Zte MF68 Manuel utilisateur
ZTE MF68
User Manual
All rights reserved
No part of this publication may be excerpted, reproduced, translated or utilized in any form or
by any means, electronic or mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.
ZTE Corporation operates a policy of continuous development. ZTE Corporation reserves the
right to make changes and improvements to any of the products described in this document
without prior notice.
For this product's Recycling Manual based on WEEE directive, please send email to inquiry or
visit the website below to download:
WWW: http://ensupport.zte.com.cn
Release: V1.0
Manual number: 056584500508
01 03, 2008
Contents
3
1 Warning and precautions ................................................................... 6
1.1 Precautions ........................................................................................................................6
1.2 Aircraft safety .....................................................................................................................7
1.3 Precautions for medical Mobile Cams and facilities........................................................... 7
1.4 General safety....................................................................................................................8
1.5 Road safety........................................................................................................................8
1.6 Vehicles equipped with an air bag .....................................................................................9
1.7 Third-party equipment ........................................................................................................ 9
1.8 Radio frequency energy .....................................................................................................9
2Getting to know your Mobile Cam ................................................... 10
2.1 Overview ..........................................................................................................................10
2.2 Technical parameters ....................................................................................................... 10
2.3 Environment requirement................................................................................................. 11
2.4 Your Mobile Cam.............................................................................................................. 11
2.5 Getting started..................................................................................................................13
2.5.1 SIM/USIM card ....................................................................................................13
2.5.2 T-FLASH ..............................................................................................................15
2.5.3 Battery..................................................................................................................15
2.5.4 Charging the battery ............................................................................................15
2.5.5 Understanding indicators .....................................................................................17
2.6 Power on/off .....................................................................................................................18
2.7 Fixing the Mobile Cam onto the ceiling ............................................................................19
Contents
4
3White list............................................................................................. 20
3.1 Mobile Cam’s own phone number ................................................................................... 20
3.2 Setting administrator (AD) number .................................................................................. 20
3.3 Setting other user numbers ............................................................................................. 21
3.4 User entry ........................................................................................................................ 22
4Mobile CAM controlled by 3G video phone .................................... 23
4.1 Camera adjustment ......................................................................................................... 23
4.2 Adjusting speaker volume ............................................................................................... 23
5Administrator main menu operation ............................................... 24
5.1 Video phone main menu operation.................................................................................. 24
5.1.1 Adding users ....................................................................................................... 25
5.1.2 Deleting user ....................................................................................................... 25
5.1.3 Changing PIN code ............................................................................................. 26
5.1.4 Changing administrator number .......................................................................... 27
5.1.5 Video recording ................................................................................................... 28
5.2 SMS command operation ................................................................................................ 29
6Infrared/daylight Operation Modes and Non-white List User
Validation Function ........................................................................... 34
7Trouble Shooting............................................................................... 36
5
Thank you for using the Mobile Cam.
To guarantee the Mobile Cam is always in best condition, please read this manual
carefully and keep for further use.
The pictures and contents in this manual are for your reference only. They might not be
completely identical to your Mobile Cam.
Warning and precautions
6
1.1 Precautions
The Mobile Cam contains delicate electronic circuitry and battery systems. You should treat it
with care and pay particular attention to the following points:
Do not allow the Mobile Cam, battery or accessories to come into contact with liquids or
moisture at any time. Do not immerse in any liquid.
The Mobile Cam can’t do the video call over 3 hours continuously. If the time is over 3
hours, it will shut off automatically.
Do not place the Mobile Cam alongside computer disks, credit cards, travel cards or other
magnetic media. The information contained on disks or cards may be affected by the
Mobile Cam.
Do not leave the Mobile Cam in places where the temperature could exceed 60°C – e.g.
on a car’s dashboard or a windowsill or behind glass in direct sunlight.
Do not dispose the Mobile Cam in a fire. This equipment is fitted with an internal battery
that can only be replaced by a qualified service engineer so used batteries must be safely
disposed at a recycling point.
Do not attempt to dismantle the Mobile Cam or any of its accessories.
The Mobile Cam may become warm during normal use. The Mobile Cam may also
become warm while the battery is being charged.
Use a damp or anti-static cloth to clean the Mobile Cam. Do not use chemical or abrasive
cleaners as these could damage the case.
Warning and precautions
7
1.2 Aircraft safety
Onboard an aircraft, please turn off your Mobile Cam before take-off. In order to protect
aircraft communications systems from interference, do not use the Mobile Cam while in
flight. Using the Mobile Cam before take-off requires aircrew permission, according to
safety regulations.
Do not use the Mobile Cam on the ground at an airport without permission from
ground staff.
1.3 Precautions for medical Mobile Cams and facilities
When using your Mobile Cam near pacemakers, please: Always keep the Mobile Cam
more than 8 inches (20 centimeters) from the pacemaker while the Mobile Cam is
switched on.
If you use any other personal medical device, please consult the device manufacturer to
determine if it is adequately shielded from RF energy.
If on premises with special demands, such as hospital or healthcare facilities, please
pay attention to the restriction of the use of the Mobile Cams. Switch off your Mobile
Cam if required.
Warning and precautions
8
1.4 General safety
Keep the Mobile Cam out of the reach of small children. The Mobile Cam may cause
injury if used as a toy.
The operation of some medical electronic items, such as hearing aids and pacemakers,
may be affected if the Mobile Cam is used in close proximity. Observe any related signs
and manufacturer recommendations.
1.5 Road safety
Switch off your Mobile Cam at refueling points, such as petrol stations, even if you are not
refueling your own car.
Do not store or carry flammable or explosive materials in the same compartment as a
radio transmitter.
Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection
systems are not normally affected by radio transmissions. The manufacturer of such
equipment can advise if it is adequately shielded from radio transmissions. If you suspect
vehicle problems caused by radio transmissions, consult your dealer and do not switch on
the Mobile Cam until it has been checked by qualified and approved installers.
Warning and precautions
9
1.6 Vehicles equipped with an air bag
An air bag inflates with great force. Do not place objects, including installed or portable
wireless equipment in the area above the air bag or in the air bag deployment area. If
in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury
could result.
1.7 Third-party equipment
The use of third-party equipment, cables or accessories, not provided or authorized by
ZTE, may invalidate the warranty of your Mobile Cam and also adversely affect the Mobile
Cam’s operation.
1.8 Radio frequency energy
Your Mobile Cam is a low-power radio transmitter and receiver. When it is switched on, it
intermittently receives and transmits radio frequency (RF) energy (radio waves). The
system that handles the call also controls the power level at which the Mobile Cam transmits.
Getting to know your Mobile Cam
10
2 Getting to know your Mobile Cam
2.1 Overview
Empowered by the latest 3G technology, ZTE Mobile Cam is capable of receiving video phone
calls automatically. Users can dial the Mobile Cam from any WCDMA handset supporting video
phone calls, and view the picture with sound captured by the Mobile Cam anytime, anywhere.
The Mobile Cam supports video call, but doesn’t support voice call.
2.2 Technical parameters
Type ZTE Mobile Cam(Model: MF68)
Dimensions (W×L×H) 105mm × 85mm × 112mm
Weight 263g (with integrated battery)
Camera 0.3 megapixel
(solar/infrared dual mode)
Battery
Continuous standby time 120 - 200 hours
Recording time (in sunlight environment) 7 -12 hours
Recording time (in infrared environment) 3 - 5 hours
Video communication time (in sunlight environment) 2 - 3 hours
Video communication time (in infrared environment) 1.6 - 2.6 hours
Charging time 5 hours
