TECHNICAL GUIDE

SINGLE PIECE VARIABLE SPEED ECM

COMMUNICATING AIR HANDLERS

FOR USE WITH SPLIT-SYSTEM

COOLING & HEAT PUMPS

MODELS: AVC SERIES

Due to continuous product improvement,

specifications are subject to change without notice.

Visit us on the web at:

www.upgnet.com and www.york.com

dditional rating information can be found at:

www.ahridirectory.org

WARRANTY SUMMARY

Standard 5-year limited parts warranty.

Extended 10-year limited parts warranty when product is

registered online within 90 days of purchase for replacement

or closing for new home construction.

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

5151060-YTG-F-1116

DESCRIPTION

This fan coil line offers the ultimate in application flexibility. This

unit may be used for upflow, downflow, horizontal right, or

horizontal left applications.

All JCI Unitary Products air handlers and coils can use a TXV to

provide our customers with the optimum performance and

refrigerant control. Single piece air handlers are available with

“Flex-coils” (without a factory installed metering device). For

added flexibility, an R-22 or R-410A TXV or piston must be field

installed to meet the requirement of the desired refrigerant.

Some coil models available with factory installed TXV.

FEATURES

RC2-Rigid Case Construction interior endoskeleton for

structural support, smooth side, and locks in insulation.

Powder-painted -G30 galvanized steel case provide a coated

edge that resists corrosion and rust creep.

MaxAlloyTM Coil - Long life aluminum coils built to deliver

lasting performance, efficiency and reliability.

Quality Construction - Structural components are made of

Aluminum or G90 galvanized steel to prevent corrosion.

Improved Insulation Design - Single piece with no external

screws to reduce thermal transmission paths to prevent

sweating. Foil faced insulation for ease of cleaning.

Thermostatic Expansion Valve - The accessory chatleff style

TXV provides easy installation to convert the indoor coil to the

required refrigerant that does not require brazing to replace or

install. Some models are available with factory installed TXV.

Case Depth -These models have 20.5” casing which provide

ease of attic access and tight applications.

Thermoset Drain Pan - Low retention and positive slope for

drainage to reduce potential mold or contaminants.

Factory Sealed - Achieves 2% or less total airflow leakage rate

at duct leakage test conditions in positive and negative

pressure for system airflow verification.

Enhanced Filter Rack -All models have integrated internal

filter racks provided for use with 1” thick standard size filters.

Electric Heat Kits -6HK series of field installed electric heat

kits are available for installation-friendly and easy service

applications.

Blowers - All models use direct-drive, variable speed ECM

motors.

2 Johnson Controls Unitary Products

5151060-YTG-F-1116

LIST OF SECTIONS

DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

DIMENSIONS & DUCT CONNECTION DIMENSIONS . . . . . . . . . . . 3

DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

COIL TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

COOLING CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PHYSICAL & ELECTRICAL DATA - COOLING ONLY . . . . . . . . . . 5

APPLICATION FACTORS - RATED CFM VS. ACTUAL CFM . . . . . 5

ELECTRICAL DATA - COOLING ONLY . . . . . . . . . . . . . . . . . . . . . . 5

ELECTRICAL HEAT - MINIMUM FAN SPEED . . . . . . . . . . . . . . . . . 6

ELECTRIC HEAT PERFORMANCE DATA:

208/230-1-60 & 208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

ELECTRICAL DATA FOR SINGLE SOURCE

POWER SUPPLY: 208/230-1-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

ELECTRICAL DATA FOR MULTI-SOURCE

POWER SUPPLY: 208/230-1-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

ELECTRICAL DATA FOR SINGLE SOURCE

POWER SUPPLY: 208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

ELECTRICAL DATA FOR MULTI-SOURCE

POWER SUPPLY: 208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

POWER WIRING - LINE CONNECTIONS . . . . . . . . . . . . . . . . . . . 11

ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

COMBUSTIBLE FLOOR BASE ACCESSORY . . . . . . . . . . . . . . . . 12

LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

TYPICAL APPLICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

TYPICAL THERMOSTAT CONNECTION . . . . . . . . . . . . . . . . . . . . 13

AIR FLOW DATA (CFM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

NOMENCLATURE

PRODUCT TYPE AA= Single Piece Air Handler

POSITION

MOTOR TYPE V

P= Multi PSC

E= Multi Std ECM

V= Multi VS ECM

Z= Compact Up Std ECM

OPTIONS CC= Communications Ready

-= Standard (No Options)

NOMINAL

UNIT CAPACITY 36

18 = 1.5 Ton 42 = 3.5 Ton

24 = 2 Ton 48 = 4-Ton

30 = 2.5 Ton 60 = 5-Ton

36 = 3 Ton

CABINET WIDTH B

A= 14.5"

B= 17.5"

C= 21.0"

D= 24.5"

TXV INDICATOR XBA-BF = Valve Size

X= no valve

VOLTAGE

(Voltage-Phase-Hertz) 21= 115-1-60 3= 208/230-3-60

2= 208/230-1-60 4= 460-3-60

GENERATION

(MAJOR REVISION) 11= 1st Gen

2= 2nd Gen

etc.

STYLE LETTER

(MINOR REVISION)

NOT USED FOR

ORDERING AA= Style A

B= Style B

etc.

Johnson Controls Unitary Products 3

5151060-YTG-F-1116

DIMENSIONS & DUCT CONNECTION DIMENSIONS

1-1/2”

7-11/32”

FILTER ACCESS

DRAIN CONNECTIONS

REFRIGERANT CONNECTIONS

BLOWER

COMPARTMENT 12-3/16”E

BOTTOM INLET

DIMENSIONS

TOP OUTLET

DIMENSIONS

SERVICE

DISCONNECT

PANEL

A0329-001

B20-1/2”

21-7/16”

COIL

COMPARTMENT

18-5/8” D

DIMENSIONS

Models

Dimensions1Wiring Knockouts2Refrigerant

Connections

Line Size

CDE FG

Height Width Power Control Liquid Vapor

AVC18BX21 41 17-1/2 12-7/8 14-1/4 16-1/2

7/8” (1/2”)

1-3/8”(1")

1-23/32” (1-1/4”) 7/8” (1/2”) 3/8”

3/4”

AVC24BX21 41 17-1/2 12-7/8 14-1/4 16-1/2

AVC30BX21 47-1/2 17-1/2 19-1/2 14-1/4 16-1/2

AVC36BX21 47-1/2 17-1/2 19-1/2 14-1/4 16-1/2

AVC36CX21 51-1/2 21 22-5/8 17-3/4 20

AVC42CX21 51-1/2 21 22-5/8 17-3/4 20

7/8”

AVC48CX21 51-1/2 21 22-5/8 17-3/4 20

AVC48DX21 55-1/2 24-1/2 26-5/8 21-1/4 23-1/2

AVC60CX21 55-3/4 21 26-7/8 17-3/4 20

AVC60DX21 55-1/2 24-1/2 26-5/8 21-1/4 23-1/2

1. All dimensions are in inches.

2. Actual size (Conduit size in parenthesis.).

COIL TECHNICAL DATA

Models Application Refrig.

Conn. Types Face Area

(Sq. Ft.) Rows

Deep Fins

Per In. Coil Size Tube

Geometry Tube

Diameter Fin

Type

18B Cooling /Heat Pump Sweat 4.3 2 14 (3) 12 x 17.1 1 x 0.866 3/8 Sine Wave

24B Cooling /Heat Pump Sweat 5.0 2 14 (3) 14 x 17.1 1 x 0.866 3/8 Sine Wave

30B Cooling /Heat Pump Sweat 6.4 2 14 (3) 18 x 17.1 1 x 0.866 3/8 Sine Wave

36B Cooling /Heat Pump Sweat 7.1 2 14 (3) 20 x 17.1 1 x 0.866 3/8 Sine Wave

36C Cooling /Heat Pump Sweat 7.1 2 14 (3) 20 x 17.1 1 x 0.866 3/8 Sine Wave

42C Cooling /Heat Pump Sweat 8.6 2 14 (3) 24 x 17.1 1 x 0.866 3/8 Sine Wave

48C Cooling /Heat Pump Sweat 8.6 2 14 (3) 24 x 17.1 1 x 0.866 3/8 Sine Wave

48D Cooling /Heat Pump Sweat 8.6 2 14 (3) 24 x 17.1 1 x 0.866 3/8 Sine Wave

60C Cooling /Heat Pump Sweat 10.0 2 14 (3) 28 x 17.1 1 x 0.866 3/8 Sine Wave

60D Cooling /Heat Pump Sweat 10.0 3 12 (3) 28 x 17.1 1 x 0.866 3/8 Sine Wave

4 Johnson Controls Unitary Products

5151060-YTG-F-1116

COOLING CAPACITY1

Models Rated CFM2Entering Air

Dry/Wet Bulb (°F) MBH@ Evap. Temp. and Corresponding R-410A Pressure (°F/PSIG)

35/107.9 40/118.9 45/130.7 50/143.3

18B 600

85/72 45.7 41.6 36.8 30.5

80/67 38.5 33.9 28.5 22.3

75/62 31.5 26.5 20.5 15.9

70/57 24.4 19.5 15.2 11.5

24B 800

85/72 52.2 47.5 41.8 35.0

80/67 43.6 38.3 31.9 24.5

75/62 35.2 29.5 22.7 16.2

70/57 27.1 20.7 15.5 11.4

30B 1000

85/72 75.3 67.8 56.8 47.1

80/67 62.6 54.6 44.2 34.5

75/62 50.2 41.3 32.0 22.9

70/57 37.8 30.1 21.5 16.2

36B 1200

85/72 91.6 82.4 71.3 59.4

80/67 76.5 65.4 54.6 42.8

75/62 61.3 51.2 40.0 30.5

70/57 47.5 38.1 28.7 22.3

36C 1200

85/72 91.6 82.4 71.3 59.4

80/67 76.5 65.4 54.6 42.8

75/62 61.3 51.2 40.0 30.5

70/57 47.5 38.1 28.7 22.3

42C 1400

85/72 108.0 98.4 88.1 73.8

80/67 93.3 82.1 69.7 57.0

75/62 75.9 64.4 53.1 41.9

70/57 60.7 49.9 39.4 32.4

48C 1600

85/72 115.2 105.0 93.9 79.0

80/67 88.3 78.2 65.5 52.6

75/62 72.7 60.8 50.1 37.6

70/57 57.7 46.9 36.6 29.7

48D 1600

85/72 115.2 105.0 93.9 79.0

80/67 88.3 78.2 65.5 52.6

75/62 72.7 60.8 50.1 37.6

70/57 57.7 46.9 36.6 29.7

60C 1800

85/72 115.1 103.0 91.7 78.6

80/67 96.8 85.9 73.7 60.5

75/62 80.7 69.4 57.5 43.5

70/57 58.7 48.9 37.7 32.7

60D 1800

85/72 133.6 118.5 103.2 86.6

80/67 111.4 96.2 80.3 62.8

75/62 90.7 75.1 60.0 43.5

70/57 70.6 56.9 42.5 32.8

1. Actual capacity varies with the outdoor AC or HP that is used with the system.

2. Airflow is calculated for each system tonnage.

Johnson Controls Unitary Products 5

5151060-YTG-F-1116

PHYSICAL & ELECTRICAL DATA - COOLING ONLY

Models 18B 24B 30B 36B 36C

Blower - Diameter x Width 10 x 8 10 x 8 10 x 8 10 x 8 11 x 10

Motor HP 1/3 HP 1/3 HP 1/3 HP 1/2 HP 1/2 HP

Nominal RPM 1050 1050 1050 1050 1050

Voltage 208/230 208/230 208/230 208/230 208/230

Full Load Amps @230V 2.9 2.9 2.9 4.5 4.5

Filter1Type DISPOSABLE OR PERMANENT

Size 16 x 20 x 1 16 x 20 x 1 16 x 20 x 1 16 x 20 x 1 20 x 20 x 1

Permanent Type Kit 1PF0601 1PF0601 1PF0601 1PF0601 1PF0602

Shipping Operating Weight (lbs.) 91/85 93/87 119/113 119/113 120/114

Models 42C 48C 48D 60C 60D

Blower - Diameter x Width 11 x 10 11 x 10 11 x 10 11 x 10 11 x 10

Motor HP 1/2 HP 3/4 HP 3/4 HP 3/4 HP 3/4 HP

Nominal RPM 1050 1050 1050 1050 1050

Voltage 208/230 208/230 208/230 208/230 208/230

Full Load Amps @230V 4.5 7.0 7.0 7.0 7.0

Filter1Type DISPOSABLE OR PERMANENT

Size 20 x 20 x 1 20 x 20 x 1 22 x 20 x 1 20 x 20 x 1 22 x 20 x 1

Permanent Type Kit 1PF0602 1PF0602 1PF0603 1PF0602 1PF0603

Shipping Operating Weight (lbs.) 144/136 158/150 163/153 156/146 180/170

1. Field supplied.

kW & MBH CONVERSIONS - FOR TOTAL POWER INPUT REQUIREMENT

For a power distribution voltage that is different than the provided nominal voltage, multiply the kW and MBH data from the table by the conversion

factor in the following table.

DISTRIBUTION POWER NOMINAL VOLTAGE CONVERSION FACTOR

208V 240V 0.75

220V 240V 0.84

230V 240V 0.92

APPLICATION FACTORS - RATED CFM VS. ACTUAL CFM

% Of Rated Airflow (CFM) 80% 90% 100% 110% 120%

Capacity Factor 0.96 0.98 1.00 1.02 1.03

ELECTRICAL DATA - COOLING ONLY

Models Motor FLA1Minimum Circuit Ampacity MOP2

208V 230V 208V 230V

18B/24B/30B 3.0 2.9 3.8 3.6 15

36B/36C/42C 5.0 4.5 6.3 5.6 15

48C/48D/60C/60D 7.3 7.0 9.1 8.8 15

1. FLA = Full Load Amps

2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. Refer to the latest edition of the

National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.

6 Johnson Controls Unitary Products

5151060-YTG-F-1116

ELECTRICAL HEAT - MINIMUM FAN SPEED

Heater Kit

Models1,2,3 Nom. kW

@240V Air Handler Models

18B 24B 30B 36B 36C 42C 48C 48D 60C 60D

6HK(0,1)6500206 2.4kW Med Lo (D)Med Lo (D)Med Lo (D) Med Lo (D) Med Lo (D)Med Lo (D)Med Lo (D) Med Lo (D)Med Lo (D)Med Lo (D)

6HK(0,1)6500506 4.8kW Med Lo (D) Med (C) Med (C) Med Lo (D) Med (C) Med Lo (D)Med Lo (D) Med Lo (D)Med Lo (D)Med Lo (D)

6HK(0,1)6500806 7.7kW Med (C) Med Hi (B) Med Hi (B) Med Lo (D) Med Hi (B) Med (C) Med Lo (D) Med Lo (D) Med Lo (D)Med Lo (D)

6HK(0,1)6501006

6HK36501025 9.6kW Med (C) Med Hi (B) Med Hi (B) Med Lo (D) Med Hi (B) Med (C) Med Lo (D) Med Lo (D) Med Lo (D)Med Lo (D)

6HK(1,2)6501306 12.5kW – Med Hi (B) Med Hi (B) Med (C) Med Hi (B) Med (C) Med Lo (D) Med Lo (D) Med Lo (D)Med Lo (D)

6HK(1,2)6501506

6HK36501525 14.4kW – – Med Hi (B) Med Hi (B) Med Hi (B) Hi (A) Med (C) Med (C) Med Lo (D)Med Lo (D)

6HK(1,2)6501806

6HK36501825 17.3kW – – – Med Hi (B) Med Hi (B) Hi (A) Med (C) Med Hi (B) Med (C) Med (C)

6HK(1,2)6502006

6HK46502025 19.2kW – – – Med Hi (B) Hi (A) Hi (A) Med Hi (B) Hi (A) Med Hi (B) Med Hi (B)

6HK(1,2)6502506

6HK46502525 24kW – – – – – – – Hi (A) – Med Hi (B)

1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.

2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.

3. 6HK3 = 3-Phase with terminal block connectors only, 6HK4 = 3-Phase with service disconnect.

ELECTRIC HEAT PERFORMANCE DATA: 208/230-1-60 & 208/230-3-60

Heater

Models1,2,3 Nominal kW

@240V

Total Heat4kW Staging

kW MBH W1 Only W1 + W2

208V 230V 208V 230V 208V 230V 208V 230V

1PH

6HK(0,1)6500206 2.4 1.8 2.2 6.2 7.5 1.8 2.2 1.8 2.2

6HK(0,1)6500506 4.8 3.6 4.4 12.3 15 3.6 4.4 3.6 4.4

6HK(0,1)6500806 7.7 5.8 7.1 19.7 24.1 5.8 7.1 5.8 7.1

6HK(0,1)6501006 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8

6HK(1,2)6501306 12.5 9.4 11.5 32 39.2 3.1 3.8 9.4 11.5

6HK(1,2)6501506 14.4 10.8 13.2 36.9 45.1 3.6 4.4 10.8 13.2

6HK(1,2)6501806 17.3 13 15.9 44.3 54.2 6.5 7.9 13 15.9

6HK(1,2)6502006 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6

6HK(1,2)6502506 24 18 22 61.5 75.2 7.2 8.8 18 22

3PH

6HK36501025 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8

6HK36501525 14.4 10.8 13.2 36.9 45.1 10.8 13.2 10.8 13.2

6HK36501825 17.3 13 15.9 44.3 54.2 13 15.9 13 15.9

6HK46502025 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6

6HK46502525 24 18 22 61.5 75.2 9 11 18 22

1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.

2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.

3. 6HK3 = 3-Phase with terminal block connectors only, 6HK4 = 3-Phase with service disconnect.

4. For different power distributions, see conversion table on Page 5.

Johnson Controls Unitary Products 7

5151060-YTG-F-1116

ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-1-60

Air Handler Models Heater Models1,2 Heater

Amps

@240V

Field Wiring

Min. Circuit Ampacity MOP.3

208V 230V 208V 230V

18B

6HK(0,1)6500206 10 14.6 15.6 15 20

6HK(0,1)6500506 20 25.4 27.5 30 30

6HK(0,1)6500806 32 38.6 42.2 40 45

6HK(0,1)6501006 40 47.0 51.5 50 60

24B

6HK(0,1)6500206 10 14.6 15.6 15 20

6HK(0,1)6500506 20 25.4 27.5 30 30

6HK(0,1)6500806 32 38.6 42.2 40 45

6HK(0,1)6501006 40 47.0 51.5 50 60

6HK(1,2)6501306 52 60.2 66.1 70 70

30B

6HK(0,1)6500206 10 14.6 15.6 15 20

6HK(0,1)6500506 20 25.4 27.5 30 30

6HK(0,1)6500806 32 38.6 42.2 40 45

6HK(0,1)6501006 40 47.0 51.5 50 60

6HK(1,2)6501306 52 60.2 66.1 70 70

6HK(1,2)6501506 60 68.7 75.4 70 80

36B

6HK(0,1)6500206 10 17.1 17.6 20 20

6HK(0,1)6500506 20 27.9 29.5 30 30

6HK(0,1)6500806 32 41.1 44.2 45 45

6HK(0,1)6501006 40 49.5 53.5 50 60

6HK(1,2)6501306 52 62.7 68.1 70 70

6HK(1,2)6501506 60 71.2 77.4 80 80

6HK(1,2)6501806 72 84.4 92.0 90 100

6HK(1,2)6502006 80 92.8 101.3 100 110

36C

6HK(0,1)6500206 10 17.1 17.6 20 20

6HK(0,1)6500506 20 27.9 29.5 30 30

6HK(0,1)6500806 32 41.1 44.2 45 45

6HK(0,1)6501006 40 49.5 53.5 50 60

6HK(1,2)6501306 52 62.7 68.1 70 70

6HK(1,2)6501506 60 71.2 77.4 80 80

6HK(1,2)6501806 72 84.4 92.0 90 100

6HK(1,2)6502006 80 92.8 101.3 100 110

42C

6HK(0,1)6500206 10 17.1 17.6 20 20

6HK(0,1)6500506 20 27.9 29.5 30 30

6HK(0,1)6500806 32 41.1 44.2 45 45

6HK(0,1)6501006 40 49.5 53.5 50 60

6HK(1,2)6501306 52 62.7 68.1 70 70

6HK(1,2)6501506 60 71.2 77.4 80 80

6HK(1,2)6501806 72 84.4 92.0 90 100

6HK(1,2)6502006 80 92.8 101.3 100 110

48C

6HK(0,1)6500206 10 19.9 20.7 25 25

6HK(0,1)6500506 20 30.8 32.7 35 35

6HK(0,1)6500806 32 44.0 47.3 45 50

6HK(0,1)6501006 40 52.4 56.6 60 60

6HK(1,2)6501306 52 65.6 71.3 70 80

6HK(1,2)6501506 60 74.0 80.5 80 90

6HK(1,2)6501806 72 87.3 95.2 90 100

6HK(1,2)6502006 80 95.7 104.4 100 110

For notes, see Page 8.

8 Johnson Controls Unitary Products

5151060-YTG-F-1116

48D

6HK(0,1)6500206 10 19.9 20.7 25 25

6HK(0,1)6500506 20 30.8 32.7 35 35

6HK(0,1)6500806 32 44.0 47.3 45 50

6HK(0,1)6501006 40 52.4 56.6 60 60

6HK(1,2)6501306 52 65.6 71.3 70 80

6HK(1,2)6501506 60 74.0 80.5 80 90

6HK(1,2)6501806 72 87.3 95.2 90 100

6HK(1,2)6502006 80 95.7 104.4 100 110

6HK(1,2)6502506 100 117.3 128.3 125 150

60C

6HK(0,1)6500206 10 19.9 20.7 25 25

6HK(0,1)6500506 20 30.8 32.7 35 35

6HK(0,1)6500806 32 44.0 47.3 45 50

6HK(0,1)6501006 40 52.4 56.6 60 60

6HK(1,2)6501306 52 65.6 71.3 70 80

6HK(1,2)6501506 60 74.0 80.5 80 90

6HK(1,2)6501806 72 87.3 95.2 90 100

6HK(1,2)6502006 80 95.7 104.4 100 110

60D

6HK(0,1)6500206 10 19.9 20.7 25 25

6HK(0,1)6500506 20 30.8 32.7 35 35

6HK(0,1)6500806 32 44.0 47.3 45 50

6HK(0,1)6501006 40 52.4 56.6 60 60

6HK(1,2)6501306 52 65.6 71.3 70 80

6HK(1,2)6501506 60 74.0 80.5 80 90

6HK(1,2)6501806 72 87.3 95.2 90 100

6HK(1,2)6502006 80 95.7 104.4 100 110

6HK(1,2)6502506 100 117.3 128.3 125 150

1. (0,1) - maybe 0 (no service disconnect) or 1 (with service disconnect).

2. (1,2) maybe 1 (with service disconnect, no breaker jumper bar) or 2 (with service disconnect & breaker jumper bar).

3. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. Refer to the latest edition of the

National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.

ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-1-60 (Continued)

Air Handler Models Heater Models1,2 Heater

Amps

@240V

Field Wiring

Min. Circuit Ampacity MOP.3

208V 230V 208V 230V

Johnson Controls Unitary Products 9

5151060-YTG-F-1116

ELECTRICAL DATA FOR MULTI-SOURCE POWER SUPPLY: 208/230-1-60

AirHandlers

Models Heater

Models

Heater

Amps

@240V

Min. Circuit Ampacity MOP1

208V 230V 208V 230V

Circuit Circuit

1st32nd 3rd 1st32nd 3rd 1st32nd 3rd 1st32nd 3rd

24B 6HK16501306 52 22.5 37.6 – 24.4 41.5 – 25 40 - 25 45 –

30B 6HK16501306 52 22.5 37.6 – 24.4 41.5 – 25 40 - 25 45 –

6HK16501506 60 25.4 43.3 – 27.6 47.9 – 30 45 - 30 50 –

36B

6HK16501306 52 25.0 37.6 – 26.4 41.5 – 25 40 – 30 45 –

6HK16501506 60 27.9 43.3 – 29.6 47.9 – 30 45 – 30 50 –

6HK16501806 72 45.3 39.0 – 48.8 43.1 – 50 40 – 50 45 –

6HK16502006 80 49.6 43.3 – 53.5 47.9 – 50 45 – 60 50 –

36C

6HK16501306 52 25.0 37.6 – 26.4 41.5 – 25 40 – 30 45 –

6HK16501506 60 27.9 43.3 – 29.6 47.9 – 30 45 – 30 50 –

6HK16501806 72 45.3 39.0 – 48.8 43.1 – 50 40 – 50 45 –

6HK16502006 80 49.6 43.3 – 53.5 47.9 – 50 45 – 60 50 –

42C

6HK16501306 52 25.0 37.6 – 26.4 41.5 – 25 40 – 30 45 –

6HK16501506 60 27.9 43.3 – 29.6 47.9 – 30 45 – 30 50 –

6HK16501806 72 45.3 39.0 – 48.8 43.1 – 50 40 – 50 45 –

6HK16502006 80 49.6 43.3 – 53.5 47.9 – 50 45 – 60 50 –

48C

6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –

6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –

6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –

6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –

48D

6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –

6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –

6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –

6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –

6HK16502506 100 52.5 43.3 21.7 56.7 47.9 24.0 60 45 25 60 50 25

60C

6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –

6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –

6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –

6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –

60D

6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –

6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –

6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –

6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –

6HK16502506 100 52.5 43.3 21.7 56.7 47.9 24.0 60 45 25 60 50 25

1. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.

Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.

10 Johnson Controls Unitary Products

5151060-YTG-F-1116

ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-3-60

Air Handler

Models Heater Models1

1. Asterisk (*) denotes the 20kW and 25kW heater models (6HK46502025 and 6HK46502525) come with service disconnects standard. Single source power

MCA and MOP requirements are given here only for reference if used with field installed single point power modification (S1-32436041000).

Heater

Amps

@240V

Field Wiring

Min. Circuit Ampacity MOP.2

2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.

Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.

208V 230V 208V 230V

18B 6HK36501025 23.1 28.8 31.3 30 35

24B 6HK36501025 23.1 28.8 31.3 30 35

30B 6HK36501025 23.1 28.8 31.3 30 35

6HK36501525 34.6 41.2 45.1 45 50

36B

6HK36501025 23.1 31.3 33.3 35 35

6HK36501525 34.6 43.7 47.1 45 50

6HK36501825 41.6 51.3 55.5 50 60

6HK46502025*46.2 56.3 61.0 60 70

36C

6HK36501025 23.1 31.3 33.3 35 35

6HK36501525 34.6 43.7 47.1 45 50

6HK36501825 41.6 51.3 55.5 55 60

6HK46502025*46.2 56.3 61.0 60 70

42C

6HK36501025 23.1 31.3 33.3 35 35

6HK36501525 34.6 43.7 47.1 45 50

6HK36501825 41.6 51.3 55.5 55 60

6HK46502025*46.2 56.3 61.0 60 70

48C

6HK36501025 23.1 34.2 36.4 35 40

6HK36501525 34.6 46.6 50.2 50 55

6HK36501825 41.6 54.2 58.6 55 60

6HK46502025*46.2 59.2 64.1 60 70

48D

6HK36501025 23.1 34.2 36.4 35 40

6HK36501525 34.6 46.6 50.2 50 55

6HK36501825 41.6 54.2 58.6 55 60

6HK46502025*46.2 59.2 64.1 60 70

6HK46502525*57.7 71.6 77.9 80 80

60C

6HK36501025 23.1 34.2 36.4 35 40

6HK36501525 34.6 46.6 50.2 50 55

6HK36501825 41.6 54.2 58.6 55 60

6HK46502025*46.2 59.2 64.1 60 70

60D

6HK36501025 23.1 34.2 36.4 35 40

6HK36501525 34.6 46.6 50.2 50 55

6HK36501825 41.6 54.2 58.6 55 60

6HK46502025*46.2 59.2 64.1 60 70

6HK46502525*57.7 71.6 77.9 80 80

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels York Unité de traitement de l'air

York

York MAXA-MISER VR036A15H Manuel utilisateur

York

York N1VSD10A06 Manuel utilisateur

York

York ZT SERIES Guide de démarrage rapide

York

York AVY24 THRU 60 Guide de démarrage rapide

York

York RFCB18BXEMP2S1 Manuel utilisateur

York

York MA - 115V Manuel utilisateur

York

York Solution Instructions d'installation

York

York MVC SERIES Guide de démarrage rapide

York

York AE SERIES Manuel utilisateur

York

York AHP18 THRU 60 Guide de démarrage rapide

York

York AHP18 THRU 60 Guide de démarrage rapide

York

York MA Guide de démarrage rapide

York

York MX Series Manuel utilisateur

York

York ZF 036-072 Manuel utilisateur

York

York LDO9688 Manuel utilisateur

York

York SOLUTION XTI Series Mode d’emploi

York

York F2RP018 Manuel utilisateur

York

York AHU Guide d'installation

York

York F4FP024H06T3X Manuel utilisateur

York

York JHVTB18B Manuel utilisateur

York

York MCH CRAH Manuel utilisateur

York

York CS2000 Manuel du propriétaire

York

York R-410A Guide de démarrage rapide

York

York YBAH Series Manuel d'instructions

Manuels Unité de traitement de l'air populaires d'autres marques

Klimor

Klimor EVO-S Manuel utilisateur

Salda

Salda SMARTY XP Mode d’emploi

BLAUBERG

BLAUBERG KOMFORT Roto EC S400 Manuel utilisateur

Trenton

Trenton TPLP Series Manuel utilisateur

Kemper

Kemper CleanAirTower Manuel utilisateur

Daikin

Daikin DV PTC 14 Series Manuel utilisateur

Haier

Haier HB2400VA1M20 Manuel utilisateur

Webasto

Webasto BlueCool A-Series Manuel utilisateur

RDZ

RDZ DA 701 Document technique

Carrier

Carrier 39T Dimensions et guide d'installation

Armstrong Air

Armstrong Air BCE5V Series Manuel utilisateur

ActronAir

ActronAir CAY500T Manuel utilisateur

Carrier

Carrier 40MBDAQ Manuel utilisateur

Allied

Allied A93UH1E Manuel utilisateur

Nortek

Nortek B6VMAI Manuel utilisateur

TemperZone

TemperZone Econex Pro OPA 1410RLTM4FPQD Guide de maintenance et de service

RDZ

RDZ WHR 200 Document technique

AAON

AAON H3 Series Manuel du propriétaire
