User Manual

Chapter 1. Safety Instruction

Before you use this product

This product has been designed with safety in mind. However, the electrical products can cause

fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to

heed the following.

Legal Caution

Video and audio surveillance can be forbidden by laws that vary from country to country. Check the

laws in your local region before using this product for surveillance purposes.

Don't open the housing of the product

Don't try to open the housing or remove the covers which may expose yourself to dangerous voltage

or other hazards.

Don't use the accessories not recommend by the manufacturer

Heed the safety precautions

Be sure to follow the general safety precautions and the “Operation Notice.”

Operation Notice - Operating or storage location

Avoid operating or storing the camera in the following locations:

Extremely hot or cold places

(Operating temperature: 0 °C to + 50 °C [32 °F to 122°F] )

Exposed to direct sunlight for a long time, or close to heating equipment (e.g., near heaters)

Close to water (e.g.,near a bathtub, kitchen sink, laundry tub)

Close to sources of strong magnetism

Close to sources of powerful electromagnetic radiation, such as radios or TV transmitters

Locations subject to strong vibration or shock

In case of a breakdown

In case of system breakdown, discontinue use and contact your authorized dealer.

Safety Instruction

F7110 / F7115 User Manual

In case of abnormal operation

If the unit emits smoke or an unusual smell,

If water or other foreign objects enter the cabinet, or

If you drop the unit or damage the cabinet:1 Disconnect the cable and the connecting cables. 2

Contact your authorized dealer or the store where you purchased the product.

Transportation

When transporting the camera, repack it as originally packed at the factory or in materials of equal

quality.

Ventilation

To prevent heat buildup, do not block air circulation around the device.

Cleaning

Use a soft, dry cloth to clean the external surfaces of the device. Stubborn stains can be

removed using a soft cloth dampened with a small quantity of detergent solution, then wipe dry.

Do not use volatile solvents such as alcohol, benzene or thinners as they may damage the

surface.

Safety Instruction

F7110 / F7115 User Manual

Chapter 2. Minimum System Requirement &

Product Feature

2.1 System Requirement

For normal operation and viewing of the network camera, it’s recommended that your

system meet these minimum requirements for proper operation:

Item Requirements

CPU Pentium 4 1.8GHz (or equivalent AMD)

Graphic Card 64 MB RAM graphic cards(or equivalent on-board graphic cards)

RAM 512 MB

Operating

System

Windows 98, Windows ME (Please see Note)

Windows2000, 2003, XP, Vista, Mac OS X Leopard

Web Browser Internet Explore 6 or later

Note:

1. If using Windows 98 or Windows ME, please install IP Installer before using WEB UI to

ensure the system runs normally.

2. If not able to view the recorded video file, please install Xvid codec while installing

Intelligent IP Installer. (For Windows 98, ME or 2000 server, the codec might not work

properly. Please download Xvid codec 1.0 from the internet.)

3. Please keep updating the latest Windows software and service package. (Ex: Net

Framework, Windows Media Player, Enhance ActiveX Security)

Minimum System Requirement

& Product Feature

F7110 / F7115 User Manual

2.2 Product Features

These easy-to-follow instructions make setup and operation quick and simple, so you’ll also soon

be enjoying the benefits of these PRODUCT FEATURES:

SYSTEM

Resolutions H.264 / MPEG-4 / Motion JPEG:

4 resolutions from 1280x1024 to 320x240 via API and

configuration web page

Screen Resolution Higher than 1024 * 720 pixels

Compressing format H.264 / MPEG-4 / Motion JPEG

Frame Rate Up to 15 fps at 1280x1024

Up to 30 fps at 640x480

Rotation: Mirror, Flip, Mirror Flip

Brightness / Contrast / Saturation

Image settings

Overlay capabilities: time, date, text and privacy image

Image snapshot Yes

Video Recording Yes

Full Screen Viewing Yes

Digital Zoom 10x digital

Two-way (full / half duplex) with built-in microphone

Audio Audio compression: G.711 μlaw, a law, and AMR

Instant Messenger Support MSN Live View

Mobile Phone Live

View Through 2.5 WAP

Alarm Sending FTP Client / SMTP / Network Storage / HTTP Event

Security Password Protection / HTTPS encryption / IP Filter

Alarm Buffer Recording image and audio file pre-and-post disconnection up

to 5 sec.

Supported protocols Bonjour, TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP,

DNS, NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA

RTSP

Simultaneous

Connection Up to 10 users

Operating conditions 0℃~ 50℃(32℉~ 122℉)

HARDWARE

Lens Changeable CS-mount lens (support Auto Iris)

Video Output RCA type with BNC adapter

Local Storage Support SD/SDHC card

I / O 2 alarm I/O and 1 RS-485

Audio Output 1

Alarm Input 2

Power 12V DC, 1A, Max 5W

NETWORK

Ethernet 10 / 100 Base T

Wireless IEEE 802.11b/g/n (for F7115)

Minimum System Requirement

& Product Feature

F7110 / F7115 User Manual

Chapter 3. Using IP Camera via Web Browser

3.1Windows Web Browser

1. Open your web browser, and enter the IP address or host name of the IP camera in the

Location / Address field of your browser.

Note : If you only want to view the video without accessing Setting screen, enter

“http://<IP>/index2.htm” as your web URL.

2. Use the default account “admin” and default password “admin”.

Note : The default user name “admin” and the password are set at the factory for the

administrator. You can change them in the Account Menu. (Please check “Setting →

Basic →Security →Account”)

3. The monitor image will be displayed in your browser. In the far left side of main

configuration are Setting, Client Setting, and Image Setup and PT control. For more details,

you can check Chapter 7.2、Chapter 7.3、Chapter 7.4 and Chapter 7.5.

Using IP Camera via

Web Browser

F7110 / F7115 User Manual

3.2 Mac Web Browser

1. Click the Safari icon, and enter the IP address of the IP camera in the Location / Address

field of your browser.

Note : If you only want to view the video without Setting screen

“http://<IP>/index2.htm” as your web URL.

2. Enter the default account “admin” and default password “admin”.

Note : The default user name “admin” and the password are set at the factory for the

administrator. You can change them in the Account Menu (Please check “Setting →

Basic →Security →Account”)

Using IP Camera via

Web Browser

F7110 / F7115 User Manual

3. The monitor image will be displayed in your browser. In the far left side of main

configuration are Setting, Client Setting, and Image Setup and PT control. For more details,

you can check Chapter 7.2、Chapter 7.3、Chapter 7.4 and Chapter 7.5.

Using IP Camera via

Web Browser

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Zavig Caméra de sécurité

Zavig

Zavig P5110 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
