Zenith R50W47 Manuel utilisateur

50" 16:9 HDTV Rear Projection (R50W47)

◗Integrated NTSC/ATSC/Digital Cable QAM

(unscrambled) Tuner

A fully integrated ATSC tuner with the ability to

receive off-air high definition broadcasts without the

need for an external set-top box. A digital cable tuner

(QAM) allows for the reception of digital cable signals

that are not scrambled

◗HD Grade Optics

Improves brightness and focus, and reduces overall

cabinet depth

◗HD Focus

Automatic system that eliminates the need to manually

adjust the picture. Simply select HD Focus from the

onscreen set-up menu, and 16 sensors automatically

adjust the picture from center to edge in ten seconds

◗Fine Pitch Screen

0.52mm dot pitch improves picture detail

◗HD Grade High Output CRTs

Improved CRTs maximize brightness and picture detail.

Specifically developed for digital program content

◗Improved Digital Display

Most HDTVs use upconversion of analog signals (line-

doubling) to simulate an HD picture, which introduces

artifacts that appear as pixilated scenes due to digital

conversion. Using advanced digital display, these

picture artifacts are nearly eliminated

◗3:2 Pulldown Cinema Correction

Most movies are shot on film, and film operates at a

frame rate of 24fps (frames per second), compared to

video which operates at 30fps. 3:2 pulldown properly

detects and syncs film to video for smooth theater-like

pictures at home

◗Built-In High Contrast Protective Shield

◗Built-In Rear Carrying Handles

Easily move from room to room

50" 16:9 HDTV Rear Projection (R50W47)

JACK PACK

RF In 1 Terrestrial/Cable Antenna (Analog)

Monitor Out 1

Hi-Res Component Video In (Y PB PR) 2

S-Video In 2 Rear/1 Side

A/V Inputs 3 Rear/1 Side

Fixed Audio Out 1

DVI w/HDCP 1

ADDITIONAL INFORMATION

Cabinet Dimensions:

Width x Height x Depth 45.9" x 53.0" x 19.9"

Weight 121.2 lbs.

Dimensions with Packaging:

Width x Height x Depth 51.5" x 56.7" x 27.7"

Weight 138.9 lbs.

UPC Code 04464270070 6

CABINET DESCRIPTION

Finish Silver

Screen Protector Yes (Scratch Resistant)

Casters Yes

SERVICE/LIMITED WARRANTY

Service Support Level "M" Module Level

Warranty: Parts/CRT/Labor 1 Year/2 Years/1 Year

REQUIRED APPROVALS

UL, C-UL

Dimensions and weights are approximate. Design and specifications subject to change without notice.

HDTV monitors require optional set-top box to receive high-definition broadcast.

Dolby® is a registered trademark of Dolby Laboratories.

Marketed and Distributed by LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

www.zenith.com 1-877-9-zenith

VIDEO ENHANCEMENTS

Screen Size 50"

Resolution Display 480i/480p/1080i

Mirror 1st Surface

Lens System Enhanced HD

Lens Elements 4-Element

Fine Pitch Screen Yes (0.52mm)

Tuning System 1-Tuner NTSC/ATSC/QAM (Unscrambled)

Aspect Ratio 16:9

Aspect Ratio Correction Yes

Scan Velocity Modulation Yes (3 Modes)

HD Digital Auto Convergence 16-Sensor Auto Convergence

Enhanced Line Doubler Yes (Progressive Scan)

All Format Up Converter Yes

Dynamic Focus Yes

3:2 Pulldown Cinema Correction Yes (Manual)

Color Temperature Warm/Cool

Gamma Correction Yes

Digital Comb Filter 3D Y/C

Black Level Exp./White Level Compression Yes

Video Noise Reduction Yes

Home Theater Mode Yes (4 Modes: User, Clear, Optimum, Soft)

AUDIO ENHANCEMENTS

MTS/SAP Yes

Surround Sound Virtual Dolby®

Bass/Treble/Balance Yes

Total Audio (Watts) 30W (15W x 2)

Volume Limiter Yes

DSP Sound Fields Yes (5 Modes: User, Movie,

Sports, Music, Virtual)

SPECIAL FEATURES

Picture-in-Picture (PIP) 2-Tuner

Picture-outside-Picture (POP) 4 Picture

Split Window Yes

Picture Swap Yes

Digital Index Yes

Tri-lingual Menus English, Spanish, French

Auto Programming Yes

Channel Add/Delete Yes

Surf's Up Favorite Channel Yes

Parental Control with V-Chip Yes

On/Off Timer Yes

Sleep Timer Yes

Clock Yes (Manual)

Flashback Yes

CC/CC When Mute/2-Level Mute Yes

Time/Channel Display Yes

REMOTE CONTROL

Transmitter Illuminated Universal Remote

DVD IN VIDEO 1

VIDEO 2

MONITOR

OUTPUT

VIDEO

AUDIO

AUDIOAUDIOAUDIOAUDIO

VIDEO

S-VIDEO 1 S-VIDEO 2

HD IN

DIGITAL AUDIO

OUTPUT

OPTICAL

ANTENNA/

CABLE 1

ANTENNA/

CABLE 2

1080i/720p/

480i/480p

1080i/720p/

480i/480p

DVI
