Zero88 Betapack 4 Manuel utilisateur
Betapack 4
Introduction
Compliance
Revisions
Warnings & Safety
Installation
Removing the cover
Connecting the mains
Getting started
Configuration & Settings
Default Mode & Channel Test
Manual Control
DMX Address
DMX Fail
Memories
Sequences
Preheat
Topset
Dimmer Laws
Super User
Lock
Reset
Firmware Version
Temperature
RDM
Maintenance & Care
Electrical
Mechanical
Troubleshooting
Support
Betapack has served the industry for 30 years with legendary reliability, robustness, versatility and value for money.
Betapack 4 builds on this heritage by distributing both dimming and “hot power” to a mixed rig of both tungsten and
LED fixtures in a single, affordable device. Betapack 4 continues to serve the most modern applications in lighting
rental, installation and portable situations for many thousands of venues worldwide.
Zero 88 - Betapack 4 - Page 1 of 22 Printed: 24/11/2020 14:35:29 ES
Betapack 4 includes variants with sockets to match most global standards, and is supplied with MCBs on every
channel. The versatility of the Betapack 4 means it can be 19” rack mounted or installed on a wall using the brackets
supplied, or made portable by using the included Easicarry kit consisting of a handle and four feet. Its legendary
reliability and durability make it the dimmer of choice for many thousands of venues worldwide.
Betapack 4
Please read this manual before use, especially the Warnings & Safety section.
E&OE. Cooper Lighting Solutions reserves the right to make changes to the equipment and specification
described in this manual without prior notice.
Zero 88 - Betapack 4 - Page 2 of 22 Printed: 24/11/2020 14:35:29 ES
Introduction
Thank you
Thank you for choosing Betapack 4 by Zero 88 to fulfil your lighting power needs. We sincerely hope that your new
unit will bring you years of trouble free service. We make great efforts to build in reliability and serviceability at every
stage of our development and production processes and include a three-year limited warranty - giving you peace of
mind for your investment.
Our extensive dealer network can also provide you with technical service and sales support in your local language no
matter where you are in the world. If you have any questions, comments or problems our contact details can be found
at zero88.com/support
Once again, thank you for choosing Zero 88.
This manual
This online manual describes the operation of Betapack 4.
For an overview of the Zero 88 Online Manuals, take a look at this
video.
For detailed information on each function, the manual has been
divided into chapters - one for each major area, which can be
navigated using the menu on the left-hand side. You can also search
the manual using the search bar top right.
Each section or whole chapters can be exported to PDF by tapping
"PDF", found just below the search bar. The whole manual can be
exported as a PDF, by tapping "PDF" at the top page of the manual.
Zero 88 online manuals are updated regularly to ensure you have all the relevant information and useful tips. Check
out the Revisions section to see what has been added. If you see something that doesn't look right, or have
Compliance
Zero 88 - Betapack 4 - Page 3 of 22 Printed: 24/11/2020 14:35:29 ES
Betapack
4
complies
with
the
following
standards:
EN 55015:2013 + A1:2015: Limits and methods of measurement of radio disturbance characteristics of
electrical lighting and similar equipment
EN 61547:2009: Equipment for general lighting purposes - EMC Immunity requirements
EN 61439-1:2011: Low-voltage switchgear and controlgear assemblies. Part 1: General Rules
EN 61439-2:2011: Low-voltage switchgear and controlgear assemblies. Part 2: Power switchgear and
controlgear assemblies
EN 50581:2012: Assessment of products with respect to RoHS II
Revisions
Change log of this manual
July 2020 - Manual Restructured - ES
June 2020 - Manual Created - ES
Zero 88 - Betapack 4 - Page 4 of 22 Printed: 24/11/2020 14:35:29 ES
Warnings & Safety
Do not remove the covers without first completely disconnecting Betapack 4 from the mains supply.
This product must be earthed.
This equipment is designed for professional stage lighting control and is unsuitable for any other purpose. It
should be used by, or under the supervision of, an appropriately qualified or trained person.
Zero 88 - Betapack 4 - Page 5 of 22 Printed: 24/11/2020 14:35:29 ES
Installation
Betapack 4 is designed for indoor use only.
In a 19" Rack
Betapack 4 is supplied with side brackets fitted for rack mounting.
On a wall
Undo the four screws ‘X’ to remove the brackets, replace the screws in
the holes for future use. Stand Betapack 4 on one end. Remove the
two screws ‘Y’, fit the brackets as shown and replace screws ‘Y’. Fit
the other bracket on the other end.
The wall drilling positions are shown. WARNING Completely fit one
bracket at a time. Removal of all four screws ‘Y’ at the same time can
allow the heatsink assembly to fall out! Allow a minimum vertical
spacing of 130mm between packs, and between packs and other
equipment. A spacing of 180mm is recommended for ease of wiring
and servicing.
For Portable Use
The ‘Easicarry’ Kit, consisting of a handle and four feet, is included
with Betapack 4. To fit, remove the brackets. Fit the handle using the
screws supplied and holes ‘Z’. Fit the four feet to the other end using
the holes ‘X’ and ‘Y’.
When one or more Betapack 4 units are mounted in an enclosed rack, a fan MUST be fitted to ensure that
adequate cool air is circulated. Up to three Betapack 4s may be stacked in free air.
Zero 88 - Betapack 4 - Page 6 of 22 Printed: 24/11/2020 14:35:29 ES
Ventilation
Betapack 4 is convection cooled with air flowing over the rear mounted
heatsink.
Betapack 4 is convection cooled and includes a temperature sensor
which monitors the internal temperature. If the temperature risesabove
the normal operating level the outputs are first reduced, thenswitched
off altogether until the temperature falls back to a safe level.
The table shows how Betapack 4 will react under these conditions.
(Note: The temperature shown on the display will be the actual
temperature not the rounded figures given in the table).
Removing the cover
Do not remove the covers without first completely disconnecting Betapack 4 from the mains supply.
Isolate and disconnect Betapack 4 from the mains supply.
The mains supply terminals (and output terminals on the hardwire version) are located under the top cover. To remove
the top cover, remove the four screws from the side plates marked “A” in the diagram below.
The Triacs (type BTA40-600A/B) are located under the bottom cover. To remove the bottom cover, remove the four
screws from the side plates marked “B” in the diagram below.
Zero 88 - Betapack 4 - Page 7 of 22 Printed: 24/11/2020 14:35:29 ES
Connecting the mains
This product must be earthed.
A separate isolator and secure mains earth connection are required.
Phase to Neutral voltage must not exceed 255VAC.
All wiring entering Betapack 4 must be rated to +85ºC, H07RN-F cable is recommended.
Cut outs are provided on the ends and rear for PG21 glands; one is supplied.
Supply terminals will accept wire sizes between 1.5mm2 and 16mm2. Tightening torque is between 1.2Nm
and 2.4Nm.
Hardwire Live/Neutral output terminals will accept wire sizes up to 6mm2.
Hardwire Earth output ring-tags (blue crimp) will accept wire sizes between 1.0mm2 and 2.5mm2. These
may be replaced if larger diameter wiring is installed.
Three phase
Betapack 4 is supplied configured for three-phase star operation as
shown.
Single phase
For single-phase operation, fit the supplied linking bar between the L1,
L2 and L3 terminals as shown.
Zero 88 - Betapack 4 - Page 8 of 22 Printed: 24/11/2020 14:35:29 ES
Three phase delta
For three-phase delta operation, the 6 neutral wires must be removed
from the terminal block, and the crimped ferrules must be cut off. Strip
the ends of these 6 wires, and reconnect as shown.
Zero 88 - Betapack 4 - Page 9 of 22 Printed: 24/11/2020 14:35:29 ES
Getting started
Betapack 4 distributes both dimming and non-dimming (“hot power”) to a mixed rig of both tungsten and LED fixtures.
Each of the six channels are capable of driving up to 10 amp loads.
The dim and hot power socket for each channel share the same channel MCB. The hot power sockets are fed directly
from the channel's MCB. Hot power sockets are therefore not affected by DMX control, and are on dependent on the
state of the MCB. The dimmed and hot power sockets for a channel can therefore be used simultaneously, providing
that the total channel load does not exceed 10 amps.
Betapack 4 features MCBs as standard. When dimming, there are preheat, topset and 3 laws per channel, 12
memories, 3 99-step sequences, local control and DMX patch per channel.
An isolated DMX512-A input and loop-through allow for remote operation. When the loop-through plug is not inserted,
the DMX line is automatically terminated.
The DMX control port supports RDM (Remote Device Management) functionality.
Zero 88 - Betapack 4 - Page 10 of 22 Printed: 24/11/2020 14:35:29 ES
