Zenith A09A02X Manuel utilisateur

machine numbers A09A02X

operating guide / warranty

thanks for

choosing zenith!

hook up directory page 3

RECORD YOUR MODEL NUMBER

(Now, while you can see it)

The model and serial number of your new TV are located

on the back of the TV cabinet. For your future convenience,

we suggest that you record these numbers here:

MODEL NO.____________________________________

SERIAL NO.____________________________________

WARNING:

TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence

of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

POWER CORD POLARIZATION:

CAUTION: To Prevent Electric Shock, Match wide blade of plug to wide slot, fully insert.

ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne

correspondante de la prise et pousser jusqu’au fond.

NOTE TO CABLE/TV INSTALLER:

This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code

(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be

connected to the grounding system of the building, as close to the point of the cable entry as practical.

REGULATORY INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following

measures: •Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

CAUTION:

Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation.

Unauthorized modification could void the user’s authority to operate this product.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

206-3366-0

INSTALLATION GETTING STARTED PAGE 3

This page will

direct you to

which page

to go to for

proper hook-

up of your

Entertainment

Machine.

Hook-Up Directory

IMPORTANT!!

Use this page to decide where you need to begin your setup. First, find the line

below that best describes what you want to do, then go to that page number.

Cable TV

wall jack

Cable box

Out

Cable TV

wall jack

Cable box

Out

If you are using an antenna, go to . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6

If you have cable or are using a cable box, go to . . . . . . . . . . . . . . . . . . . . . . . . . page 6

If you are using an antenna and have a VCR, go to . . . . . . . . . . . . . . . . . . . . . . . page 7

If you have cable or are using a cable box and a VCR, go to . . . . . . . . . . . . . . . . . . page 7

Antenna only

Cable only

Antenna with VCR

Cable and VCR

Antenna

UNDERSTANDING YOUR TV THE JACKPACKPAGE 4

Your jack-pack

and its

various uses.

Understanding the Rear Jackpack

DC Input Jack

This is the jack to use

when you want to connect

your DC cord for direct

current (DC) power from a

12-volt source such as a

car cigarette lighter, etc.

Antenna /RF Jack

Attach your antenna,

cable-TV line or VCR

to this jack.

Phone Jacks Can

be used for connecting headphones, ear-

phones or an external speaker. 8-ohm imped-

ance at 1.5 watts (min) subminnature plug

3.5mm (1/8”).

TV Built-in Monopole

Antenna Connector

If you are using the

“over-the-air” built-in

antenna supplied with

the TV, connect this

to the Antenna jack.

Audio/Video Input

Jacks for connecting the

audio and video signals

from VCRs, camcorders and

various other types of

equipment.

For DC operation, use only a 12-volt negative ground power

source or the TV may be damaged.

Mini glossary

JACK A connection on the back of a TV, VCR or any other A/V device. This includes the RF jacks and the Audio/Video jacks

that are color-coded.

SIGNAL Picture and sound traveling through cable or in the air to your television screen.

206-3366-o

UNDERSTANDING YOUR TV TV CONTROL PANEL PAGE 5

See at a

glance what

each button

on the front

of your TV

controls and

operates.

Mini glossary

SOURCE This is the term for the equipment that provides audio and video information to your Entertainment

Machine. Antenna, Cable Boxes or VCRs are examples of a source.

Front Panel Diagram

206-3366-o

1This is the Remote Control Window.

Point the Remote Control at this

window to operate the TV.

This is the SOURCE button. Press it

to select your picture source, either

from Antenna or from Video.

Press repeatedly to choose the dif-

ferent picture adjustment options.

Press the Up/Down ADJUST buttons

to change the selected menu option.

Use either of the VOLUME Up/Down

buttons to increase or decrease the

audio level of your Entertainment

Machine.

Press the CHANNEL Up/Down buttons

to select a higher or lower numbered

channel than you are currently

watching.

This is the Power Indicator Light

that lets you know that your

Entertainment Machine is receiving

power.

This is the POWER button. Press to

turn the the TV on and off.

When the Power Indicator Light is

dimly lit, it indicates that the power

is connected to the TV. When the

Power Indicator Light is brightly lit it

indicates that the TV is turned on.

Always try to keep the immediate area

in front of the Remote Control Window

clear for easier remote control access.

206-3366-o

INSTALLATION STANDARDPAGE 6

Connect an

antenna/cable

or cable box

to your

Entertainment

Machine.

Basic Hook Up of your Antenna, Cable or Cable Box to the TV

Mini glossary

75 OHM RF CABLE The wire that comes from an off-air antenna or cable service provider. Each end looks like a hex shaped nut with a wire

sticking through the middle, and it screws onto the threaded jack on the back of your TV.

300 TO 75 OHM ADAPTER A small device that connects a two-wire 300 ohm antenna to a 75 ohm RF jack. They are usually about an

inch long with two screws on one end and a round opening with a wire sticking out on the other end.

Remember, when connecting RF

cables onto jacks, clockwise

tightens and counterclockwise

loosens.

Please refer to diagram then

hook up your

Entertainment Machine.

Remove the back of the

remote and put in two AAA

batteries.

Plug in your TV. Do not plug it

into a switched outlet.

Go to page 10 to Auto Search

your Entertainment Machine.

206-3366-o

INSTALLATION TO VCR PAGE 7

Connect

a VCR to your

Entertainment

Machine.

Mini glossary

CABLE SERVICE The wire that supplies all your cable TV (CATV) stations.

If you’re using a cable box, leave your

TV on channel 3 or 4 and use your

cable box to change channels.

Remember, when connecting RF cables

onto jacks, clockwise tightens, and

counterclockwise loosens.

If you’re using a cable box, Auto-

Search might only find the channel

your cable service is on (usually chan-

nel 3 or 4). Don’t worry, that’s all you

need!

Basic Hook Up of your Antenna, Cable or Cable Box to the TV and VCR

Hook up your

Entertainment Machine as

outlined above.

Remove the back of the

remote and put in two AAA

batteries.

Plug in your TV. Do not plug

it into a switched outlet.

Go to page 10 to Auto Search

your Entertainment Machine.

206-3366-o

INSTALLATION QUICK STARTPAGE 8

Use Auto

Search to

automatically

find and

store all of

the stations

available in

your area.

Auto Search

With the remote control in hand,

press the POWER button to turn

on your Entertainment Machine.

Press the TV/CATV button on the

remote control repeatedly to

choose the TV picture signal

source.

Now press the AUTO SEARCH key

and the TV will collect all of the

live channels that are available

through your signal source.

Mini glossary

AUTO SEARCH Auto Search is how your Entertainment Machine finds all the channels available in your area and stores them into memory.

Select TV, if your signal is coming

from an antenna. Select STD if

your signal is coming from a cable

service.

If the picture from your cable ser-

vice is weak or snowy, try running

the AUTO SEARCH in the IRC and

HRC mode until you find the mode

that gives you the best picture.

206-3366-o

OPERATION BUTTON FUNCTIONS PAGE 9

A quick list

of all the

buttons on

your remote

and what

they do.

POWER

Turns controlled

device on and off.

Mute

Turns sound off and on.

Volume(Up/Down)

Adjusts the sound level

on your Entertainment

Machine.

Channel(Up/Down)

Cycles through available

channels.

NUMBER KEYPAD

Use for direct

channel

entry.

TV/CATV

Use to select Tuning Band,

either TV or cable service

modes STD, IRC and HRC.

SKIP/SEARCH

Allows you to skip to next

channel in memory or search

each available channel..

remote control part number

SC3492

The Buttons on Your Remote

SOURCE

Selects either the Antenna

jacks or the Audio/Video

jacks as the source of the

TV picture.

100+

Use when selecting

channel numbers

higher than 100.

Example: For 125,

press 100+, then 2

and then 5.

AUTO SEARCH

Use to find and retain all avail-

able channels in memory.

ERASE/WRITE

Use to erase or add channels

into memory.


Press repeatedly to select

picture settings.

ADJUST UP/DOWN

Use to change settings in

picture menu.

A broken or lost Remote Control? Call 1-800-255-6790 to purchase a replacement.

206-3366-o

OPERATION MENUSPAGE 10

Quicker

access to

your

favorite

channel

listings

Skip/Search

Press the SKIP/SEARCH button on

your Remote Control.

If you want to see every channel

numerically in the channel scan, put

the Skip Mode into the OFF position.

If you want the channel scan to go

directly to the saved channels only,

press the SKIP/SEARCH button until

in the Skip Mode displays ON. The TV

will do the rest!

Autres manuels pour A09A02X

Table des matières

Autres manuels Zenith TV

Zenith

Zenith D27B48T Manuel d'utilisation et d'entretien

Zenith

Zenith SENTRY 2 SY2500 Manuel d'utilisation et d'entretien

Zenith

Zenith Z36H32 Manuel d'utilisation et d'entretien

Zenith

Zenith IQA32M46W Series Manuel utilisateur

Zenith

Zenith SENTRY 2 SMS1917SG Manuel d'utilisation et d'entretien

Zenith

Zenith IQB42P97G Manuel d'utilisation et d'entretien

Zenith

Zenith B27A34Z Manuel utilisateur

Zenith

Zenith H13E01L Manuel d'utilisation et d'entretien

Zenith

Zenith R56W36 Manuel utilisateur

Zenith

Zenith SM2571BT Manuel d'utilisation et d'entretien

Zenith

Zenith A50M84W Series Manuel utilisateur

Zenith

Zenith ZLD15A1 Manuel d'utilisation et d'entretien

Zenith

Zenith SENTRY 2 Z27A11 Manuel d'utilisation et d'entretien

Zenith

Zenith B25A11Z Manuel utilisateur

Zenith

Zenith Concierge H27C35DT Guide de dépannage

Zenith

Zenith L23W36 - 23" Widescreen Flat-Panel HD-Ready LCD... Manuel utilisateur

Zenith

Zenith Sentry 2 SLS1935W Manuel d'utilisation et d'entretien

Zenith

Zenith A27B43 Manuel utilisateur

Zenith

Zenith A13P01D Manuel utilisateur

Zenith

Zenith Concierge H20E35DT Manuel d'utilisation et d'entretien

Zenith

Zenith C27C35T Series Manuel d'utilisation et d'entretien

Zenith

Zenith Sentry 2 SY2518 Manuel d'utilisation et d'entretien

Zenith

Zenith SENTRY 2 SLS2751Y and warranty Manuel d'utilisation et d'entretien

Zenith

Zenith SENTRY 2 SR1941 Manuel d'utilisation et d'entretien

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
