Yuasa MDX-617 Manuel utilisateur
For 6 & 12-volt automotive
starting batteries
YUASA
MDX-617
Battery
Conductance
Analyzer
INSTRUCTION MANUAL
Blank page
•3•
Contents
Safety Guidelines 5
Capabilities 5
Registering Your MDX-Series Tester 6
Display and Keypad 6
User Interface 7
UP and DOWN Arrows 7
ENTER Button 7
BACK/PRINT Button 7
MENU Button 7
Options Menu 8
Procedure 8
Preparations Before the Test 9
Connecting the Tester 9
Battery Test 10
YUASA Warranty Test Results 12
Battery Test Results 12
New Battery Test Results 12
Test Messages 13
Error Messages 14
Maintenance & Troubleshooting 15
Changing The Cable Assembly 15
Changing The Printer Paper 16
Printer Troubleshooting 17
Troubleshooting the Display 17
Replacing the Battery 18
www.midtronics.com
•4•www.midtronics.com
•5•
!
Safety Guidelines
Because of the possibility of personal injury, always use extreme caution when
working with batteries.
Battery posts, terminals, and related accessories contain lead and lead
compounds. Wash hands after handling.
Capabilities
The tester tests 6 & 12-volt regular ooded, AGM at plate, AGM spiral, and GEL
batteries. It displays the test results in seconds and features a built-in printer to
provide customers with a copy of the results.
Additional features include the ability to:
• testtheStartingandChargingsystem
• testbatteriesfromratedfrom100to2000CCA
• detectbadcells
• protectagainstreversepolarity
• testdischargedbatteries
• testmultipleratingsystems
• provideamulti-lingualuserinterface
www.midtronics.com
•6•
Registering Your MDX-Series Tester
Before using your tester, we recommend that you register it online to activate
your warranty. Registration will also make it faster and easier for you to obtain
technical support and service.
To register, log on at www.midtronics.com/warranty.html and have your serial
number ready. The number is at the bottom of the label on the back of the
tester.
Display and Keypad
When you rst connect the tester to a battery, it functions as a voltmeter until
you press the ENTER button.
IMPORTANT:Ifyouconnectthetestertoavoltagesourcegreaterthan30Vdc,
you may damage the tester’s circuitry.
The menu-driven display will then guide you step by step through the test
process. Use the keypad buttons to scroll to and select options in the menu.
To turn o the tester when not connected to the battery, briey press and hold
the MENU button.
Serial Number Label
Serial
number
www.midtronics.com
•7•
User Interface
1 UP and DOWN Arrows
Use these keys to choose test
parameters and scroll to menu
options.
2 ENTER Button
Use this button to make
selections.
3. BACK/PRINT Button
Use this button to move to
the previous screen or move
back one space when creating
custom headers. You can also
use this button to printout test
results using the built-in printer.
4 MENU Button
Use the MENU button to
access the Main Menu options
of the tester.
For information about the
options, see “Options Menu”.
www.midtronics.com
1
2
Display Showing
Battery Result
3
4
IR Output
Decision
Measured rating
Measured voltage
Selected rating
Printer
Button
Toolbar
•8•
Option Explanation
View/Print Display the previous test result. Press the PRINT
button to print the results.
QC Mode A quick test to check battery inventory
Export Data Export the last test result to an IR Reader program.
Perform Test Begin the Battery Test procedure.
Language Selection Select a language for the tester.
Set Address Enter the address to display on the top of the printout.
(Limit: 8 lines, 21 characters per line)
Time Select 24-hour or AM/PM and set the time.
Date Select the date format as well as set the correct date.
Counter Clear or display battery and system test by results.
Contrast Adjust the contrast setting of the tester display.
Temperature Units Select the temperature units
Degrees F or Degrees C
Voltmeter Automatically test battery voltage when the clamps are
rst connected to the battery terminals. Press ENTER
to continue testing the battery. Press BACK to return to
the menu. (Default: ON)
Options Menu
Procedure
1. Press the MENU button to access the Options Menu.
2.
Use the UP (p) and DOWN (q) arrows to move to the line you want to
edit.
3. Press the ENTER button to make highlighted line editable.
4. Use the UP (p) and DOWN (q) arrows to select the character for that cur-
sor location.
5. Press the ENTER button to move to the next location.
6. Press the MENU button to return to the Options Menu.
www.midtronics.com
•9•
Preparations Before the Test
Before connecting the tester, clean the battery posts with a wire brush and a
mixture of baking soda and water. When testing side-post batteries, install and
tighten lead terminal adapters.
IMPORTANT: Do not test at steel bolts. Failure to install terminal adapters or
installing terminal adapters that are worn or dirty may result in inac-
curate test results. To avoid damage, never use a wrench to tighten the
adapters more than 1/4 turn.
If you are testing in the vehicle, make sure all accessory loads are o, the key is
not in the ignition, and the doors are closed.
Connecting the Tester
• Connecttheredclamptothepositive(+)terminalandtheblackclampto
the negative (–) terminal.
• For a proper connection, rock the clamps back and forth.The tester re-
quires that both sides of each clamp be rmly connected before testing. A
poorconnectionwillproduceaCHECKCONNECTIONorWIGGLECLAMPS
message. If the message appears, clean the terminals and reconnect the
clamps.
• Thepreferredtestpostionisatthebatteryterminals.Ifthebatteryisnot
accessible, you may test at the jumper post; however, the available power
measurement may be lower than the actual value.
www.midtronics.com
•10 •
Battery Test
When you rst connect the tester to the battery, it functions as a voltmeter
until you press the ENTER button to start the test. This function can be turned
o through the Options Menu
After you press ENTER, scroll to each parameter using the UP or DOWN
ARROW button and press ENTER to select. If any messages appear during the
test, see “Test Messages”
1. TESTTYPE:choosewhichtestneedstobeperformed:
-YUASAwarrantytest
- Battery test
- New battery test
2.
YUASA WARRANTY:
The Yuasa warranty test needs to be used whenever you want to send
in a Yuasa battery for warranty purposes. When the test outcome is
“Charge & Retest” the battery needs to be charged with an approved
Yuasa charger.
BAT. LOCATION:
Scroll to and select IN VEHICLE or OUT OF VEHI-
CLE for a battery not connected to a vehicle. Following an IN VEHICLE
test you will be prompted to test the starting and charging systems.
IMPORTANT: The performance of the starting and charging systems depends
on the battery’s condition. It is important that the battery is good and
fully charged before any further system testing.
BAT. AGE: Select
new battery
or
in service
:
New battery: battery is fresh produced and not yet installed in a ve-
hicle. For instance: the battery is in a warehouse waiting for delivery
to a customer.
In service: the battery is already used and cycled in the vehicle
3. APPLICATION:scrolltoandselectAUTOMOTIVE,MOTORCYCLE,TRUCK.
4. BATTERYTYPE: scroll to and select REGULAR FLOODED, AGM FLAT PLATE,
AGMSPIRAL,orGEL where applicable.
www.midtronics.com
