Yolink M2 Manuel d'utilisation

YoLink Smart Lock M2

(Door Knob)

YS7607-UC

Installaon & User Guide

Rev 1.1

Contents

B .

C .

E .

F .

I .

J .

In the Box ······· ····· · ·· · ·1······················ ····· ···················································· · ·

Introducon ······························································································2

Set Up ····································································································· ·4·

Installaon ·······························································································6

Using the YoLink Smart Lock M2 ·······························································14

Using the YoLink App ···············································································19

Maintenance ······················································································· ···25·

Speciﬁcaons ····················································································· ····27·

Troubleshoong ················································································· ·····28·

Warning ······························································································ ····29·

Revised: 04/25/2021

A. In the Box

A. Front Module

B. Back Module

C. Strike Plate

D. Back Mounng Plate

E. Dead Latch

F. Screws (8)

G. Mechanical key (2)

E. F. F3

F2F1

C. D.

A. B.

B. Introducon

The YoLink Smart Lock M2, is a stand-alone electronic keypad door knob which provides four

methods for both unlocking and locking the door: the knob, the mechanical key, the keypad and the

YoLink app. Add the smart lock to YoLink app, you can lock or unlock the door and can check the

historical unlocked record (including member, method, date and me) though app. When the door is

unlocked, noﬁcaons will be sent to you via the YoLink app (available noﬁcaons types are: email,

text/SMS and push/banner noﬁcaons on your Apple or Android smartphone, each conﬁgurable in

app sengs)

Doorbell Buon

Tap to nofy and send

a visit noﬁcaon the

house host

0-9 Digit keypad

Tap to enter password

Unlocked Buon

Tap to unlock aer

password entered

Locked Buon

Tap to lock

Mechanical Key Hole

Baery Cover

Baery Compartment

Housing four AA non-rechargeable

baeries

Automac Lock 10 Seconds

Aer Being Unlocked

On: Enable automacally lock

Oﬀ: Disable automacally lock

Clear Buon

Knob

SET Buon

The LED light indicates the current status of the smart lock:

Fast Blinking Green Once

Door is Unlocked

Blinking Green

Connecng to Cloud

Fast Blinking Red Once

Door is locked

Blinking Red

Restoring to Factory Default

light Up Blue

Digit keypad backlight

C. Set Up

C-1. Set Up - First-Time YoLink Users (Exisng users proceed to C-2. Add Device, next page)

YoLink Hub is required to set

up your Smart Lock YoLink

M2. Please set up your YoLink

Hub ﬁrst (refer to YoLink Hub

manual)

Power

Adapter

YoLink Hub

Create a new account

if required

Download the YoLink app through

Apple App Store or Google Play

Store (Search in the store or use

the QR code on the right)

Apple iPhone or tablet that is iOS 9.0

or higher, or an Android phone or

tablet that is Android 4.4 or higher

YS1603-UC

User Guide

2. Ethernet patch cable (included) to

your network (router, switch, etc.),

r e c o m m e n d e d , b u t o p  o n a l .

Otherwise connect your Hub to your

home 2.4 GHz Wi-Fi network. Refer

to the Hub set up manual for more

informaon:

1. Make sure your Hub is connected

to the internet (green LED indicator is

blinking, blue LED indicator is always

on)

C-2. Add Device

Ta p “ ” buon, then scan Q R

C o d e o n t h e d e v i c e . Fo l l o w t h e

ste ps to a d d t h e d ev i c e

Install four AA non-rechargeable

baeries aer installaon. The

“ ” Buon LED will blink green

severa l  mes, ind i ca n g your

device has connected to the cloud

and is ready to use

1. You will need to press the SET buon once aer installing four AA baeries or re-install the AA

baeries if the device failed to connect to the cloud

2. If the green LED does not blink as noted this may indicate a problem with the smart lock. Please

see the troubleshoong secon and the contact secon for technical support

D. Installaon

D-1. IMPORTANT SAFETY NOTICE!

DO NOT USE POWER DRILL

The back module (part B) needs to be protected from weather

D-2. These Tools May be Required

Phillips Screwdriver AA Baery (4,

Non-rechargeable)

Adjust Latch Backset

Anclockwise rotate to loose the buckle

Clockwise rotate to ghten the buckle

Pull right to extend the length of buckle to

70 millimeters ; push le to (23/4'' inches)

s ho r te n t h e l e ng th o f b u c k l e t o 6 0

millimeters inches)(23/8''

Default is 60 millimeters (23/8''

inches)

60mm(23/8′′)

70mm(23/4′′)

Please keep the square

in the circle aligned to

the latch backset

D-3. Get Ready

D-4. Begin Installaon

Install the door latch

G e n t l y p u t t h e d o o r l a t c h a c r o s s t h e

i n s t a l l a  o n h o l e o n t h e d o o r

Sc rew an d fasten the dead latch wit h

two mou n ng s crews (F3 )

1. Keep the inclined plane outward
