ZAVIOOutdoorIRMiniDome
Quick Installation Guide
1
Quick Installation Guide
Please follow the installation steps below to set up your IP Camera.
Check the package contents with the list below. See P.1
Physical overview. See P.2
I/O Terminal Block Circuit. See P.3
I/O Terminal Block Pin Definition. See P.3
LED Indicator Definition. See P.3
Power mode. See P.4
Installation of hardware and connection of all cables. See P.4
Windows: Go to Zavio website and download Camera Installation Tool. See P.9
Access the IP Camera using Camera Installation Tool. See P.10
MAC OS: using Safari Browser. See P.13
Lighting environment. See P.15
Change language of the web interface. See P.15
Application of IP Camera. See P.16
Package Contents
Camera IP Camera
Quick Installation Guide Brief product information and quick installation
Accessory Alignment Sticker, L-type hex key wrench,
Screw pack for wall and ceiling mounting,
Plastic plate for wall and ceiling mounting,
2 pin terminal block DC connector, 6 pin cable for
DI/DO and audio, Focus adjustment tool
Software
The following software and information are available online:
- Video Management Software
- Camera Installation Tool
- User manuals
- Camera Language Packs
You may download the above at http://www.zavio.com/downloads.php or you
may scan the below QR-Code.
ToactivateVideoManagementSoftware,pleaseenterthelicensekeybelow.
2
Physical overview
Built-in Microphone
Dome bubble Top cover
Ethernet Socket
Lens
MicroSD/SDHC
Reset
Power LED Indicator
Network LED Indicator
External I/O connector
DC 12V/1A
Internal microphone
Light Sensor
IR LEDs
Routing hole
3
I/O Terminal Block Circuit
I/O Terminal Block Pin Definition
PIN Definition Description Max. V/A
Black Ground -
Brown + 12VDC
12V DC
1.2 W
Red Audio In
Connect the wires of the audio input device to GND
(Pin 1) and AUDIO.IN (Pin 3). -
Orange Audio Out Connect the wires of the audio output device to
GND (Pin 1) and AUDIO.OUT (Pin 4). -
Yellow Digital
Output 1
Uses an NPN transistor with the emitter connected
to the GND pin. If used with an external relay, a
diode must be connected in parallel with the load
for protection against voltage transients.
100 mA
24V
Green Digital
Input 1 Connected to GND to activate, or leave floating (or
unconnected) to deactivate. 30V DC
LED Indicator
LED Color Indication
Network Blue Solid blue when network is established.
Blink blue when there is network activity.
Power
Red Solid red for booting up process
Blue Solid blue for booting up completion
Purple Blink purple during: (a) firmware upgrade, (b) reset
button pressed for at least 5 sec to factory default.
Unlit When reset button is pressed or when power off.
4
Power Mode
PoE Mode Power Requirement PoE (IEEE802.3af) with Class 3
Power Consumption 4.19 W
Adaptor Mode Power Requirement 12V/1A Adaptor
Power Consumption 4.24 W
Install the hardware and connect all cables
A. Hardware installation
1) Loosen the tamper-proof screws using supplied L-type hex key wrench and
remove the dome cover. Be careful not to scratch the dome cover.
2) You may feed the cables through the upper conduit hole or the side conduit
hole. Please use the supplied blind pug to seal the unused conduit hole.
3) Side conduit hole installation: Disassemble the cable gland first and feed the
network and I/O cable through the sealing nut, claw and cable gland. Connect
the cables to the camera. Attach the cable gland to the conduit hole. Push the
claw into the cable gland and tighten the sealing nut to secure the cables.
B. Wall and ceiling mounting
1) Attach the alignment sticker to the wall/ceiling. Drill three holes into the wall -
two for screws and one for cable.
2) Align the screw holes on the plastic base to the two plastic anchors on the
wall/ceiling, insert the supplied screws to the hole and secure them.
3) Secure the camera to the plastic plate with the screws (M2.5x6 * 2pcs)
5
6
C. Wall mounting with L-type bracket (optional)
1) Drill two holes and hammer the supplied screw anchors on the desired
installation location.
2) Align L-type bracket to the two plastic anchors on the wall/ceiling, insert the
supplied screws to the corresponding hole and secure them.
3) Secure the plastic plate to the L-type bracket with screws (M4x10 * 2pcs)
4) Secure the camera to the plastic plate with screws(M2.5x6 * 2pcs)
7
D. Outdoor wall mount kit with L-type bracket (optional)
1) Drill two holes and hammer the supplied screw anchors on the desired
installation location.
2) Align L-type bracket to the two plastic anchors on the wall/ceiling, insert the
supplied screws to the corresponding hole and secure them.
3) Assemble the silicone rubber and outdoor kit together.
4) Put O-ring on the screws (M4x10); secure the outdoor kit to L-Type bracket.
5) Secure the camera to the plastic plate with screws(M2.5x6 * 2pcs)
6) Paste the waterproof-tape at microphone hole on the top cover.
Conduit
Conduit
Note: Once waterproof sticker is
pasted on top cover for outdoor
used, microphone reception will be
affected.
8
E. Connect all cables
E1. Without Power over Ethernet (PoE) connection
1. Connect the power adaptor to the IP Camera.
2. Use a standard RJ-45 network cable and connect the IP Camera to a
hub/switch/router.
E2. Power over Ethernet (PoE)
1. Use a standard RJ-45 network cable and connect the IP Camera to a
PoE-enabled hub/switch/router.
F. To adjust the view angle- 3 axis mechanism design
1) Turn the lens module right and left to your desired pan position.
2) Turn the lens module up and down to your desired tilt position.
3) Turn the lens module to adjust the image orientation to satisfied angle.
9
Important:
Make sure the IR LEDs are not blocked by the housing as it will affect the IR performance.
If the image is upside down, please use the image rotate function in Video Setting.
G. Completion
Fix the tamper-proof screws using supplied special hex. Be careful do not scratch
the cover glass. Clean the dome bubble to remove the dust and finger print.
Windows: Go to Zavio Website and download Camera Installation Tool
Please go http://www.zavio.com/softwaredownloads.php download “Camera
Installation Tool”. And follow the installation process to complete the
installation.
