Zebex Z-3101 Mode d'emploi

GLLS

Advanced Handheld CCD/Laser Scanner

Revision History

Changes to the original manual are listed below:

Version Date Description of Version

1.0 September 9, 2010 Initial release

1.1 February 18, 2011 Added Blink mode selections

1.2 April 30, 2013 Corrected AIM mode

1.3 May. 21, 2013 Corrected ASCII code in appendix

1.4 August 01, 2013 Added Appendix 5 Header and Trailer

1.5 August 26, 2013 Corrected Repeat mode descriptions

1.6 April 29, 2014 Added Auto Detect Mode

1.7 August 22, 2014 Added Multi-line modes

Important Notice

No warranty of any kind is made in regard to this material, including, but not limited to,

implied warranties of merchantability or fitness for any particular purpose. We are not

liable for any errors contained herein nor for incidental or consequential damages in

connection with furnishing, performance or use of this material. We shall be under no

liability in respect of any defect arising from fair wear and tear, willful damage,

negligence, abnormal working conditions, failure to follow the instructions and warnings,

or misuse or alteration or repair of the products without written approval. No part of this

document may be reproduced, transmitted, stored in a retrieval system, transcribed, or

translated into any human or computer or other language in any form or by any means

electronic, mechanical, magnetic, optical, chemical, biological, manual or otherwise,

except for brief passages which may be quoted for purposes of scholastic or literary

review, without express written consent and authorization. We reserve the right to make

changes in product design without reservation and without notification. The material in

this guide is for information only and is subject to change without notice. All trademarks

mentioned herein, registered or otherwise, are the properties of their various, ill,

assorted owners.

General Handling Precautions

Do not dispose of the scanner in fire.

Do not put the scanner directly in the sun or by any heat source.

Do not use or store the scanner in a very humid place.

Do not drop the scanner or allow it to collide violently with other objects.

Do not take the scanner apart without authorization.

Printing Guidance

This programming guide is in A5 size. Please double check your printer setting before

printing it out.

When barcodes are to be printed out for programming, the use of a high-resolution laser

printer is strongly suggested for the best scan result.

Advanced Handheld CCD/Laser Scanner ii

Advanced Handheld CCD/Laser Scanner

iii

Laser Safety

This equipment generates, uses, and can radiate radio frequency energy. If not installed

and used in accordance with the instructions in this manual, it may cause interference to

radio communications. The equipment has been tested and found to comply with the

limits for a Class A computing device pursuant to EN55022 and 47 CFR, Part 2 and Part 15

of FCC Rules. These specifications are designed to provide reasonable protection against

interference when operated in a commercial environment.

Radiant Energy: The laser scanner uses one low-power visible laser diodes operating at

650nm in an opto-mechanical scanner resulting in less than 3.9μW radiated power as

observed through a 7mm aperture and averaged over 10 seconds.

Do not attempt to remove the protective housing of the scanner, as unscanned laser light

with a peak output up to 0.8mW would be accessible inside.

Laser Light Viewing: The scan window is the only aperture through which laser light may

be observed from this product. A failure of the scanner motor, while the laser diode

continues to emit a laser beam, may cause emission levels to exceed those for safe

operation. The scanner has safeguards to prevent this occurrence. If, however, a

stationary laser beam is emitted, the failing scanner should be disconnected from its

power source immediately.

Adjustments: Do not attempt any adjustments or alteration of this product. Do not

remove the protective housing of the scanner. There are no user-serviceable parts inside.

Optical: The use of optical instruments with this product will increase the eye hazard.

Optical instruments include binoculars, magnifying glasses, and microscopes but do not

include normal eye glasses worn by the user.

CAUTION: Use of controls or adjustments or performance of procedures other than

those specified herein may result in hazardous radiation exposure.

For CE-Countries

This scanner is in conformity with CE standards. Please note that an approved, CE-marked

power supply unit should be used in order to maintain CE conformance.

Advanced Handheld CCD/Laser Scanner iv

Table of Contents

About This Guide ........................................................................................................1

Introduction to Scanner Configuration.......................................................................2

Default Parameters.....................................................................................................3

Scanner Operation ............................................................................................3

Interface Communication .................................................................................3

Symbologies......................................................................................................4

Data Formating .................................................................................................5

Programming Procedure.............................................................................................6

Parameter Setting.......................................................................................................7

Scanner Operation ............................................................................................7

Interface Configuration ...................................................................................19

The Symbologies .............................................................................................27

Data Editing.....................................................................................................51

Appendix 1: USB Virtual COM Driver Installation ...........................................56

Appendix 2: Barcode Length Setting...............................................................57

Appendix 3: Multi-Barcode Editor ..................................................................58

Appendix 4: Full ASCII Code 39 Table .............................................................60

Appendix 5: Header And Trailer......................................................................65

Advanced Handheld CCD/Laser Scanner

PROGRAMMING GUIDE

About This Guide

This programming guide applies to various handheld scanners, including

* Advanced Handheld Contact CCD Scanner,

* Advanced Middle-Range Handheld CCD Scanner,

* Advanced Handheld Laser Scanner, and

* Advanced Handheld High-Speed Laser Scanner

Some settings are not available for certain models. If you are not sure about the

model of your scanner at hand, refer to the device label or contact your distributor.

This document is in A5 size. Please check your printing setting before printing it out.

When barcodes are to be printed out for programming, the use of a high-resolution

laser printer is strongly suggested for the best scan result.

The settings herein shall be updated periodically without prior notice. For the latest

version, please contact your distributor.

Advanced Handheld CCD/Laser Scanner 2

PROGRAMMING GUIDE

Introduction to Scanner Configuration

Scanning a series of programming barcode labels can configure the series scanners.

This allows decoding options and interface protocols to be tailored to a specific

application. The configuration is stored in non-volatile memory and will not be lost by

removing power from the scanner.

The scanner must be properly powered before programming. For RS-232C type

scanners, an external power adapter must be used to supply DC power to the scanner.

If a keyboard emulation type scanner is used with an IBM PC/XT/ AT, PS/2 or any fully

compatible computers, power will be drawn from the keyboard port. No external

power adapter is required. If keyboard emulation type scanner is used with any other

non IBM PC compatible computers, an external power adapter may be needed.

During the programming mode, the laser scanner will acknowledge a good and valid

reading with a short beep. It will give long beeps or remain silent for either an invalid

or bad reading.

Programmable options are divided into four groups. The first group includes the

options that show the general behavior of the laser scanner. The second group

governs the operation of different interfaces, RS-232 serial ports, keyboard, and USB.

The third group sets the decoding parameters for each barcode symbology. The last

group is about more advanced data formatting.

Advanced Handheld CCD/Laser Scanner

PROGRAMMING GUIDE

Default Parameters

This table gives the default settings of all the programmable parameters. The default

settings would be restored whenever the laser scanner reads the "Reset"

programming label in programming mode. If you wish to change any setting, scan the

appropriate barcodes below.

Scanner Operation

Parameter Default

Same code delay 500msec

Beeping frequency Medium

Beeping duration 50msec

LED/Beep before data transmission On

Scan mode Trigger mode

Stand mode (only available for specific models) Enable

Header and trailer None

Inter message delay 0msec

Inter character delay 0msec

Interface Communication

Parameter Default

RS-232 Interface

Baud rate 9600

Parity none

Data Bits 8

Stop Bit 1

RTS/CTS off

Terminator <CR><LF>

Keyboard Wedge Interface

Terminal Type PC/AT

Keyboard US keyboard

Terminator Enter

USB Interface

Terminator type Enter

Code mode Scan code

Keyboard US keyboard

Wand Emulation

Wand emulation speed Normal

Data output Black=high

Advanced Handheld CCD/Laser Scanner 4

PROGRAMMING GUIDE

Symbologies

Parameter Default

Decoder Selection

EAN/UPC Enable

Code 39 Enable

Code 32 Disable

Codabar Enable

ITF 2 of 5 Enable

MSI Disable

Chinese Post Code Disable

Code 93 Enable

Code 128 Enable

EAN-128 Disable

Telepen Disable

Code 11 Disable

Standard 2 of 5 Disable

Industrial 2 of 5 Disable

Matrix 2 of 5 Disable

GS1 DataBar Disable

PDF417 Disable

Code Identifiers

Identifier code as factory standard Disable

Identifier code as AIM standard Disable

Code 39 identifier code M

ITF 2 of 5 identifier code I

Chinese post code identifier code H

UPC-A identifier code A

UPC-E identifier code E

EAN-13 identifier code F

EAN-8 identifier code FF

Codabar identifier code N

Code 128 identifier code K

Code 93 identifier code L

MSI identifier code P

Code 11 identifier code O

Standard 2 of 5 identifier code S

Industrial 2 of 5 identifier code D

Matrix 2 of 5 identifier code G

GS1 DataBar identifier code RS

GS1 DataBar Limited identifier code RL
