YORKVILLE YX150 Manuel utilisateur

➲400 Watts

➲15-inch Ceramic Woofer

➲1-inch Neodymium Compression Driver

➲2-inch Mylar Diaphragm Horn Driver (1-inch exit)

➲Designed as Front-of-house or Monitor Loudspeaker

➲Innovative Dual-bulb CTL™ High Frequency Protection

➲90° x 40° Custom ABS Waveguide Horn

➲Solid Plywood Cabinet Construction

➲Speakon™ & 1/4-inch Inputs

➲All-Metal Grille, Integrated Bar Handles

& Stand Mount

➲122dB Maximum SPL

Designed for any PA application where higher power and maximum clarity is required,

the passive 400-watt YX150 uses a single 15-inch woofer and 1-inch Neodymium

compression driver with a 2-inch Mylar diaphragm mounted on a custom 90º x 40º ABS

horn to deliver a full 50Hz to 20kHz frequency response with unmatched linearity.

Yorkville’s tried and true dual-bulb CTL™ protection system protects the horn driver’s

Mylar diaphragm ensuring unmatched reliability in the field. The YX150 is built

road-ready with easy-to-clean, durable black carpet covering, solid internal plywood

bracing and reinforced internal component mounts.

Designed with working musicians in mind, the YX150 offers rugged 5/8-inch plywood

cabinet construction, all metal bar handles, metal input plate, integrated speaker mounts

and a custom punched, perforated metal grille to protect the speaker components. Two

Speakon™ and two 1/4-inch parallel inputs are provided ensuring maximum

connectivity in virtually any PA application.

YX Series Specifications:

YX150

15-inch Passive Front-of-house or

Monitor Loudspeaker

YX150

Features:

Overview:

yorkville.com

MODEL YX150

SYSTEM TYPE 2-Way

ACTIVE OR PASSIVE Passive

PROGRAM POWER (Watts) 400

BIAMPABLE No

NOMINAL IMPEDANCE (Ohms) 8

SENSITIVITY (dB @1Watt/1m) 98

MAX SPL (dB) 122

FREQUENCY RESPONSE (Hz +/- 3db) 50 - 20k

CROSSOVER FREQUENCY (Hz) 1200

DRIVER CONFIGURATION 15 inch / 2 inch

HF DRIVER(S) 1 inch Neodymium

HF DIAPHRAGM 2 inch Mylar (1 inch throat)

HF HORN Injection Molded ABS

HF DISPERSION (°H X °V) 90 x 40

HF PROTECTION CTL™ Dual Bulb

LF DRIVER(S) 15 inch Ceramic

LF PROGRAM POWER(Watts) 400

INPUTS - 1/4" JACKS 2

INPUTS - SPEAKON 4-PIN 2

CORNERS Metal

FEET Plastic Glides

BAR HANDLES 2 (Sides)

POLE MOUNT ADAPTER (1 3/8"-3.5cm) Yes

ENCLOSURE MATERIALS 15mm (5/8inch) Plywood

GRILLE Custom Punched Black Perforated Metal

COVERING / FINISH Black Ozite

DIMENSIONS (DWH xbackW, inches) 15.9 x 20.3 x 28.9 x 7.5

DIMENSIONS (DWH xbackW, cm) 40 x 51 x 73 x 19

WEIGHT (lbs/kg) 52 / 23.6

Specifications subject to change without notice.
