ZTE Blade C342

User Manual

Getting Started

Overview

Front camera

Earpiece

Touch Screen

Menu Key

Back Key

Home Key

Distance

Sensor

Volume Key

Power Key

Microphone

Headset Jack

Charging/USB Jack

Camera

Flash

Back Cover

Speaker

Keys Explained

Key

Function

Power Key

Hold to turn on or off Silent, Vibrate,

standard or Airplane mode, or to restart

or power off.

Press to switch your phone to Sleep

mode.

Press to wake up your phone.

Home Key

Press to return to the Home Screen from

any application or screen.

Hold to see Google search.

Menu Key

Press to get the options for the current

screen.

Hold to see recently used applications.

Back Key

Press to go to the previous screen.

Volume Keys

Press or hold to turn the volume up or

down

Switching Your Phone On/Off

Make sure the SIM card is in your device and the battery

is charged.

Hold Power Key to switch on your phone.

To switch it off, hold Power Key to get the phone options.

Select Power off, and then tap OK.

Setting Up Your Phone for the First Time

When you first power on your phone after you purchase it

or reset it to factory settings,you need to do some

settings before using it.

Reset to Factory Settings: Tap Menu Key in the standby

mode, then select SETTINGS > My device> Language &

input > Language to change the language you want to

use, if needed.

Switching to Sleep Mode

To save battery power, Sleep Mode suspends your device

to a low-power-consumption state while the display is off.

Your device also goes into Sleep Mode by itself when the

display is automatically turned off after a certain period of

time.

You can start sleep mode by pressing the Power Key.

Waking Up Your Phone

1. Press Power Key to activate your screen display.

2. Long press icon to unlock.

NOTE: If you have set an unlock pattern, PIN or password

for your phone, you’ll need to draw the pattern or enter

the PIN/password to unlock your screen.

Touch Control

You can use finger gestures to control your phone. The

controls on your touch-screen change dynamically

depending on the tasks you’re performing.

1. Tap the buttons, icons, or applications to select items

or to open applications.

2. Flick the screen to scroll up, down, left or right.

3. Drag to move particular items across the screen.

4. Double-tap the screen or pinching two fingers on the

screen apart/together to zoom in/out the screen.

NOTE: You can view the phone screen in portrait or

landscape orientation simply by holding it upright or

turning it on its side. Not all screens are viewable in

landscape.

Home Screen

In the Home screen, besides the shortcut icon is

displayed, you can also set your own wallpaper, add the

widgets or application shortcuts you need, or remove

them as you like.

Extended Home Screen

The Home Screen extends beyond the screen width,

giving you loads more space to add more stuff. Simply

slide your finger to the left or right.

Choosing Your Wallpaper

1. Press the Home Key to return to the Home Screen.

2. Tap the Menu Key and select CUSTOMIZE

DESKTOP >Set idle wallpaper.

3. Choose the image or animation you want to use as the

wallpaper. Some cropping may be needed for Gallery

images.

4. Tap Set wallpaper.

Adding Items to Your Home Screen

1. Press Home Key > tap to enter the main menu

Application Program Interface

2. In the list of applications, touch and hold the icon until

the main screen appears, move the application icon to the

idle position, release the finger.

Removing Items from Your Home Screen

1. Press the Home Key to return to the Home Screen.

2. Tap and hold the item you want to delete until the

Remove icon appears on the top of the screen.

3. Drag the item to the Remove icon and release your

finger when the item turns red.

Status and Notification Icons

Here is what simple icons mean.

USB connected

Missed call

Airplane mode

Signal strength

Battery charge

New message

Meeting mode

Wi-Fi network

Alarm set

Earphone insert

Silent mode

Signal searching

Bluetooth icon

USB debugging connected

Data Conn off

New Wi-Finetwork detected

Using the Notification Panel

Flick the status bar downwards from across the top of the

screen to open the Notification Panel, where you can see

your calendar events, new Messages and so on. Tap to

open the shortcuts panel from notification panel. To hide

the panel, tap on the bottom of the panel, drag up.

Open Recently-Used Applications

1. Press and hold the Menu Key from any screen. The

phone will display the applications you used recently.

2. Tap the application you want to open.

3. Slide the application away to end it.

Making Calls

There are many ways to make a call with your phone. And

They all are easy to do.

Calling from the Phone

1. Press Home key > tap > Phone on the Home

Screen.

2. Enter the number you want to call on the dial pad.

Tap to delete wrong digits.

3. Tap the dial icon .

4. Select SIM card 1 or SIM card 2 to dial.

Calling from Your Contacts

1. Press Home key > tap > Contacts .

2. Slide your finger to scroll the contacts list and tap the

contact name you want to call, when the contact details

appear, tap icon; choose the SIM card to dial.

3. You can search for a contact by

tapping on the screen.

Calling from Your Call Log

1. If you have opened the dialer, touch the call log tab to

open the call records, respectively touch all, dialed,

received, missed call button to display a list of the

corresponding call records.

2. Tap dial icon on the right side of the record.

Calling from a Text Message

If a text message contains a phone number that you

want to call, you can make the call while viewing the

text message.

1. Press Home key > tap > Messaging .

2. Tap the conversation and then find the message that

contains the phone number you need.

3. Tap the number; the phone will list the options.

Receiving Calls

Answering a Call

1. Lock screen to answer the call

Drag the icon down to answer the call.

2. Non lock screen to answer the call

Tap the icon to answer the call

Rejecting a Call

1. Lock screen to answer the call

Drag the icon down to reject the call.

2. Non lock screen to answer the call

Tap the icon to answer the call

Muting a Call

During a call, you can mute your microphone so that

the person you are speaking to cannot hear you, but you

can still hear them.

Turning the Speakerphone On/Off

Tap during a call to turn the speakerphone on. Tap

again to turn off the speakerphone.

Ending a Call

Tap to finish a call.

Contacts

You can add contacts on your phone and synchronize

them with the contacts in your Google account or other

accounts that support contact syncing.

Press the Home key > tab > Contacts .
