YURAKU YM782D Manuel utilisateur

Safety precautions and maintenance

1 Unplug themoniter before cleaning clean with a slightly damp cloth.

wiping the screen with a dry cloth is okay when the power is off .

however never use alcohol or ammonia-based liquids.

2 There are cooler hole design on the cabinet back, please do not cover or

wall it up, also do not lay the monitor near the electric heater or heater,

including not airiness setting place.

3 Please do not insert any matter or spray any liquid on it.

4 Please do not lay it on the unsafe space, if it falls down, it may be

shatter strictness, or it may hurt the user.

5 Unplug the monitor if you are not going to use it for an extended period of

time.

6 Please do not put heavy on the monitor, electric cord or upper power.

7 Please do not open the monitor back cover voluntarily because the

monitor is including high voltage part.

Catalogue

Security matter 1

Basic instruction 2

Setup guide 3

Adjustment setting 4

Trouble shooting 8

Specification 10

Basic instruction

Equipment subassembly

Please check your monitor equipment subassembly including the

followings:

A piece of monitor and a piece of signal cord

Aset of warranty card and eligibility certificate.

Aset of user instruction.

FUNCTION

TFT-LCD MONITOR HAS THE FOLLOWING CHARACTERS:

No radiation, protect your health.

Save space

TFT-LCD monitor is more thickness, it can save more space

on the desk.

Save more power.

The product maximum power consuming is only 35w.

Smart model image screen setting

View window of smart model controls the interface to make

easy setting and offering high-tech enjoyment.

High quality image

This product best working model:1280 1024@75Hz

A piece of power cord.

Apiece of audio cord.(just for monitor with audio)

Warring

If the monitor has DVI function please turning off the monitor

first when you want to exchange the DVI signal cord.

Apiece of DVI signal cord(just for monitor with DVI)

16.2M high quality image color

this product specially emphasizes view effect, to provide perfect

image resolution

Auto function

When no menu please press Exit function key ,it automatically

adjust the signal to the best statement setting.

Setup guide

1 To inert the signal cord to the back side of PC signal tie in.

2 The monitor have wider power voltage range, it can be used in

AC 100-240 50/60Hz area.

3 To switch on the PC and press monitor power on/off key.

Power indicator light

Blue (green)light expresses power on

Blue (green)light expresses the signal is under normal working model

Blue (green)flash express the signal not input statement

Screen image adjustment

To through five keys of control panel to adjust the monitor setting

by view of control interface

The key of control broad

Menu /Enter: Shows main choice menus

To adjust the option column down or lower

Power ON/OFF key

To adjust the option column up or higher,

EXIT: Exit main menu ,when no menus,auto adjust image..

Adjustment setting

1Press menu into main function choice menu

into this menu.

2 Press Exit to return back main menu

2 Press o switch the image of main function changing setting.or t

3 Press menu to switch to submenu changing setting ,To press or

1 Press to adjust the settingor

Main choice menu with VGA

A: PC main menu item including:

1 Color adjust

2 Image adjust

3 Color Temp.t

4 OSD Tools

5 Language

6 MISC.

All kinds of functions particular instruction

1Color adjustment

3.1. Color temperature adjustment

To press menu into choice men

-us ,press to this choice ,

and then press menu into color

temperature to choose the standard warm or cool to adjust the image

to obtain the best display .

2 Image adjustment

2.1 Horizontal position adjustment

To press menu into main choice

menus, press menu into Horizon

-tal position adjustment and then press to adjust the Horizontal

position image display.

2.2 Vertical position adjustment

To press menu into main choice menus, press menu into Vertical

position adjustment, and then press to adjust the Vertical

posit ion image display.

2.3 Phase adjustment

To press menu into main choice menus, press menu into phase

adjustment, and then press to start pixel sampling by phor

-ase improving stabilization.

2.4 Colck adjustment

To press menu into main choice menus, press menu into Frequ

-ency adjustment, and then press to adjust colck imageor

display to track stability.

3.2.User Defined

To press menu into choice menus ,press menu into color adjustment ,

and then press into color temprature menu ,press menu into the

color adjustment of red green blue.

1.2. Contrast adjustment

To press menu into main choice menus ,press Menu into contrast

adjustment ,and then, press to adjust the image to obtain theor

best display

1.1.Brightness adjustment

To press menu into main choice

menus ,press Menu into brightn

-ess adjustment ,and then, press

to adjust the image brightness to fit the environmentor

1280X1024@75Hz

COLOR

MISC

COLOR TEMP.

LANGUAGE


OSD

3 Color temp.

4.1 OSD H-position adjustment

To press menu into main choice

menus, press menu into OSD H-

position adjustment to adjust the

H-position image display.

4 OSD Tools adjustment

1280X1024@75Hz

BRIGHTNESS

CONTRAST

0100

1280X1024@75Hz

WARM

COOL

USER DEFINED

1280X1024@75Hz

1000

1280X1024@75Hz

PHASE

CLOCK

100

HORIZONTAL POSITION

VERTICAL POSITION 100

100

No function when the signal

is DVI

To press menu into main choice menus, press menu into this choice

to get back to factory setting.

To press menu into main choice menus, press menu into this choice

and then press to adjust volume. just for monitor with audio)or

Trouble shooting

No image on screen

1 Check the power button is switched on.

2. Verify brightness and contrast setting of the moniter.

3. Check TFT-LCD monitor is under non-input signal or not, if

under non-input signal, the power indicator light will flash.

4. if signal indicator is note book, please make sure that the signal

has been switched to out connect screen model or not

Non-focus image

1 To check the image signal cord is inserted right position or not.

Flash screen

1 The power is not enough, to connect the monitor to other plug.

2 To get rid of matter to make magnetic field around the monitor,

such as radion , not cover speaker, fluorescence light, ac trans

-former ,table fans etc.

3 Press Exit key, auto adjust image to improve image quality .

This product has six or ten language

Deutsch

English

Spanish Italian

French

6 MISC.

To press menu into main choice

menus, press menu into auto ad-

justment to adjust to best display.

To press menu into main choice menus, press menu into auto

adjustment to adjust color to best display.

6.1 Auto Configuration

6.2 Auto Color

6.3 Factory Reset

6.4 Volume

5 Language

5.1 OSD choice language setting

To press menu into main choice menus, press menu into OSD

choice language setting, and then press to select menuor

language.

4.2 OSD V-position adjustment

To press menu into main choice menus, press menu into OSD

V-position adjustment to adjust the V-position image display.

1280X1024@75Hz

FACTORY RESET

VOLUME

AUTO CONFIGURATION

AUTO COLOR

77 0

MORE : Russian Poland Korean

(Please consult the real model in order of the language)

(No function,when the signal is DVI)

Wrong or unusual color

1 If red, green, blue, anyone of color disappear, shall check the

view cord is connected all right or not .If the pin inside the plug

of electric cord is loose, it will occur bad connection.

2 To connect the monitor to another PC to try

The whole screen appear up and down H-rolling scan

1 To make sure the view of input signal is within the order(60-75

Hz)of the monitor

2 To connect the view cord close

How to clean the monitor

1 To make sure the monitor switch off.

2 To not spray any liquid on the screen or plastic PC directly.

When clean the screen

1 Please use clean, soft and no fur cloth to clean the screen.

2 If it is still dirty, please add a little of non-ammonia liquid and

non-alcohol glass cleanser to clean the screen

When clean the cabinet

1 To use soft dry cloth

2 To add a little of non-ammonia liquid and non-alcohol of non

-abrasion cleanser to clean surface if it is still unclean.

Specification form

Brightness 250cd/m

Color 16.2M

Viewing angle H:L80-R80 V:Up80-Down80

Resolution 1280 1024

H-frequency 30~80KHz

Power input AC100V-240V

Power 35W

910

This product best working mode:1280 1024@75Hz

Operation Temp 0 C -40 C

Humidity 20% - 80%

Storage Temp -20 C -60 C

Humidity 10% - 90%

Environment

55 76Hz

V-frequency

NOTES:

1 The notes included are for indication only. Pls. refer to final products.

2. New narration will not be showed in the manual if the product changes

are based on quality improvement.
