USER MANUAL

PCDI-24V

PROGRAMMABLE CDI IGNITION AND PV CONTROLLER

TECHNICAL DATA

Limit values:

- minimum revs 200 RPM

- maximum revs 20000 RPM

- minimum supply voltage 8 Volts

- maximum supply voltage 16 Volts

- max. supply voltage for 1 minute 35 Volts

- current draw 25 mAmp

- maximum continuous current for shift light output 1 Amp

- peak current for shift light output 5 Amp

Circuit is protected against reverse supply voltage (wrong connection).

Features:

- CDI charged from hi voltage charging coils (generator)

- programmable ignition map (3D interpolated)

- store and load function for 2 ignition maps

- one input for magnetic pickup

- TPS input (ignition map is 3D interpolated above TPS33%)

- external switch for changing ignition map while riding

- power jet output

- quick shift (shift kill)

- tachometer output

- advance/retard whole ignition curve

- programmable timing offset between twin output (RD/RZ500)

- three stage rev limit (retard timing, reduced spark, spark off)

- signal delay compensation

- timing calculation for every 1 RPM change (1000, 1002, .. , 9805, 9806, ...)

- programmable power valve actuation

- store and load function for 5 PV curves

- programmable PV deviation

- programmable max close and max open positions

- self PV test on power-up

- 2 -

- PV error detecting (position sensor failure, servo motor failure)

- easy and fast programming on the field, via hand held programmer

- programming while machine running - you can immediately see effects

- monitoring of rev's, TPS position, ignition and PV angle, via LCD(hand held programmer)

- fast processing for high accuracy - delays from 1us

1. HOW TO ENTER MENU

PCDI must be connected to power supply. Connect programmer to PCDI and wait few

seconds for activation of programmer and then press enter. With pressing + or - you can

move through menu and select with pressing enter .

Exit menu with selecting Exit.

2. MENU ORGANISATION

Set Ign. - set ignition parameters submenu

Set PV - set PV parameters submenu

Exit

2.1. SET IGNITION PARAMETERS SUBMENU

Load Ign. Curve - load previously saved ignition curve set (from #1 to #2)

Save Ign. Curve - save new ignition curve set (from #1 to #2)

Ignition Curve - ignition curve parameters submenu

Advance - advance/retard whole ignition curve

Out 1→2 Advance - timing offset between outputs

Power Jet - power jet

Shift Kill Time - shift kill time

Rev Limit - rev limit

Static Angle - static angle (stator position)

Compensation - signal delay compensation (from pickup to spark plug)

TPS close [0%] - calibrating TPS close position

TPS open [100%] - calibrating TPS open position

Remote SW - activating/deactivating external switch

Exit

- 3 -

2.2. SET PV PARAMETERS SUBMENU

Load PV Curve - load previously saved curve (from #1 to #5)

Save PV Curve - save new curve (from #1 to #5)

Set PV Curve - valve curve parameters submenu

Deviation +- - deviation of valve position

Close Position - max close valve position

Open Position - max open valve position

PV test - valve position test

Exit

3. LOAD IGN. CURVE

Enter menu and move to Load Ign. Curve with pressing + or - and then press enter .

Now you can select position number of previously saved ignition curve set, with pressing +

or - and then press enter .

4. SAVE IGN. CURVE

Enter menu and move to Save Ign. Curve with pressing + or - and then press enter .

Now you can select position number to which you want to save your ignition curve set, with

pressing + or - and then press enter .

5. Set IGNITION CURVE

Three ignition curves must be programmed for different TPS positions. PCDI does not only

switch between ignition curves, but also calculate timing between programmed curves for all

TPS positions above 33%. From 0% to 33% TPS is used only one ignition curve.

Enter menu and move to Ignition Curve with pressing + or - and then press enter .

Now you are in submenu for selecting ignition curve.

Submenu organisation:

Nr. of Points - number of ignition curve points (from 4 to 10)

Curve 0-33% - ignition curve from 0 to 33% TPS

Curve 66% - ignition curve for 66% TPS

Curve 100% - ignition curve for 100% TPS

Exit - exit submenu

Important!

To avoid wrong processing, don't make unreasonable curve course.

Every time you make any changes to ignition curve, it is automatically saved to #0 position.

Then you can save it to any other position number from #1 to #2.

- 4 -

Curve Example:

5.1. Set NUMBER OF IGNITION CURVE POINTS

Move to Nr. of Points with pressing + or - and then press enter .

Now you can select number of ignition points, with pressing + or - and then press enter .

5.2. Set PARAMETERS OF IGNITION CURVE POINT

Move to point you want to change, with pressing + or - and then press enter .

Now you can change rev point with pressing + or - (in 100 rpm steps) and then press

enter .

Now you can change advance angle with pressing + or - (in 0.1deg steps) and then press

enter .

6. Set ADVANCE

With this setting is possible to advance or retard whole ignition curve. When setting is

positive then ignition curve is advanced and when setting is negative than ignition curve is

retarded. With Advance 0.0deg, ignition curve is unchanged.

Enter menu and move to Advance with pressing + or - and then press enter .

Now you can set advance with pressing + or - (in 0.1deg steps) and then press enter .

7. OUT 1→2 ADVANCE

It is timing advance from output 1 to output 2 in degrees. Programmable timing offset enable

compensation of front to rear crank offset on RD/RZ500.

Enter menu and move to Out 1→2 Advance with pressing + or - and then press enter .

Now you can change offset in degrees with pressing + or - and then press enter .

- 5 -

8. Set POWER JET parameters

Enter menu and move to Power Jet with pressing + or - and then press enter .

Now you are in submenu for selecting Power Jet parameters.

Submenu organisation:

Power Jet ON RPM - revs for activating power jet

Power Jet OFF RPM - revs for deactivating power jet

Power Jet ON TPS - throttle position for activating power jet

Exit - exit submenu

Example:

Power jet ON (RPM) = 8000rpm

Power jet OFF (RPM) = 10000rpm

Power jet ON (TPS) = 90%TPS

Power jet is switched on, when revs are above 8000rpm and throttle position above 90%TPS.

Power jet is switched off, when revs are above 10000rpm or throttle position is below

90%TPS.

8.1. Set POWER JET ON RPM

Enter menu and move to Power Jet 1 ON RPM with pressing + or - and then press enter .

Now you can change rev limit with pressing + or - (in 100 rpm steps) and then press

enter .

8.2. Set POWER JET OFF RPM

Enter menu and move to Power Jet OFF RPM with pressing + or - and then press enter .

Now you can change rev limit with pressing + or - (in 100 rpm steps) and then press

enter .

8.3. Set POWER JET ON TPS

Enter menu and move to Power Jet ON TPS with pressing + or - and then press enter .

Now you can change TPS position with pressing + or - (in 1%TPS steps) and then press

enter .

9. Set SHIFT KILL TIME

Enter menu and move to Shift Kill Time with pressing + or - and then press enter .

Now you can change kill time with pressing + or - (in 10 ms steps) and then press enter .

- 6 -

10. Set REV LIMIT

Enter menu and move to Rev Limit with pressing + or - and then press enter .

Now you can change rev limit with pressing + or - (in 100 rpm steps) and then press

enter .

11. Set STATIC ANGLE

Enter menu and move to Static Angle with pressing + or - and then press enter .

Now you can set static angle with pressing + or - (in 0.1deg steps) and then press enter .

More information's about static angle you can find in section 22.

12. Set COMPENSATION

It is compensation of signal delay from pickup to spark plugs. You can check this delay with

stroboscope lamp. Without this compensation, ignition advance angle decreasing with rising

revs.

This compensation helps that advance angles in ignition curve are real (more accurate).

How to check, if compensation is correct:

First you must set flat ignition curve. Then measure with stroboscope lamp, if mark at

flywheel moving when changing revs. If mark moving, then you must change compensation

delay.

Change Compensation:

Enter menu and move to Compensation with pressing + or - and then press enter .

Now you can change compensation delay with pressing + or - and then press enter .

13. Set TPS close [0%]

For correct operation, TPS close position must be calibrated!

Enter menu and move to TPS close [0%] with pressing + or - and then press enter .

Leave throttle at close position and confirm calibrating with pressing enter , or exit

calibration with pressing - . Displayed number should be between 0 and 500.

14. Set TPS open [100%]

For correct operation, TPS open position must be calibrated!

Enter menu and move to TPS open [100%] with pressing + or - and then press enter .

Move throttle to maximum open position and confirm calibrating with pressing enter , or exit

calibration with pressing -. Displayed number should be between 500 and 1010.

- 7 -

15. Set REMOTE SW

Enabling or disabling external switch for changing ignition curves while riding.

Enter menu and move to Remote SW with pressing + or - and then press enter .

Now you can enable or disable external switch with pressing + or - and then press enter .

16. LOAD PV CURVE

Enter menu and move to Load PV Curve with pressing + or - and then press enter .

Now you can select position number of previously saved ignition curve set, with pressing +

or - and then press enter .

17. SAVE PV CURVE

Enter menu and move to Save PV Curve with pressing + or - and then press enter .

Now you can select position number to which you want to save your ignition curve set, with

pressing + or - and then press enter .

18. Set PV Curve

Enter menu and move to Set PV Curve with pressing + or - and then press enter .

Now you are in submenu for setting valve curve.

Submenu organisation:

Nr. of Points - number of valve curve points (from 2 to 8)

1) - first valve position point

2) - second valve position point

... ...

Exit - exit submenu

Important!

To avoid wrong processing, don't make unreasonable curve course.

Every time you make any changes to valve curve, it is automatically saved to #0 position.

Then you can save it to any other position number from #1 to #5.

18.1. Change Number of Curve Points

Move to Nr. of Points with pressing + or - and then press enter .

Now you can select number of curve points, with pressing + or - and then press enter .

- 8 -

18.2. Change Parameters of Valve Position Curve Points

Move to point you want to change, with pressing + or - and then press enter .

Now you can change rev point with pressing + or - (in 100 rpm steps) and then press

enter .

Now you can change valve position from 0% to 100%, with pressing + or - (in 1% steps)

and then press enter .

19. Deviation

Enter menu and move to Deviation with pressing + or - and then press enter .

Now you can change deviation from 2% to 20% with pressing + or - (in 1% steps) and then

press enter .

Deviation means how accurate valve is moved to calculated position. If deviation is too low

then servo motor won't be stabile – it will always search for calculated position in small

movements. Default setting is +-5% and should meet in most cases.

20. Max Close Position

Enter menu and move to Close Position with pressing + or - and then press enter .

Now you can set close position with pressing + or - and then press enter .

Max close position is when curve is set to 0%. This close position can be moved to any

desired position. For RZ350 default close position is 240. Max close position can be moved to

deeply closed or less closed position.

21. Max Open Position

Enter menu and move to Open Position with pressing + or - and then press enter .

Now you can set open position with pressing + or - and then press enter .

Max open position is when curve is set to 100%. This open position can be moved to any

desired position. For RZ350 default open position is 512. Max open position can be moved to

more open or less open position.

22. PV Test

Enter menu and move to PV Test with pressing + or - and then press enter .

Now you can set valve position with pressing + or - and then press enter .

PV test can be used for testing or measuring valve position. Valve can be moved to any

position from 0% to 100%, without engine running.

- 9 -

23. MECHANICAL SETTINGS (Static Angle)

Static Angle is ignition advance angle, set with stator (generator).

Measure this angle with dial gauge. This measured Static Angle is your maximum advance

angle you can set with PCDI.

Example:

Measured Static Angle = 39.2deg (this angle you must enter in PCDI)

Calculating mm to deg or vice versa:

24. MONITORING

Connect programmer to PCDI and wait few seconds for activation of programmer. Fist

information displayed on the programmer is software version.

With programmer you can watch revs, calculated advance ignition angle, PV valve position

and TPS position.

Information!

You can connect or disconnect PCDI unit from programmer any time you want, without any

harm. It is not important, if motor running or not and if power supply is connected or not.

Important!

Do not use too much force when connecting or disconnecting programmer unit!

25. ERROR REPORTS

Two errors can be displayed:

Program Memory Error - when program memory is corrupted. With this error present,

function of program could be faulty.

EEPROM Error - when eeprom memory is corrupted. All programmable data are stored in

eeprom memory (curve, rev limit...). With this error present, function of program could be

faulty. You must check all your settings and correct changed.

PVerror 1 – position sensor error, or servo motor disconnected

PVerror 2 – servo motor error (short connection)

Autres manuels zeeltronic Contrôleurs

zeeltronic

zeeltronic PCDI-VE1 Manuel utilisateur

zeeltronic

zeeltronic PDCI-24 Manuel utilisateur

zeeltronic

zeeltronic PPV-RZ3 Manuel utilisateur

zeeltronic

zeeltronic PCDI-RGT Manuel utilisateur

zeeltronic

zeeltronic PDCI-20V Manuel utilisateur

zeeltronic

zeeltronic PSR-S01 Manuel utilisateur

zeeltronic

zeeltronic PCDI-10 Manuel utilisateur

zeeltronic

zeeltronic PDCI-44V Manuel utilisateur

zeeltronic

zeeltronic PDCI-24V Manuel utilisateur

zeeltronic

zeeltronic PDCI-24VT Manuel du propriétaire

zeeltronic

zeeltronic PDCI-11V Manuel utilisateur

zeeltronic

zeeltronic VCDI-04 Manuel utilisateur

zeeltronic

zeeltronic PDCI-NS1V Manuel utilisateur

zeeltronic

zeeltronic PDCI-11V Manuel utilisateur

zeeltronic

zeeltronic PDCI-11 Manuel utilisateur

zeeltronic

zeeltronic ZeelProg PSR-B11T Manuel du propriétaire

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur

zeeltronic PCDI-24V Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques
