Zonet ZVC7610 Manuel utilisateur
- 1 -
1 Getting Started
Package Contents
One ZVC7610 or ZVC7610W
One AC Power Adapter
One Camera Stand
One RJ-45 Ethernet Cab e
One Insta ation CD w/ User Manua
One Quick Insta ation Guide
One Wire ess Antenna (ZVC7610W on y)
System Requirement
Networking
LAN: 10Base-T Ethernet 100Base-TX Fast Ethernet.
WLAN: IEEE 802.11b/g (ZVC7610W on y)
Accessing the Camera using Web Browser
P atform: Windows 2000/XP/Vista, Macintosh OSX
CPU: Inte Pentium III 800MHz or above
RAM: 512MB
Reso ution: 800x600 or above
User Interface: Internet Exp orer 6.0 or above, Mozi a Firefox 2.00 or above,
App e Safari 2 or above
- 2 -
2 Setting p the Camera
Installing the Camera Stand
ZVC7610/ZVC7610W comes with a Camera Stand. It uses a swive ba screw
head to ock to the camera’s screw ho es. Attach the Camera Stand and you
can p ace the unit anywhere by mounting the camera through the three screw
ho es which ocated at the bottom of the Camera Stand.
The Camera Stand
Connect ZVC7610 to your Network (LAN)
Use the provided RJ-45 Ethernet cab e to connect the ZVC7610 to your oca
area network (LAN).
ZVC7610 wi power ON automatica y after the AC Power Adapter is connected.
You may a so verify the power status from the Power LED on the front pane .
The Link LED wi start f ashing in green ight. ZVC7610 wi be on standby
mode and it is ready to use.
- 3 -
Connect ZVC7610W to your Wireless Network (WLAN)
You have to connect the Wire ess Antenna to the ZVC7610W if you’d ike to use
it in a wire ess network environment.
ZVC7610W wi start searching any avai ab e wire ess networks around it after
it is power ON.
NOTE: If the ZVC7610W cannot connect to your wireless network (WLAN , you’ll
have to configure the wireless settings through your network by using the
RJ-45 Ethernet Cable.
Connecting the RJ
-
45 Ethernet Cab e
Connecting the
Wire ess Antenna
- 4 -
3 Accessing the
ZVC7610/ZVC7610W
sing IP Finder
1. Insert the Insta ation CD into your computer’s CD-ROM drive and initiate
the Auto-Run program.
2. C ick IP Finder and the uti ity wi aunch automatica y. The fo owing
contro pane wi appear on your screen.
3. You may use your web browser or U tra View to access the configuration
after you obtained the IP address of the connected ZVC7610/ZVC7610W.
TIP: To insta IP Finder, you have to use the Insta ation CD and
insta the IP Finder setup program to your computer first.
Disp ay a connected
ZVC7610/ZVC7610W
C ick
Search
t
o find the IP address of the connected camera(s)
C ick Change IP to modify the IP address of the se ected camera
C ick Exit to c ose the uti ity
- 5 -
Configuration of ZVC7610/ZVC7610W
1. Open your web browser of your computer, for examp e: Microsoft Internet
Exp orer
2. Enter the IP address on the address bar and press Enter
Defau t IP Address: 192.168.0.30
3. The fo owing ogin window wi appear. Enter the username and password
to ogin and access the web configuration of the camera.
Defau t username: admin (a owercases)
Defau t password: admin (a owercases)
Enter the IP address here.
Enter Username and Password to ogin
- 6 -
4. C ick Setup and Smart Wizard to set up your ZVC7610/ZVC7610W quick y.
The Smart Wizard wi guide you through the necessary settings with
detai ed instructions of each step.
For more information of web configuration or Ultra View, p ease refer to the
User Manual in the provided Insta ation CD.
