TCP and UDP. ASPF Policy view

ah authentication-algorithm

Use the ah authentication-algorithm command to set the authentication algorithm adopted by

Authentication Header protocol in IPSec proposal.

Use the undo ah authentication-algorithm command to restore the default setting. IPSec Proposal view

ahdsl annex

Use the shdsl annex command to configure annex standard at an SHDSL interface. You cannot activate a

link with different standard types at its two ends. ATM (G.SHDSL) Interface view

alarm (CT3 Interface)

Use the alarm command to enable the CT3 interface to detect/send alarm signals. CT3 Interface view

alarm-threshold

Usethe alarm-threshold commandto configure the alarmthresholds on the CT1/PRIinterfaceasneeded.

CT1/PRI Interface view

algorithm-suite

Use the algorithm-suite command to specify the algorithm suite used when a client registers. Dvpn-Class view

allow l2tp

Use the allow l2tp command to specify the name of the peer end of the tunnel on receiving call and the

Virtual-Template it uses. L2TP Group view

annexg

Use the annexg command to enable T1.617 Annext G on the frame relay interface for data transmission. DLCI view

ani

Use the ani command to enable or disable the terminating point to send the calling party information

(service category and calling number) to the originating point during call connecting process. R2 CAS view

3Com Router 5000/6000 Family 5

Command Reference

ani-offset

Use the ani-offset command to configure the number of digits of the called number to be collected prior

to requesting the calling party information. R2 CAS view

answer

Use the answer command to configure whether the terminating point is required to send answer signal. R2 CAS view

apply access-vpn vpn-instance

Use the apply access-vpn vpn-instance command to specify to search private network forwarding routes

in vpn-name1, vpn-name2, vpn-name3, vpn-name4, vpn-name5, vpn-name6 (if they all

exist) and forward packets after policy routing is enabled to satisfy route-policy. Route-Policy view

apply as-path

Use the apply as-path command to specify the AS numbers to be added in front of the original AS path in

route-policy. Routing Policy view

apply community

Use the apply community command to set BGP community attributes in route-policy. Routing Policy view

apply cost

Use the apply cost command to set the route cost value of route information. Routing Policy view

apply cost-type

Use the apply cost-type command to set the route cost type of route information. Routing Policy view

apply default output-interface

Use the apply default output-interface command to set default forwarding interface for packets. Route-Policy view

apply ip-address

Use the apply ip-address command to set the next hop address of route information. Routing Policy view

apply ip-address default next-hop

Use the apply ip-address default next-hop command to set the default next hop of a packet. Route-Policy view

apply ip-address next-hop (for Multicast Policy Routing)

Use the apply ip-address command to configure the next hop IP address list in a route-node. Route-Policy view

apply ip-address next-hop (for Unicast Policy Routing)

Use the apply ip-address next-hop command to set the packet next hop. Route-Policy view

apply ip-dscp

Use the apply ip-dscp command to configure to modify the packet DSCP value matching the policy. Route-Policy view

apply ip-precedence

Use the apply ip-precedence command to set precedence of IP packets. Route-Policy view

apply isis

Use the apply isis command to apply the level of a matched route to be redistributed to Level-1, Level-2

or Level-1-2. Routing Policy view

apply local-preference

Use the apply local-preference command to apply the local preference of route information. Routing Policy view

apply mpls-label

Use the apply mpls-label command to assign MPLS labels for public network routes that match

route-policy filter conditions. Route-Policy view

63Com Router 5000/6000 Family

Command Reference

apply origin

Use the apply origin command to set the routing source of BGP routing information. Routing Policy view

apply output-interface (for Multicast Policy Routing)

Use the apply output-interface command to configure an outgoing interface list in a route-node. Route-Policy view

apply output-interface (for Unicast Policy Routing)

Use the apply output-interface command to set a packet forwarding interface. Route-Policy view

apply policy outbound

Use the apply policy outbound command to set the frame relay virtual circuit queuing to CBQ

(Class-Based Queuing). Frame Relay Class view

apply tag

Use the apply tag command to set the tag area of OSPF route information. Routing Policy view

area

Use the area command to enter OSPF area view. OSPF view

OSPF Area view

area

Use the area command to configure the type of busy tone detection for FXO voice subscriber-line. Voice Subscriber-line view

area-authentication-mode

Use the area-authentication-mode command to configure IS-IS to authenticate the received Level-1

routing information packets (LSP, CSNP and PSNP), according to the pre-defined mode and password. IS-IS view

area-id (Voice Entity view)

Use the area-id command to configure the area ID of voice GW. Voice Entity view

area-id (Voice GK Client view)

Use the area-id command to configure the H.323 gateway area ID. Voice GK Client view

arp check enable

Use the arp check enable command to enable ARP entry check to have the device not learn the ARP

entries with broadcast MAC addresses. System view

arp-proxy enable

Use the arp-proxy enable command to enable proxy ARP on an interface. Ethernet interface view

arp security

Use the arp security command to disable dynamic ARP learning on an Ethernet interface. Ethernet Interface view

arp security time-out

Use the arp security time-out command to configure the aging time of the authorized ARP entries. Ethernet Interface view

arp send-gratuitous-arp

Use the arp send-gratuitous-arp command to enable sending gratuitous ARP packet on this interface

periodically and set the sending period. Bridge Template view

Ethernet Interface view

Ethernet Subinterface view

Gigabit Ethernet Interface view

Gigabit Ethernet Subinterface view

Virtual Ethernet interface view

VLAN Interface view

arp static

Use the arp static command to configure ARP mapping table. System view

3Com Router 5000/6000 Family 7

Command Reference

arp timer aging

Use the arp timer aging command to set the aging timer for dynamic ARP entries. System view

asbr-summary

Use the asbr-summary command to configure summarization of redistributed routes by OSPF. OSPF view

ascii

Use the ascii command to set the type of the transmitted data to ASCII. FTP Client view

aspf-policy

Use the aspf-policy command to define an ASPF policy. For a defined policy, the policy can be invoked

through its policy number. System view

async mode

Use the async mode command to set the operating mode of the asynchronous serial interface.

Asynchronous Serial Interface view

AUX Interface view

AM Interface view

async mode padpos

Use the async mode padpos command to configure a POSPAD access port. Asynchronous Serial Interface view

AUX Interface view

async mode pos

Use the async mode pos pos-number command to create a POS access port in nontransparent

transmission and permanent TCP connection mode. Asynchronous Serial Interface view

AM Interface view

FCM Interface view

AUX Interface view

async mode posapp

Use the async mode posapp command to configure the interface to operate in POS application mode.

Asynchronous Serial Interface view

AUX Interface view

atm-class

Use the atm-class command to apply a set of parameters (which are defined in ATM-Class) to an ATM

interface or a PVC. Interface view

PVC view

atm class

Use the atm class command to create an ATM-Class and enter the ATM-Class view. System view

atm-ctt

Use the atm-ctt command to set all interfaces on a board to transparent transmission. ATM Interface view

atm-link check

Use the atm-link check command to have the protocol state of the ATM P2P subinterface changes

depending on whether the physical interface is up and whether a PVC is configured on the subinterface.

ATM P2P Subinterface view

authentication

Use the authentication command to configure an authentication scheme for the current ISP domain. ISP Domain view

authentication

Use the authentication command to set the IP address, port number and shared key for the primary and

secondary RADIUS authentication servers. RADIUS Scheme view

authentication

Use the authentication command to set the IP address, port number and shared key for the primary and

secondary TACACS+ authentication servers. TACACS+ view

83Com Router 5000/6000 Family

Command Reference

authentication

Use the authentication command to enable user authentication and authorization for the access service

number. Voice Access-Number view

authentication

Use the authentication command to set the IP address, port number and shared key for the primary and

secondary TACACS+ authentication servers. TACACS+ view

authentication-algorithm

Use the authentication-algorithm command to select the authentication algorithm for an IKE proposal. IKE Proposal view

authentication-client method

Use the authentication-client method command tospecify how the DVPNserver that applies the DVPN

policy authenticates clients. None, CHAP, and PAP are currently available. Dvpn-Policy view

authentication-did

Use the authentication-did command to enable authentication for all one-stage dial (direct dial) users. Voice AAA view

authentication-method

Use the authentication-method command to select the authentication method used by an IKE proposal. IKE Proposal view

authentication-mode

Use the authentication-mode command to set the authentication mode at login.

Use the authentication-mode none command to set the authentication mode to none, that is, no

authentication at login. User Interface view

authentication-mode

Use the authentication-mode command to configure one area of OSPF to support the authentication

attribute. OSPF Area view

authentication-server method

Use the authentication-server method command to specify a client whether or not to authenticates the

DVPN server it accesses. Dvpn-Class view

authentication super hwtacacs-scheme

Use the authentication super hwtacacs-scheme command to configure super authentication scheme for

a domain. ISP Domain view

authorization

Use the authorization command to configure an authorization scheme for the current ISP domain. ISP Domain view

authorization

Use the authorization command to set the IP address, port number and shared key for the primary and

secondary TACACS+ authorization servers. TACACS+ view

authorization-level

Use the authorization-level command to configure a local caller authorization level for the voice entity. Voice Entity view

auto-config

Use the auto-config command to implement the auto-config operation. System view

auto-config enable

Use the auto-config enable command to enable auto-config.System view

auto-execute command

Use the auto-execute command command to set a command to be automatically executed. User Interface view

3Com Router 5000/6000 Family 9

Command Reference

balance

Use the balance command to configure the number of routes participating in BGP load balancing. BGP view

band-based-sharing

Use the band-based-sharing command to enable bandwidth-based unbalanced load sharing. System view

baudrate

Use the baudrate command to set the baud rate of a serial interface. Serial Interface view

bert

Use the bert command to set test error bit for line Bit. CE3 interface view

bert (CT1/PRI Interface)

Use the bert command to start a BERT test on the CT1/PRI interface. CT1/PRI Interface view

bert (CT3 Interface)

Use the bert command to start a BERT test on the CT3 interface. CT3 Interface view

bgp

Use the bgp command to enable BGP and enter the BGP view. System view

This command is used to enable and disable BGP as well as to specify the local AS number of BGP.

bims boot request

Use the bims boot request command to enable the BIMS device to access the branch intelligent

management system (BIMS) center at startup. System view

bims device-id string

Use the bims device-id command to configure the unique identifier of the BIMS device at the BIMS center. System view

bims enable

Use the bims enable command to enable BIMS. System view

bims interval

Usethebims interval commandtoconfigure the interval for accessing the BIMS center. When theinterval

is set to 0, the BIMS device does not access the BIMS center regularly. System view

bims ip address

Use the bims ip address command to configure the IP address and port number of the BIMS center. System view

bims request

Use the bims request command to have the BIMS device access the BIMS center. System view

bims-server

Use the bims-server command to enable and configure BIMS option for a global address pool on the

DHCP server. Global DHCP Address Pool view

bims sharekey

Use the bims sharekey command to configure the shared key between the BIMS device and the BIMS

center. System view

bims source ip-address

Use the bims source ip-address command to specify a source IP address for the packets sent by the

BIMS device. It can be the IP address of a port on the router. System view

bims specify-time

Use the bims specify-time command to configure the BIMS device to access the BIMS center at the

specified time and if desired, configure the device to access the BIMS center at regular intervals from then

on during a specified period. System view

10 3Com Router 5000/6000 Family

Command Reference

binary

Use the binary command to set data type to binary for file transfer. FTP Client view

boot bootrom

Use the boot bootrom command to upgrade BootRom. System view

boot bootrom

Use the boot bootrom command to upgrade BootRom. System view

bootfile backup

Use the bootfile backup command to specify the backup boot file. System view

bootfile dir

Use the bootfile dir command to view information about all the boot files in the Flash, including file type,

date, time, file size, and file name. System view

bootfile main

Use the bootfile main command to specify the main boot file. System view

bridge aging-time

Use the bridge aging-time command to configure the aging time of the dynamic address table. System view

bridge bridge-set enable

Use the bridge bridge-set enable command to enable the specified bridge set. System view

bridge bridging

Use the bridge bridging command to enable the bridging function of a network layer protocol on a

specified bridge set. System view

bridge enable

Use the bridge enable command to enable the bridging function. System view

bridge learning

Use the bridge learning command to enable forwarding by dynamic address table. System view

bridge mac-address

Use the bridge mac-address command to manually configure a static address table entry of bridge. System view

bridge routing

Use the bridge routing command to enable the routing function of a specified bridge-set for the specified

network protocol. System view

bridge routing-enable

Use the bridge routing-enable command to enable the routing function of the bridge. System view

bridge-set

Use the bridge set command to add an interface to a bridge set. Interface view

Bridge Template view

bridge-set (Ethernet Interface view)

Use the bridge-set (in the Ethernet Interface view) command to add the Ethernet interface into the

bridge. Ethernet Interface view

bridge set (Synchronous Serial Interface view)

Use the bridge-set (in Synchronous serial interface system view) command to add the

synchronous serial interface encapsulated into SDLC into the bridge group. Synchronous Serial Interface view

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels 3Com Routeur réseau

3Com

3Com Router 3012 Mode d’emploi

3Com

3Com MSR 20-40 Mode d’emploi

3Com

3Com Router 5000 Series Manuel utilisateur

3Com

3Com OfficeConnect 3CP4144 Instructions d'installation

3Com

3Com Router 6000 Series Manuel utilisateur

3Com

3Com SuperStack II Switch 9300 Manuel utilisateur

3Com

3Com 3C17540 Manuel utilisateur

3Com

3Com Router 3012 Manuel utilisateur

3Com

3Com OfficeConnect 3CRWDR200A-75 Manuel utilisateur

3Com

3Com 3C8S400 - SuperStack II PathBuilder S400... Manuel utilisateur

3Com

3Com OfficeConnect 3CR858-91 Manuel utilisateur

3Com

3Com OfficeConnect WX4400 Manuel d'installation

3Com

3Com OfficeConnect 3C840 Instructions d'installation et d'utilisation

3Com

3Com 3CBLUG24A Manuel utilisateur

3Com

3Com NJ95 Network Jack Manuel utilisateur

3Com

3Com -1623 Manuel utilisateur

3Com

3Com 3C410012A - OfficeConnect Remote 531 Access... Manuel utilisateur

3Com

3Com OfficeConnect 3C612 Manuel utilisateur

3Com

3Com Router 3031 Manuel d'utilisation

3Com

3Com 3C13612-US - Router 3012 Manuel utilisateur

3Com

3Com 3CNJ100 - IntelliJack Switch Manuel utilisateur

3Com

3Com MSR 50-40 Manuel utilisateur

3Com

3Com OfficeConnect 3CP4144 Mode d’emploi

3Com

3Com 3C16980A SuperStack3300 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
