2nd Sight BioScience InstaCaliper Manuel utilisateur

InstaCaliper™

Electronic Caliper System for Commercial Nurseries

User Manual

2nd Sight BioScience

823 N Crestline St

Spokane, WA 99202

509-381-2112

[email protected]

www.2ndsightbio.com

Part Number: IC00001

Released: Jul 2018

Information in this document is subject to change without notice

No part of this document may be reproduced or transmitted in any form or by any means

without written permission from 2nd Sight BioScience

1
Table of Contents
GENERAL INFORMATION..................................................................................................................... 2
INTRODUCTION.........................................................................................................................................................2
SYSTEM REQUIREMENTS ..........................................................................................................................................3
Caliper Head......................................................................................................................................................3
Ruggedized Handheld Computer.......................................................................................................................3
TERMS AND DEFINITIONS ................................................................................................................... 4
INSTALLATION ..................................................................................................................................... 6
UNPACKING AND INSPECTION....................................................................................................................................6
UNPACKING THE INSTACALIPER BOX .........................................................................................................................6
ASSEMBLING THE CALIPER HEAD ..............................................................................................................................7
ASSEMBLING THE RHC &RHC MOUNT.....................................................................................................................8
RUGGEDIZED HANDHELD COMPUTER ............................................................................................. 10
OPERATING THE RHC............................................................................................................................................ 10
CUSTOMER PORTAL .......................................................................................................................... 11
INSTACALIPER APPLICATION........................................................................................................... 12
DOWNLOADING THE INSTACALIPER APP.................................................................................................................. 12
OPENING THE APPLICATION.................................................................................................................................... 12
SYNCING DATA...................................................................................................................................................... 13
CONFIG SCREEN................................................................................................................................ 14
OFFSETS............................................................................................................................................................... 15
CIRCUMFERENCE................................................................................................................................................... 17
ROUND DATA ........................................................................................................................................................ 18
PRIVATE MODE...................................................................................................................................................... 19
Enable Private Mode....................................................................................................................................... 19
Retrieving CSV Data....................................................................................................................................... 20
AUDIO NOTIFICATIONS........................................................................................................................................... 22
COLOR NOTIFICATIONS.......................................................................................................................................... 23
Add Color Range............................................................................................................................................. 23
Delete Color Range...........................................................................................Error! Bookmark not defined.
MEASUREMENT SCREEN................................................................................................................... 28
CHANGING THE TASK............................................................................................................................................. 29
CHANGING LIST INFORMATION................................................................................................................................ 30
MEASUREMENT SCREEN........................................................................................................................................ 32
CHANGING THE UNIT OF MEASURE......................................................................................................................... 33
CHANGING THE UNIT OF MEASURE.........................................................................ERROR!BOOKMARK NOT DEFINED.
CALIPERING ....................................................................................................................................... 34
TAKING MEASUREMENTS ....................................................................................................................................... 34
MANUALLY ENTER A MEASUREMENT ...................................................................................................................... 36

GENERAL INFORMATION

Introduction

Thank you for purchasing the InstaCaliper™. The InstaCaliper measuring system semi-

automates nursery stock measurement.

The purpose of this manual is to provide information to allow users to safely and optimally

operate the InstaCaliper.

You may need to refer to sections of the RHC-E430 and Customer Portal User Manuals for

further instruction on operating the InstaCaliper system.

For your safety, it is critical that you carefully read and follow all warnings and cautions in this

manual. The InstaCaliper must only be used in the manner in which it is intended. Any other

use of the Insta-Caliper may cause damage to the device and harm to the user.

The following signs call attention to special warnings and cautions.

Caution: Failure to follow these instructions constitutes a hazard to the operator.

Warning: Failure to follow these instructions constitutes a hazard to the device.

Note: Important note.

System Requirements

Caliper Head

•Dimensions: 8.3” x 6.0” x 1.3” in (210 x 152 x 32 mm)

•Weight: 0.6 lbs. (0.27 kg)

•Power: 5V DC, 125 mA

•Operating Temperature: 32°F to 110° F / 0°C to 43°C

•Humidity: 90% RH, non-condensing

Ruggedized Handheld Computer

Winmate Rugged Handheld Device 7” Model Name: M700DM4

•Dimensions: 212.4 mm x 132.8 mm x 19 mm (8.36“ x 5.23” x 0.75”)

•Weight: 1.21lbs. (550 g)

•Power: 5V DC in, 15W Adapter

•Battery 3.7V, 5300mAh Li-Poly user

•Battery: 3.7V 5300mAh Li-Poly user replaceable battery

•Operating Temperature: AC Mode: -4°F to 140°F (-20°C to 60°C), Battery Mode: 14°F

to 122°F (-10°C to 50°C (Battery mode)

•Humidity: 5% ~ 95% RH non-condensing

TERMS AND DEFINITIONS

Term

Definition

Arm Support

Attachment that connects the Ruggedized Handheld Computer to the

Caliper Head

U-Shaped part that uses sensors to calculate diameter of an object

Customer Portal

Secure website where the customer manages InstaCaliper settings and

data. Access the Customer Portal by clicking:

http://portal.2ndsightbio.com

List

User-created category of information that can contain any number of

List Items. Each Task can have up to five Lists. “Variety” and “Location”

are examples of List names. See Figure 1 and 2 below.

List Item

User-created piece of information contained in a List. A List can contain

any number of List Items. “Juniper” and “Pine” are examples of List

Items. See Figure 1 and 2 below.

RHC

Ruggedized Handheld Computer with 2nd Sight software

Task

User-created activity that can contain up to five additional pieces of

information (Lists) to record with each measurement. “Evergreens” is an

example of a Task name. See Figure 1 and 2 below.

Figure 1

Figure 2

INSTALLATION

Unpacking and Inspection

Note: Save the original box and packaging material. Shipping the

InstaCaliper in a different box or with different packaging material may

damage the machine and void the warranty. To repackage, follow inverse

order of unpacking.

Unpack the boxes and examine their contents. If anything is missing or damaged, contact your

2nd Sight sales representative.

The InstaCaliper box contains:

•InstaCaliper Arm Support

•Caliper Head with Micro USB Cord

•Velcro Straps

•Ruggedized Handheld Computer (RHC)

•RHC Mounting Bracket

•Micro USB Charging Cord & 120v Plug

•Mounting Bolt (Caliper Head)

Unpacking the InstaCaliper Box

Step 1 Open the box.

Step 2 Carefully remove the InstaCaliper components from the box.

Assembling the Caliper Head

Step 1 Pull the Shaft Pole to the desired length.

Step 2 Push in the locking latches on bottom of shaft.

Step 3 Use a 4mm hex wrench to attach the

Caliper Head to the bottom Shaft Pole

using the provided bolt and nut. (4mm hex

wrench not included)

Assembling the RHC & RHC Mount

Step 1 Attach the RHC Mount to the top of

the Shaft Pole.

Step 2 Peel the adhesive cover off the RHC

Battery Mount piece.

Step 3 Adhere the Battery Mount piece to

the battery on the back of the RHC.

Ensure the ribs are positioned

vertically. Press firmly to secure.

Step 4 Attach the RHC Battery Mount to the

RHC Mount by aligning the ribs and

sliding the Battery Mount onto the

RHC Mount.
