Zte SPARK LITE 3G Guide de référence

Spark Lite 3G

Help Guide

Get to Know Your Phone

Adding a memory card (optional)

The microSDHC memory card can be installed or removed

while the phone is turned on. You need to unmount the

microSDHC card before removing it.

Volume keys

Power key

Flash lamp

Charging/USB

jack

Headset jack

Camera

Speaker

Volume keys

Earpiece

Sensor

Front camera

Touch screen

Home key

Menu key

Back key

LED indicator

Power Key

Back cover

Insert your SIM card

WARNING!

To avoid damage to the phone do not use SIM adaptors. Only

insert a standard micro SIM from your service provider.

1. Insert your fingernail into the slot at the bottom left of the

back cover and lift it up gently.

2. Insert the micro SIM card with the cut corner as shown

The microSD memory card is an optional accessory

SIM slot

microSD

slot

3. Align the gold connectors on the phone and the battery

and insert the battery.

4. Replace the back cover.

Charging the Battery

The battery comes partially charged so connect the charger to

charge the battery fully.

WARNING!

Use only ZTE-approved chargers and cables. The use of

unapproved accessories could damage your phone.

Always insert the charger lead carefully.

Check the plug and socket are aligned correctly.

Do NOT use excessive force which may damage the USB

port.

Be careful to avoid tripping on the lead whilst it is plugged in.

Physical damage to the USB port is not covered by warranty.

1.Connect the charger to a standard AC power outlet.

2.Disconnect the charger when the battery is fully charged.

Power On and Off

Press and hold the Power Key to turn on your phone.

When already on, press the Power Key to light up your

screen.

Press and hold the Power Key to open the options menu.

Touch “Power off”.

TIPS

For general usage of the Android operating system there are

many guides available on line.

Pull down from the top of the screen twice to access the Quick

Settings panel and press the cog wheel at the top for Settings.

All Google apps use the three dots for Options in the app.

Press Options or long press on the Homescreen to add

widgets or change the wallpaper to customise your device.

Drag and drop an app from the apps tray to the Homescreen

as a quick shortcut to the app.

New apps downloaded from Play Store will be added to the

Homescreen automatically.

Settings

Pull down twice from the top of the screen and

press the Settings icon or goApps > Settings

Wi-Fi Switch Wi-Fi on and off. Scan

and join Wi-Fi networks.

Bluetooth Switch Bluetooth on and off.

Connect to Bluetooth devices.

Data usage Switch Data on or off. Check

your data usage details.

More – Flight

mode

Default SMS

app

Switch off all radio functions for

use on aircraft.

You can change your default

SMS app if required.

Tethering &

portable

hotspot

Control USB & Bluetooth

tethering and your Wi-Fi

hotspot.

VPN Configure Virtual Private

Networks.

Hard key Swap the Back and Recent apps

keys if required.

Display Set your display brightness,

sleep time, wallpapers etc.

Audio

Profiles

Set your Ringtone,

Notifications, vibrate and other

settings.

Prompt &

notification

Change interruption and

notification prompts for

different features

Storage Check available storage on your

device. Check SD card if fitted.

Battery Check battery level and see

what is using your battery

power.

Apps Review and control Apps,

memory, running processes

Delete

Applications

Delete installed apps (note

stock apps cannot be

uninstalled)

Location Configure location based

services. Touch Mode for GPS

mode.

Security Set lock screen security,

encryption modes and

passwords.

Accounts Manage your Gmail and other

accounts.

Language &

input

Control handset, keyboard,

spelling language options.

Factory data

reset

Backup to Google and perform

a Factory Reset.

Timer Switch

Machine

Schedule your device to switch

on and off automatically.

Date & time Manually set date & time

options and set date & time

formats.

Accessibility Enable features such as large

font, text to speech etc.

Printing Connect to Google on line

printing services.

About phone Check phone model, software,

version, IMEI status etc.

Switch to sleep mode (turn off the

display)

The display will automatically dim and turn off

after a pre-set period of time (see Settings >

Display) to save power and prevent inadvertent

operations such as making phone calls in your

pocket. It is also good practice to manually switch

off the display after use. Press the Power key to

turn your screen on or off during normal use.

Wake up your phone

After the phone switches to sleep mode the

screen will be turned off and locked. Press the

power key to wake up your device.

1. Press the Power key to turn on the screen.

2. Slide the icon up to unlock the screen.

If you've set an unlock PIN, pattern or password,

you need to draw the unlock pattern or input the

password to enter the main interface.

Secure your device

Go to Settings > Security > Screen Lock to apply a

lock screen to your device. Locking your device

will prevent unauthorised use.

Make and answer calls

Make a call from the Dialler

On the home screen, touch the button to

open the Dialler. Touch a recently called number

or press to open the Dial Pad and touch

to make the call.

Make a call from Contacts

On the home screen, touch the Contacts

icon, touch the desired contact and touch the

phone number to make a call.

Make a call from Call log

On the home screen, touch the button, the

recents tab shows recent calls. Touch the phone

icon to make a call.

Make an international call

On the home screen, touch the button >

to display the dial pad. Press & hold the “0”

key to get the “+” symbol for international calls.

Enter the country code, area code and phone

number, dropping the leading zero as normal.

Dial from Messaging

1. On the home screen, touch the Messaging icon

2. Touch a message or conversation to select it

3. Touch the icon at the top of the phone to

dial.

Answer a call

Your phone will ring or vibrate (depending on your

current settings) for an incoming call.

- Slide the icon from middle to right to

answer the call.

- If you are using another application press the

Answer or Reject button displayed at the top of

the screen. If you inadvently dismiss this panel,

pull down the Notifications Panel to retrieve the

Answer Call panel.

- If the earphone is inserted, press the key on the

earphone to answer the call.

Reject a call

Slide the icon from middle to left to reject

the call.

End a call

Touch the button to hang up the call.

Adjust the volume

In a call, you can raise or lower the volume by

using the volume keys.

Turn the speaker on or off

In a call, touch the button to turn on the

speaker, and touch it again to turn off speaker.

Add a multi party or Conference

call

In a call, touch for Options then Add call. Dial

a number and touch the phone icon to add one

call and put the current caller on hold. Press

Options > Merge to join the two (or more) parties

together.

Use touch tones during a call for

automated call systems

Touch the button to open the dial pad to

enter numbers during a call.

Contacts

You can place calls from the Phone app , the

Contacts app , or other apps or widgets that

display contact information. Wherever you see a

phone number or call icon, you can usually touch

it to dial.

The contacts interface can be divided into the

following tab pages:

- All Contacts: View the list of contacts.

- Favorites: Display the numbers you usually call.

All of your contacts are displayed alphabetically in

a scrollable list. Slide your finger up or down to

scroll through the list.

Add new contact

1. In Contacts, touch the add contacts icon

at the bottom right hand corner of the screen.

2. Select a memory location.

3. Input all contact information. Slide up to move

to the next field.

4. Touch the icon to save your contact.

Batch delete

1. In Contacts, touch the and then select

Delete contact.

2. Touch the contacts you want to delete or touch

, then touch the Done.

Edit contact details

1. In Contacts, touch the contact whose details

you want to edit.
