ZipRip UC5E Manuel utilisateur
Operators Manual
UC5e (Revision 2-1)
ZipRip hardware and software is the property of SMA (Pty) Ltd Australia
P.O. Box 774, Fyshwick 2609,ACTAustralia
This documentation or any part of it may not be reproduced, stored or trans-
mitted in any form, including but not limited to electronic, photocopying,
mechanical copying, electrostatic copying, recording or other means without
express written permission of SMA(Pty) LtdAustralia
Windows is a registered trademark of Microsoft Corporation. Macintosh is a
registered trademark ofApple Computers Incorporated. Other brand or prod-
uct names, throughout this document, are trademarks or registered trade-
marks of their respective holders.
Ricoh and Priport are registered trademarks of Ricoh Japan.
4UC5e OM Rev2-1 July 2004
Table of Contents
Introduction ........................................................................ 5
Safety Information ............................................................. 6
Basic Specification ............................................................. 7
Generic Digital Duplicator Drivers Groups ................... 8
Package Contents ............................................................. 10
Testing your UC5E............................................................ 12
Activity Indicator............................................................... 13
GDI Printer Driver Installation....................................... 14
Win95/98/ME .................................................................. 15
Win NT ............................................................................ 20
Win2000 & XP................................................................. 25
Basic Operation of the UC5E .......................................... 32
Frequently Asked Questions ............................................ 34
Troubleshooting UC5E (GDI).......................................... 38
UC5e OM Rev2-1 July 2004 5
Introduction
The UC5E is a high speed interface for Digital Duplicators. With a UC5E
you can print directly from your PC to your Digital Duplicator. This will
significantly improve the quality of your printed material as well as speed up
your printing jobs.
We are confident that you will find it a pleasure to use and an asset to your
organisation.
Plug into interface port
Plug into „centronics“
parallel printer port
Windows 95/98/ME, Windows NT ,Windows 2000 and
Windows XP based PC.
6UC5e OM Rev2-1 July 2004
SafetyInformation
Thisequipment must beconnected to SELVcircuitsandother equipment com-
plying with the requirements of SELV circuits as defined in the standards
EN60950,IEC950 and CSAC22.2 N0. 950, UL 1950.
Sicherheit-Auskünfte
DieseAusrüstung muß zur SELV Schaltungen von anderenAusrüstungen,
diemitden Forderungen von SELV Schaltungendie in den Standards
EN60950, IEC950 und CSAC22.2 N0 950, UL1950 definiert werden,
nach kommen.
Renseignements de sécurité
ILest absolunent nécessaired’interconnecter cet équipment dux circuits
SELVdetoutéquipmentquiseconformeduxbesoirsdescircuits SELVcomme
précisés dux standards EN60950, IEC950 et CSAC22.2 NO. 950, UL 1950
UC5e OM Rev2-1 July 2004 7
Basic Specifications
Printer Language:..............................Windows GDI,
SupportedResolutions: .......................300, 400 and 600 dpi.
GraphicsScreening: ............................Coarse,Fine,LineArt,ErrorDiffusion.
Densitycontrolsupported.
SupportedDrivers:..............................Win95/98/ME.,Win 2000, Win NT,
WinXP
Ports:..................................................ECP/EPPparallelport.
OnBoardMemory: ............................16. MB
Supported
DigitalDuplicatorBrands:....................Ricoh, Gestetner, Rex Rotary,
Nashuatec, Savin and Standard. NB
check that your model has interface
support.
Certification ........................................CE, UL, FCC, ClassA.
SupplyVoltage....................................5VoltsfromDigitalDuplicator
8UC5e OM Rev2-1 July 2004
Driver Name Model Digital Duplicator Model
ZipRIP Classic A C224 VT2200/5327/1252/CP327/3200DNP
C226 VT2250/5329L/2546/CP329L/325DNP
C222 VT2400/5360/1270/CP360
ZipRIP Classic B C210 VT3500/5375/1280/CP375
C218 VT3600/5380/1285/CP380
C223 VT3800/5385/1290/CP385/330DNP
ZipRIPClassicX C228 VT6000/5390/1295/CP390/3400DNP/SD600
ZipRIP Pro A C231 JP1010/5306/1224/CP306
C237 JP1210/5308/1225/CP308
C248 JP1215/5308+/1225+/CP308+
ZipRIP Pro B C231 JP1030/5306L/1224L/CP306/3150DNP/D300
C231 JP1050/5306B/1224B/CP306B
C237 JP1230/5308L/3150eDNP/SD330
C237 JP1250/5308B/1225B/CP308B
C247 JP2800/5425C (China)
C248 JP1255/5308b+/1225B+/CP380
C248 JP1235/5309L/3160DNP/LDD020/SD333550
C248 JP1250/5300 (China)
C252 JP750/6123CP
C252 JP780C/5410C (China)
C252 JP730/6123LCP/LDD730
ZipRIP Pro C C229 JP5000/5450/1560/CP450/3350DNP/SD400
C239 JP5500/5450/5455/1560/CP450/3360DNP/
SD450
C249 JP4500/CP6244/3560DNP/SD420/LDD145
*ModelswithsuffixPTindicateadditionalpapertrayunitinstalled
Digital Duplicator Driver Groups
UC5e OM Rev2-1 July 2004 9
*ModelswithsuffixPTindicateadditionalpapertrayunitinstalled
Driver Name Model Digital Duplicator Model
ZipRIP Pro C PT C232 JP5800/5480/1580/CP480
C239 JP5500/5450/5455/1560/CP450/3360DNP/
SD450
ZipRIP Pro E C238 JP3000/5430/1330/CP430/3260DNP/SD370
JP3800/5428C (China)
ZipRIP Pro X C235 JP8000/5490/1395/CP490/3450DNP/SD630
C244 JP8500/5490+/5499/1395+/CP490+/
3460DNP/SD650
ZipRIP Pro X PT C235 JP8000/5490/1395/CP490/3450DNP/SD630
C244 JP8500/5490+/5499/1395+/CP490+/
3460DNP/SD650
DigitalDuplicatorDriverGroups(Continued)
10 UC5e OM Rev2-1 July 2004
Package Contents
Checkthatyouhave receivedthefollowingItemsin yourUC5Epackage.
ComponentsForGDIUC5E.
1. Main Board
2. Mounting Plate
3. Mounting Plate Cover
4. 2-pin cable and connector - C235
5. 2-pin cable and connector - C237
6. Keypad PCB
7. 26-pin MPU Ribbon cable(C235,C237
andC238)
8. 26-pin to 25-pin Ribbon PCB to Cover
9. 8-pin Ribbon cable - The long cable is
for C237 the other is for C235 and C238.
10. 11xM3x6mmScrews
11. 3 xM4x10mmStandoffs (C249)
123
456
78 9
10 11
UC5e OM Rev2-1 July 2004 11
12. 3 xM3x35mmStandoff
13. 3 xM4x45mmStandoff
14. 1 xM4x26mmStandoff
15. 4xM3x 25mmFFStandoff
16. 6xM3x 10mm MFStandoff
17. 1xM3x 10mmFFStandoff
18. Marguard LED and Button
19. PCDB25Maleto DB25 Male parallel
Cable
20. Installation CD and manuals
21. 6 x Cable Ties
22. 2 x 2.6mm Standoff-post - suppled with
IF Kit.
23. 3xM4 x 6mmScrews
12 14
15 16 17
18 19 20
21
13
22 23
