ZyXEL Communications WAP3205 v2 Manuel utilisateur

Complying with the 802.11n standard, the ZyXEL WAP3205 v2 Wireless N300 Access Point can

enhance wireless speeds up to 300 Mbps* and extend the coverage.With the AP/Universal

Repeater/Client mode switch, you can setup the operating modes of WAP3205 v2 according to

your needs easily and instantly.

Benefits

Easily enhance wireless performance and coverage

The 802.11n standard-compliant WAP3205 v2 brings you wireless speeds of up to 300 Mbps* for

multimedia streaming.The all-in-one design allows WAP3205 v2 to perform as an AP, a WLAN client,

a universal repeater or a Wireless Distribution System (WDS) according to your needs for wireless

coverage extension and access sharing.

Simply set up wireless network and security

You can easily set up the operating modes of WAP3205 v2 to meet your needs through the AP/Universal

Repeater/Client mode switch without complicated configuration.The one-touch Wi-Fi Protected Setup

(WPS) push button of WAP3205 v2 only takes a few seconds to setup a secured wireless network.

Expend wireless networks effortlessly

Some wired devices such as Set-Top Boxes or network storage devices might not have wireless network

functions built-in; to connect these devices without additional wiring installation or configuration, just

plug an Ethernet cable from the wired devices to the LAN ports of WAP3205 v2 to connect them to the

home network.The WAP3205 v2 makes network connection simple and easier.

• 802.11n compliant with data

transfer rates of up to 300 Mbps*

• Two 5 dBi antennas enhance

wireless signals for stable data

transmission

• Four operating modes to satisfy

different needs for wireless

coverage extension

• AP/Universal Repeater/Client

mode switch simplifies operating

mode setup

• One-touch WPS button for

wireless security setup

• Two Ethernet ports for connecting

wired devices to wireless

networks

• Effortless wireless access control

with wireless on/off button

• Environment-friendly LED light

on/off button

WAP3205 v2

Wireless N300

Access Point

Easily Enhance Wireless Coverage for Your Needs N

300

5-100-00212008 06/12

For more product information, visit us on the web at www.ZyXEL.com

trademarks of ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned

are the property of their respective owners. All specifications are subject to change without notice.

Universal Repeater Mode

AP Mode Client Mode

InternetInternet

WAP3205 v2

Wireless N300

Access Point

NBG-419N v2

Wireless N300

NetUSB Router

Router

WAP3205 v2

Wireless N300

Access Point

Internet

WAP3205 v2

Wireless N300

Access Point

NBG-419N v2

Wireless N300

NetUSB Router

NSA325

2-Bay Power Plus

Media Server

Game

Console

Ethernet HDMI Cable

Application Diagram

System Specifications

Wireless Standard

• 802.11 b/g/n

Wireless Transfer Rate

• Receive: 300 Mbps*

• Transmit: 300 Mbps*

Wireless Security

• 64/128 bit WEP, WPA/WPA2, WPA-PSK/

WPA2-PSK

WLAN Features

• 4-in-1 operation modes, including access

point,WLAN client, universal repeater, and

WDS

• Wi-Fi Protected Setup (WPS)

• Wi-Fi Multimedia (WMM)

• Wireless scheduling

• Wireless output power management

• Auto channel selection

• MAC address filtering

System Management

• HTTP

• Diagnostic logs

• Online firmware upgrade

Hardware Specifications

• LAN:Two 10/100 Mbps Ethernet RJ-45 ports

with auto MDI/MDIX support

• LED indicators:

■Power

■LAN (1 - 2)

■Wireless

■WPS

• Antenna: Two 5 dBi detachable antennas

• Switch: AP/Universal Repeater/Client mode

switch for setting up operation mode

• Button/Switch:

■Wireless on/off button

■LED light on/off button

■WPS button

■Reset button

• Power rating: 12 V DC, 1 A

• Power consumption: 8 watt max.

Physical Specifications

• Item dimensions (WxDxH):

159 x 111 x 23 mm (6.26” x 4.37”x 0.91”)

• Item weight: 255 g (0.56 lb.)

• Packing dimensions (WxDxH):

247 x 61 x 155 mm (9.72” x 2.4”x 6.1”)

• Packing weight: 650 g (1.44 lb.)

Specifications

Environmental Specifications

Operating Environment

• Temperature: 0°C to 40°C (32°F to 104°F)

• Humidity: 10% to 90% (Non-condensing)

Storage Environment

• Temperature: -30°C to 70°C (-22°F to 158°F)

• Humidity: 10% to 95% (Non-condensing)

Certification

Safety

• CE, LVD

EMC

• CE, FCC, IC

Package Contents

• Wireless Access Point

• Two detachable antennas

• Ethernet cable

• Quick start guide

• Support CD

• Warranty card

* The maximum wireless data transfer rate is derived from IEEE Standard

802.11 specifications.Actual data transfer rate will vary from network

environment including: distance, network traffic,building site

materials/construction, interference from other wireless devices,and

other adverse conditions.

WAP3205 v2

Wireless N300 Access Point
