YORKVILLE COLISEUM C170 Manuel utilisateur

➲ 100 Watt Mini Series Speaker

➲ 90° x 90° HF Driver

➲ 8-inch Woofer with 1-inch Mylar Dome Tweeter

➲ Cabinet is Available In Either a White (C170W) or

Black (C170) Finish

➲ Integrated 70-Volt 'Matching Transformer'

➲60 to 20,000 Hz Frequency Response

➲1 x 1/4-inch / Dual Binding Post Inputs

➲Injection Molded, ABS Plastic Cabinet Construction

➲Two-year Unconditional Warranty*

*Warrany valid in Canada and the United States only

The integrated 70V 'matching transformer' allows multiple C170's to be connected

together without danger of overloading the power amplifier due to impedance drop. The

user has a choice of three sensitivity settings (6W, 12.5W, 25W or bypass) selected via a

rotary switch located on the rear panel of the speaker, allowing convenient adjustment of

the relative volumes of multiple interconnected cabinets.

The C170 is based on the already popular C110, C120 and C130, which have a complete list

of features that make them an extremely good value for fixed installations. The C170, is a

compact 100-watt loudspeaker made from an ABS plastic enclosure with an 8-inch driver

and 1 inch Mylar tweeter, and features both dual binding posts and 1/4" connectors for

maximum versatility.

The trapezoidal shape makes the C170 ideal for install or array mounting in tight locations.

Shipped with a rugged U-bracket for wall or ceiling mounting, they are a very versatile and

cost-effective solution where superior sonic quality is required for small installations, or as

a repeater or fill cabinet in larger venues. An optional polemount adapter (C170ADAPT) is

also available for applications where placing the C170 on a speaker stand is required. The

C170 is also available in white as the C170W, for situations where a more discreet

speaker is required.

Coliseum C170

Features:

Overview:

yorkville.com

8-inch Mini Series Speaker

C170 Specifications:

Model

SYSTEM TYPE

ACTIVE OR PASSIVE

IMPEDANCE

SENSITIVITY (dB @ 1W / 1M)

PROGRAM POWER (watts)

MAXIMUM SPL (dB)

FREQ. RESPONSE (Hz +/- 3dB)

DRIVER CONFIGURATION

HF DRIVER(S)

LF DRIVER(S)

TOTAL POWER (watts)

COOLING SCHEME

POWER CABLE

POWER SWITCH

INPUTS

INPUTS - 1/4” Jacks

MIXER CONTROLS

OTHER CONTROLS / FEATURES

FEET

INCLUDED HARDWARE

OPTIONAL HARDWARE

ENCLOSURE MATERIALS

OPTIONAL FINISH

GRILLE

DIMENSIONS (DxWxH inches)

DIMENSIONS (DxWxH cm)

WEIGHT (lbs/kg)

C170 / C170W

2-Way

Passive

100

113

60 - 20000

8" / 1" dome tweeter

1" Mylar Dome Tweeter

100

1 x Binding Post

1 x TRS

Yes

Mounting Bracket

Pole Mount Adaptor (1 3/8"-3.5cm)

(C170ADAPT)

ABS Plastic

White (C170W)

Perforated Metal

11 x 9 x 16

28 x 23 x 41

14.5 / 6.6
