ZVM-328 User Manual Issue 05 Page 10 of 29
MEYERTECH LIMITED
The CAMERA OPTIONS MENU allows the user to configure all options on a camera by camera basis.
To view the current settings for a camera enter the camera number in the camera field. All other fields
on the page will then be updated with the current operating values.
Editable Fields are:
Camera [ ] Enter a camera number between 01 and 32. 0 = Global
Video [ ] Toggle between Video PRESENT and ABSENT. This should be used when
video loss is being detected to discount unused video inputs. Telemetry is
also affected by this field.
Camera Text Allows the user to enter a caption for the current camera of up to 24
characters in length.
Text Position Toggle camera caption text position TOP, BOTtom or OFF. This option is
applied to both camera and monitor captions as well as time and date text.
Time / Date [ ] Toggle time and date display TIME, DATE, BOTH or OFF.
Head Type [ ] This option defines the RS-422 telemetry protocol output. Options available
are:
DomeVu Must be selected when driving Meyertech telemetry receivers
DVR-xxx.
ZoneVu Must be selected when driving Meyertech telemetry receivers
ZVR-xxx over RS-422 .
ZV + VICTA Must be selected when driving Meyertech telemetry receivers
ZVR-xxx over coaxial cable
3
rd
party protocols The Series 328 will support a range of 3
rd
party
domes directly. See the supported driver documentation for
more information
For further information regarding Meyertech ZoneVu protocols or any
interfacing requirements please contact Meyertech Head Office. Contact
details can be found at the end of this document.
Caption Camera text on or off.
