ZANUSSI

P R O F E S S I O N A L

2 BURNERS GAS BOILING TOPS - cast iron grids

N 900

200100

Net weight - kg. 43 43

Total Power - kW 12 20

Front burners power - kW 6 10

Front burners dimension - mm Ø 60 Ø 100

Back burners power - kW 6 10

Back burner dimensions - mm Ø 60 Ø 100

height 250 250

depth 900 900

width 400 400

External dimensions - mm

Power supply Gas Gas

NCG400C

200150

NCG401C

200158

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION

N 900: a range of over 150 models

for the professional caterer designed

to guarantee the highest level of

performance, reliability, energy

saving, safety standards and

ergonomic operation. These

concepts are reflected in the total

modularity of the range that ensures

innumerable configurations, either

free-standing, bridged or cantilever.

N900 demonstrates how advanced

technology can satisfy the needs of

the professional caterer.

The models detailed on this sheet

are 2 burners gas boiling tops with

cast iron grids.

FUNCTIONAL AND

CONSTRUCTION

FEATURES

� Burners with optimized

combustion interchangeable on site,

flame failure device and protected

pilot light:

- 60 mm burners with continuous

power regulation from 1,5 to 6 kW

- 100 mm burners with continuous

power regulation from 2,2 to 10 kW

� Manual ignition of the top burners.

� Worktop in 20/10 stainless steel.

Front, side and rear panels in

stainless steel with Scotch Brite

finish.

� All models have right-angled side

edges to allow flush-fitting joins

between units, eliminating gaps and

possible dirt traps.

� Cast iron grids.

� All gas appliances are supplied for

use with natural gas, with LPG

conversion jets supplied as standard.

� The special design of the control

knob system guarantees against

water infiltration.

� All models can be easily mounted

on open base cupboards, bridging

supports or cantilever system.

� IPX5 water protection.

� Main connections can be via the

rear or the base of the unit.

BACB3 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

WATER COLUMN WITH SWIVEL ARM 206288 206288

WATER COLUMN EXTENSION FOR 900 LINE 206290 206290

SINGLE BURNER(6KW)RADIANT PLATE-900 LINE 206170 206170

SINGLE BURNER SMOOTH PLATE 206171 206171

SINGLE BURNER RIBBED PLATE 206172 206172

SIDE HANDRAIL-RIGHT/LEFT HAND 206165 206165

S/S GRID FOR DOUBLE BURNER-900 LINE 206298 206298

PRESSURE REGULATOR FOR GAS UNITS 927225 927225

PAIR OF COVERING STRIPS FOR END ELEMENTS 206234 206234

LARGE HANDRAIL(PORTIONING SHELF)800 MM 206186 206186

LARGE HANDRAIL(PORTIONING SHELF)400 MM 206185 206185

JUNCTION SEALING KIT 206086 206086

FRONTAL HANDRAIL 800 MM 206167 206167

FRONTAL HANDRAIL 400 MM 206166 206166

FRONTAL HANDRAIL 1600 MM 206192 206192

FRONTAL HANDRAIL 1200 MM 206191 206191

CHIMNEY UPSTAND 400MM 206303 206303

2 SIDE COVERING PANELS FOR TOP-D=900MM 206278 206278

NCG400C

200150

NCG401C

200158

ACCESSORIES MODELS

OPTIONAL ACCESSORIES

H - Gas connection 1/2" 1/2"

NCG400C

200150

NCG401C

200158

LEGEND

200150, 200158

56 688 / 1088 56

674 100126

52800748

1600

299

900

200

180 20 20 250

664236

56148856

50 I

176 724

900

1600 400/800/1200

356 / 756

400 / 800 / 1200

348/748/1148
