Benefits

Ultra-compact design for optimal portability

The compact, lightweight design of NWD2205 offers excellent portability. Users can easily plug

NWD2205 to a USB connector on desktop or laptop computers to upgrade the network speed

instantly. In addition, with bundled USB cable users can easily adjust the direction of NWD2205.

Latest 802.11n compliance with data transfer rates of up to 300 Mbps*

The ZyXEL NWD2205 USB adapter brings you faster wireless connection.With the data transfer rate

of up to 300 Mbps*, which is over 5 times faster than the 802.11g standard, the NWD2205 offers you

the high-speed connection everywhere under Wi-Fi coverage. It not only provides a high-speed

network capability, but also works with your existing 802.11b/g network.

Soft AP feature for sharing wireless Internet access

With the built-in soft AP function, the NWD2205 can help users to create wireless networks instantly.

Just plug NWD2205 into a desktop or laptop computer connecting to a cable or xDSL modem,all

other wireless-capable devices can connect to the Internet through the NWD2205.

Wi-Fi WMM certified for prioritizing multimedia streaming

With WMM QoS support, the NWD2205 is an excellent solution for you to deliver time-sensitive

applications such as video and voice streaming. It significantly enhances your experience on audio,

video and voice applications by prioritizing data traffic, so you can enjoy and share multimedia

contents with your family or friends without interruption.

■

Ultra-compact design for optimal portability

■

Latest 802.11n compliance with data transfer rates of up to 300 Mbps*

■

Soft AP feature for sharing wireless Internet access

■

Wi-Fi WMM certified for prioritizing multimedia streaming

■

One-touch WPS button for easy wireless security setup

■

Green adapter saves energy effortlessly

Upgrade Wireless Connection

in A Green Way

NWD2205

Wireless N USB Adapter

NWD2205

Wireless N USB Adapter

65-100-220502B 11/10

For more product information, visit us on the web at www.ZyXEL.com

trademarks of ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned are the

property of their respective owners. All specifications are subject to change without notice.

NWD2205

Wireless N

USB Adapter

NWD2205

Wireless N

USB Adapter

NBG-419N

Wireless N

Home Router

xDSL/Cable

Modem

Application Diagram

Internet

NWD2205

Wireless N USB Adapter

NWD2205

Wireless N USB Adapter

System Specifications

• Compliant with 802.11 standard

• Backwards compatible with 802.11b/g

• Wireless data transfer rate:

- Transmit: 300 Mbps*

- Receive: 300 Mbps*

• Wi-Fi Multimedia (WMM) support

• Wireless security:

- WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 802.1x

- WPS hardware button,WPS software feature

• Soft AP mode support

• Wireless green feature:

- Automatically adjust wireless output power by

detecting the distance between NWD2205 and

wireless access point

- Enter power-saving mode when no traffic

Hardware Specifications

• Operation voltage: DC 5 V

• One WPS button with Link/Act LED

• One USB 1.1/2.0 port

• Power consumption:

- Transmit: 315 mA

- Receive: 250 mA

Physical Specifications

• Item weight: 3 g (0.01 lb)

• Item dimensions:

36 (W) x 18 (D) x 6 (H) mm

(1.42 (W) x 0.71 (D) x 0.24 (H) inches)

• Packing weight: 81 g (0.18 lb)

• Packing dimensions:

95 (W) x 20 (D) x 135 (H) mm

(3.74 (W) x 0.79 (D) x 5.31 (H) inches)

Environmental Specifications

• Operating environment:

- Temperature: 0°C ~ 50°C / 32°F ~ 122°F

- Humidity: 20% ~ 90% (Non-condensing)

• Storage environment:

- Temperature: -30°C ~ 70°C / -22°F ~ 158°F

- Humidity: 10% ~ 90% (Non-condensing)

Certification

• FCC/CE/IC/NCC

• Wi-Fi 11b/g/n,WMM, WPS

• WHQL for Windows XP/Vista/7

OS Support

• Microsoft Windows XP,Vista, and 7

(32-bit/64-bit)

• MAC OS X v10.4, v10.5, and v10.6

Package Contents

• Wireless USB Adapter

• Support CD

• Quick start guide

• USB extension cable

• Warranty card

* The wireless data transfer rate 300 Mbps is the theoretical

maximum data transfer rate.The actual data transfer rate

may vary depending on the network environment.

Specifications

One-touch WPS button for easy wireless security setup

Establishing a secure wireless network is no longer a hassle.The WPS (Wi-Fi Protected Setup) feature takes just a few seconds to set up a secure wireless

network without complicated procedures. A click on the WPS button is all it needs to set up a secure wireless network easily.

Green adapter saves energy effortlessly

The ZyXEL NWD2205 brings you not only a plug-and-play wireless solution but also a smart way to save energy. Without complicated setup, just plug the

NWD2205 into your laptop or PC, and it automatically adjusts wireless output power by detecting the distance from the device to the wireless access point.

If the PC equipped with NWD2205 is close to the wireless access point, NWD2205 lowers the output power to reduce power consumption.When there is no

transmission traffic,the NWD2205 will enter the power-saving mode to save electricity.
