Zonet ZEW3002 Manuel utilisateur
Copyright Statement
is the registered trademark of Zonet Technology Inc. All the products and
product names mentioned herein are the trademarks or registered trademarks of their
respective holders. Copyright of the whole product as integration, including its
accessories and software, belongs to Zonet Technology Inc. ithout the permission of
Zonet Technology Inc., any individual or party is not allowed to copy, plagiarize, imitate
or translate it into other languages.
All the photos and product specifications mentioned in this manual are for references
only. As the upgrade of software and hardware, there will be changes. And if there are
changes, Zonet is not responsible for informing in advance. If you want to know more
about our product information, please visit our website at www.zonetusa.com .
1
Table of Contents
Chapter 1 Introduction………………………………………………………………….2
1.1 elcome……………………………………………………………………………………………………2
1.2 Features………………………...…………………………………………………………………………2
1.3 Package contents………………………………………………………………………………………2
Chapter 2 Hardware Installation…………………………………………………….3
2.1 Panel Layout …………………………………………………………………………………………...3
2.1.1 The Top Panel………………………………………………………………………………….3
2.1.2 The Rear Panel…………………………………………………………………………………4
2.2 System Requirements………………………………………………………………………………4
2.3 Installation Environment Requirements………………………………………………….4
2.4 Hardware Connection……………………………………………………………………………….5
Chapter 3 Configure your Computer......................................................6
3.1 TCP/IP Address Setting..................................................................6
Chapter Configure your ZEW3002.......................................................8
4.1 Log in..........................................................................................8
4.2 izard........................................................................................9
4.3 System Status............................................................................11
4.4 LAN Setting................................................................................12
Chapter 5 Radio Configuration............................................................13
5.1 Basic Setting..............................................................................13
5.2 Mode Setting..............................................................................14
5.2.1 AP mode............................................................................14
5.2.2 DS P2P Bridge..................................................................15
5.2.3 DS P2MP Bridge................................................................17
5.2.4 DS AP Repeater................................................................19
5.2.5 Client mode........................................................................21
5.3 Access Filter...............................................................................22
Chapter 6 System Tools.......................................................................23
6.1 Change Password........................................................................23
6.2 Firmware Upgrade.......................................................................23
6.3 Reboot......................................................................................24
6.4 Restore Factory Default................................................................24
6.5 Restore / Backup Setting..............................................................25
6.6 Logout.......................................................................................25
6.7 Help..........................................................................................25
Chapter 7 Troubleshooting..................................................................27
Appendix I : Glossary.............................................................................28
2
Chapter 1 Introduction
1.1 Welcome
ZE 3002 is fully compliant with IEEE802.11g/b standards. It can help you extend from
the wired network to the wireless network, free from the cabling troubles. It is the best
choice for SOHO and small enterprise users. ZE 3002 provides five work modes: AP,
DS P2P Bridge, DS P2MP Bridge, DS AP Bridge and Client. It also supports
64/128-bit EP, PA, PA2. The MAC address filter can protect your network against
any malicious intrusion. Moreover, the eb management utility can benefit you to
manage the device easily.
1.2 Features
Supports IEEE 802.11g, IEEE 802.11b standards
Supports five connection modes: AP, DS P2P Bridge, DS P2MP Bridge, DS AP
Repeater and Client
Supports one 10/100M Auto-Negotiation Ethernet port
Supports 100 meters indoors and 300 meters outdoors (depends on the
environments around)
Supports eb management utility and easy Setup izard
Supports 64/128-bit EP, PA & PA2 encryptions and security mechanism
Supports IEEE802.11b/IEEE802.11g Auto-negotiation and manual configuration
modes
Supports Auto MDI/MDIX
Supports Netscape 6.1, IE5.5 or later
Supports authorization access over thirty-two MAC addresses
Supports auto wireless channel selection
Provides detachable antenna
1.3 Package Contents
One ZE 3002
One Detachable Antenna
One External AC Power Adapter
One Quick Installation Guide
One CD
3
Chapter 2 Hardware Installation
2.1 Panel Layout
2.1.1 The Top Panel
The top panel of ZE 3002 consists of several LED indicators.
Name
Action Description
OFF No Power
Power
ON
Power on
ON ZE 3002 is initializing
Flashing
ZE 3002 is working properly
SYS
OFF ZE 3002 has a hardware error
ON There is a device linked to the corresponding port but no activity
LAN
OFF There is no device linked to the corresponding port
ON There is a device linked to the corresponding port but no activity
Flashing
There is an active device linked to the corresponding port
LAN
OFF There is no device linked to the corresponding port
4
2.1.2 The Rear Panel
The rear panel contains the following features. (Viewed from left to right)
1. Power Jack only use the power adapter applied with ZE 3002 to prevent damage
2. One LAN 10/100Mbps RJ45 port for connecting to the router/modem, local PC or
switch/hub.
3. Factory Default Reset button
4. One external dipole antenna
There is a way to reset the ZE 3002’s factory defaults by using the Factory Default
Reset button:
1. Turn on ZE 3002’s power
2. Press and hold the default reset button, until the system LED lights up (about 5
seconds)
3. Release the reset button and wait for ZE 3002 to reboot.
Note: Ensure ZEW3002 is powered on before it restarts completely.
2.2 System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet)
PC on the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45
connector
TCP/IP protocol must be installed on each PC
eb browser, such as Microsoft Internet Explorer 5.5 or later, Netscape Navigator 6.1
or later
2.3 Installation Environment Requirements
Do not in direct sunlight or near a heater or heating vent
Do not in cluttered or crowded place. There should be at least 2 inches (5 cm) of clear
space on all sides of ZE 3002
ell ventilated (especially if it is in a closet)
Operating temperature: 0°C~40°C
Operating Humidity: 10%~95%RH, Non-condensing
5
2. Hardware Connection
Note: Before connecting ZEW3002, be sure to power off your computer, SL/Cable modem, and
ZEW3002. To achieve maximum wireless coverage, tilt the AP’s antenna outward at 45°
angle.
1. Connect one end of the cable to your broadband router, DSL/Cable modem, PC or
Switch/Hub port and connect the other end to the LAN port of ZE 3002.
2. Power on ZE 3002 by connecting one end of the supplied power adapter to the
power jack of ZE 3002 and connecting the other end to an electrical outlet.
3. Power on your computer.
4. Make sure the LEDs of ZE 3002 are lit. If not, try the above steps again.
6
Chapter 3 Configure your computer
3.1 TCP/IP Address Setting
Default IP Address: 192.168.0.25
Default Subnet Mask: 255.255.255.0
1. Click Start
→
→→
→
Settings
→
→→
→
Control Panel
2. Click Network and Internet Connections
→
→→
→
Network Connections
7
3. Choose Local Area Connection, right-click on the icon, choose Properties
→
→→
→
Local Area Connection Properties
→
→→
→
Internet Protocol (TCP/IP) and then click
Properties.
4. Choose Use the following IP address, enter the IP address as: 192.168.0.xxx.
("xxx" is from 1 to 253), Subnet mask is: 255.255.255.0
5. Click O to apply and return to Local Area Connection Properties page and then
click O to exit the setting window.
8
Chapter Configure your ZEW3002
.1 Log in
ZE 3002 provides eb based configuration scheme, which is, configuring by Netscape
Communicator or Internet Explorer. Take example for Microsoft Internet Explorer.
1. Open an Internet Explorer (or other web browser), type 192.168.0.25 in the
address bar, and then press Enter.
2. Input user name and password and then press O .
Default User Name: Admin
Default Password: Admin
3. After login successfully, welcome screen will be displayed.
