Safety information

Correct use

●This dishwasher is only intended for washing

household utensils suita le for machine

washing.

●Do not put any solvents in the dishwasher.

This could cause an explosion.

●Knives and other items with sharp points

must e loaded in the cutlery asket with

their points down or placed in a horizontal

position in the upper asket.

●Only use products (detergent, salt and rinse

aid) suita le for dishwashers.

●Avoid opening the door whilst the appliance

is in operation, hot steam may escape.

●Do not take any dishes out of the dishwasher

efore the end of the dishwashing cycle.

●After use, isolate the appliance from the

power supply and turn off the water supply.

●This product should e serviced only y an

authorised service engineer, and only

genuine spare parts should e used.

General safety

●Dishwasher detergents can cause chemical

urns to eyes, mouth and throat. Could

endanger life! Comply with the safety

instructions of the dishwasher detergent

manufacturer.

●The water in your dishwasher is not for

drinking. Detergent residues may still e

present in your machine.

●Ensure that the door of the dishwasher is

always closed when it is not eing loaded or

unloaded. In this way you will avoid any ody

tripping over the open door and hurting

themselves.

●Do not sit or stand on the open door.

Child safety

●This appliance is designed to e operated y

adults. Don’t allow children to use the

dishwasher unsupervised.

●Keep all packaging well away from children.

There is risk of suffocation.

●Keep all detergents in a safe place out of

children’s reach.

●Keep children well away from the dishwasher

when the door is open.

Installation

●Check your dishwasher for any transport

damage. Never connect a damaged

machine. If your dishwasher is damaged

contact your supplier.

●All packaging must e removed efore use.

●Any electrical and plum ing work required to

install this appliance must e carried out y

a qualified and competent person.

●For safety reasons it is dangerous to alter

the specifications or attempt to modify this

product in any way.

In the interest of your safety and to ensure the correct use, efore installing and first using the

appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary

mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly

familiar with its operation and safety features. Save these instructions and make sure that they

remain with the appliance if it is moved or sold, so that everyone using it through its life will e

properly informed on appliance use and safety.

156999 58/0en 17-03-2006 14:09 Pagina 3

●Never use the dishwasher if the electrical

supply ca le and water hoses are damaged;

or if the control panel, work top or plinth area

are damaged such that the inside of the

appliance is freely accessi le. Contact your

local Service Force centre, in order to avoid

hazard.

●All sides of the dishwasher must never e

drilled to prevent damage to hydraulic and

electric components.

WARNING!

For electrical and water connection carefully

follow the instructions given in specific

paragraphs.

Control panel and functions

Function and pro ramme selection uttons

Di ital display

On/Off utton

Delay start utton

Pro ramme in pro ress light

Salt and rinse aid lights

IMPORTANT!

Always remem er that when performing

operations such as:

- selecting a washing programme,

- setting the water softener,

the appliance MUST e in setting mode:

●Press On/Off utton, ALL programme

selection utton lights are illuminated =

appliance in settin mode.

●Press On/Off utton, ONLY a programme

utton light is illuminated = last performed

pro ramme still set.

In this case the programme has to e

cancelled (see instructions “Cancel a

washing programme in progress”).

156999 58/0en 17-03-2006 14:09 Pagina 4

Pro ramme selection

uttons

●Startin the washin pro ramme:

1. Press the On/Off utton.

2. Press the utton corresponding to the required programme, the

corresponding light remains illuminated while the other programme

lights turn off. In the digital display will appear, flashing, the running

time of the programme (in minutes).

3. The pro ramme in pro ress light illuminates.

4. After a out 3 seconds from the last pressure of a utton the

programme starts automatically. In the digital display the running time

of the programme is no longer flashing and the pro ramme in

pro ress light remains illuminated.

IMPORTANT!

Once the programme has started, if you want to change the selection made

you must cancel the washing programme in progress.

●Cancel the washin pro ramme in pro ress:

1. Press and hold simultaneously function uttons 2and 3until ALL

programme utton lights will illuminate.

2. Release function uttons 2and 3.

3. Switch off the machine y pressing the On/Off utton or select a new

washing programme (check that there is detergent in the detergent

dispenser.

Function uttons

In addition to the dishwashing programme selection, the following functions

can also e set with the help of these

uttons.

- the setting of the water softener,

- the cancelling of a programme in

progress.

IMPORTANT!

It is possi le to select a washing programme and the delay start also with the door slightly

opened. In this case the start of the programme or the countdown will occur after the closure of

the door. Until that moment it is possi le to modify the set made.

156999 58/0en 17-03-2006 14:09 Pagina 5

Pro ramme in

pro ress light

Illuminates when the washing programme has een set.

When the delay start has een set, this light turns off and will come on again

once the countdown has elapsed and the washing programme has started.

Salt refillin

light

Illuminates when special salt needs to e filled.

It can remain illuminated several hours after the salt has een filled.

Delay start

utton

This option allows the start of the programme to e delayed from 1 to 19

hours. Before selecting the washing programme, press the On/Off utton

and then press the delay start utton until the flashing num er of the hours

for the delay start will appear in the digital display.

Select a washing programme, in the digital display will appear for a

moment, the running time of the programme and then again appears the

selected delay start time.

As soon as the num er of hours is displayed without flashing, the

countdown for the delay start is active.

Once the countdown has elapsed the washing programme will start

automatically.

●Cancel the delay start in pro ress:

To cancel a delay start in progress you have to reset the dishwasher;

follow the same instructions given in “Cancel the washing programme in

progress”.

IMPORTANT!

Cancelling a delay start involves also the cancelling of the washing

programme set. In this case you have to select the washing programme

again.

Rinse aid

refillin light Illuminates when rinse aid needs to e filled.

156999 58/0en 17-03-2006 14:09 Pagina 6

Pro ramme Use Cycle description

Pro ramme table

Auto Normal / Light soil. Prewash - Main wash

65°50° Crockery and cutlery 1 or 2 intermediate rinses

Final rinse - Dry

Intensive Heavy soil. Prewash - Main wash

70° Crockery, cutlery, pots and pans 2 intermediate rinses - Final rinse

Dry

Rinse and Any. Prewash

Hold Partial load (to e completed later in the

day). This programme does not require the

use of detergent.

30 min. Light soil. Main wash - Final rinse

Crockery and cutlery

Eco Normal soil. Prewash - Main wash

50° Crockery and cutlery 1 intermediate rinse - Final rinse

Dry

"AUTO" washin pro ramme

During the "AUTO" washing programme the

amount of soil on the dishes is determined y

how cloudy the water is.

If the appliance is partially loaded and the

dishes lightly soiled, the "prewash", "main

wash", and "rinse" phases of the programme

are shorter and the water consumption level is

lower.

If the appliance is fully loaded and the dishes

heavily soiled, the "prewash", "main wash", and

"rinse" phases of the programme are longer

and the water consumption level is higher.

For this reason the programme duration, water

and energy consumption levels can vary within

the stated range for AUTO programme (see

"Washing programmes chart").

During the "AUTO" programme the

temperature of the main wash water is also

automatically adjusted etween 50°C and

65°C depending on the amount of soil on the

dishes.

156999 58/0en 17-03-2006 14:09 Pagina 7

Before the first use

When usin separate special

(dishwasher) salt, rinse aid and

deter ent:

- set the water softener

- add special (dishwasher) salt

- fill up with rinse aid

When usin tablets that inte rate

rinse aid and deter ent:

there is no need to fill up with rinse aid

- set the water softener

- add special (dishwasher) salt

When usin tablets that inte rate

rinse aid, deter ent, salt function

and other additives:

there is no need to fill up with special salt or

rinse aid.

Check whether these detergents are suita le

for your water hardness. Follow the

manufacturers instructions.

- Set the water hardness to level 1.

IMPORTANT!

If the drying results are not satisfactory we

recommend that you:

1. Fill up the rinse aid dispenser with rinse aid.

2. Set the rinse aid dosage to position 2.

If you decide in future to use separated

detergents, we advise that you:

- Fill up the salt and rinse aid container.

- Adjust the water hardness setting to the

highest level and perform 1 normal washing

programme without loading any dishes.

- Adjust the water hardness setting according

to the hardness of the water in your area.

- Adjust the rinse aid dosage

Settin the water softener

The dishwasher is equipped with a water

softener designed to remove minerals and salts

from the water supply, which would have a

detrimental or adverse effect on the operation

of the appliance.

The softener should e adjusted according to

the hardness of the water in your area. Your

local Water Authority can advise you on the

hardness of the water in your area.

IMPORTANT!

The water softener must e set in oth ways:

manually and electronically.

156999 58/0en 17-03-2006 14:09 Pagina 8

1) Clarke degree, measure of the water hardness.

2) (°TH) French degree, measure of the water hardness.

3) (mmol/l) millimol per litre, international unit for water hardness

The water softener is factory set at position 2.

Settin the water softener manually (see table)

Set switch to position 1

or 2

64 - 88 91 - 125 9,0 - 12,5 2 level 10

53 - 63 76 - 90 7,6 - 8,9 2 level 9

46 - 52 65 - 75 6,5 - 7,5 2 level 8

36 - 45 51 - 64 5,1 - 6,4 2 level 7

28 - 35 40 - 50 4,0 - 5,0 2 level 6

18 - 22 26 - 32 2,6 - 3,2 1 level 4

5 - 12 7 - 18 0,7 - 1,8 1 level 2

23 - 27 33 - 39 3,3 - 3,9 2 level 5

13 - 17 19 - 25 1,9 - 2,5 1 level 3

< 5 < 7 < 0,7 1 level 1

no salt necessary

Water hardness Level indicated on Adjustment of the

the di ital display water hardness settin

Clarke1) in °TH2) in mmol/l3) manually electronically

factory

setting

156999 58/0en 17-03-2006 14:09 Pagina 9

Settin the water softener electronically (see table)

The dishwasher must

e switched off.

Switch on the

dishwasher y pressing

the On/Off utton.

The digital display

indicates the current

level.

To change the level,

press function utton 1.

Each time the utton is

pressed the level

increases. (For the

selection of the new

level see the chart).

The digital display

indicates the new level

set. (Level 1 follows

level 10).

To memorise the

operation, switch off the

dishwasher y pressing

the On/Off utton.

Press and hold

simultaneously function

uttons 2and 3until the

lights of function

uttons 1, 2and 3start

flashing.

Release the uttons

and then press function

utton 1; the lights of

function uttons 2and 3

turn off while function

utton 1goes on

flashing.

The water softener is factory set at position 5.

156999 58/0en 17-03-2006 14:09 Pagina 10

Autres manuels pour ZDF 501

Table des matières

Autres manuels Zanussi Electrolux Lave-vaisselle

Zanussi Electrolux

Zanussi Electrolux ZSF 2400 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DEF201 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE6344 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE 4855 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE 6955 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZSF 4112 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZSF 6280 Manuel d'utilisation

Zanussi Electrolux

Zanussi Electrolux ZSF 6150 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DX 6453 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE 6554 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE 6865 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DCS 12 W Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE 6954 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZDF 121 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZSF 6126 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZSF 4143 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZSF 4111 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DX 6451 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DE 540 X Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZSF 6161 S Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZDT 6053 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZDF 501 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZDF 121 Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux DA4143 Manuel utilisateur

Manuels Lave-vaisselle populaires d'autres marques

Electrolux

Electrolux ESI5211LOX Manuel utilisateur

KitchenAid

KitchenAid KUDB230B Manuel utilisateur

Brandt

Brandt BDJ424DB Manuel utilisateur

Asko

Asko DSD767UXXL.AU Manuel utilisateur

Beko

Beko DFN26210W Manuel utilisateur

NEFF

NEFF S153ITX00E Fiche technique

Midea

Midea SV 4.45 wi Manuel utilisateur

LG LDF7932 Manuel utilisateur

Gorenje

Gorenje GV63214 Manuel utilisateur

Hotpoint

Hotpoint HDA1100ZWH Manuel de service

Blomberg

Blomberg LDFN2240W Manuel utilisateur

AEG

AEG FFB83836PM Manuel utilisateur

Cylinda

Cylinda DM3220RFD Manuel utilisateur

Atag

Atag DW8214MB Manuel utilisateur

GE GLD8000 Series Manuel utilisateur

Siemens

Siemens SN23HI02KE Fiche technique

Omega

Omega ODW717X Manuel utilisateur

BORETTI

BORETTI BVW-683 Manuel utilisateur
