Yolink YS7704-UC Manuel utilisateur

User Guide

Door Densor YS7704-UC

REV 1.0

Contents

Introduction··············································· 1

Features··················································· 2

Product Requirements·································· 2

Set Up Door Sensor ····································· 3

Using YoLink App with Door Sensor··················· 5

Maintaining the Door Sensor···························8

Troubleshooting·········································10

Speciﬁcations·············································11

Installation················································· 4

YoLink Control···········································7

Introduction

YoLink Door Sensor will detect opening and closing of your door and send alert or trigger

action.

Red Once

Alert.

Blinking Green

Connecting to cloud.

Fast Blinking Green

Set up connection with devices.

Fast Blinking Red

Remove connection with devices.

Blinking Red and Green

Factory resetting.

SET Button

Slow Blinking Green

Updating.

Sensor

Magnet

This device can also be applied to windows, drawers, boxes or other stuff which you want to

monitor on and off or trigger certain action

Features

Real-time Status - Monitor the real-time state of door via YoLink App.

Open Remind - Remind you while the door is open for a set up time.

Battery Status - Update battery level and send low battery alert.

YoLink Control - Trigger an action of certain YoLink devices without internet.

Automation - Set up rules for “If this then that” function.

Product Requirements

1. A YoLink Hub.

2. A smartphone or tablet running iOS 9 or higher; Android 4.4 or higher.

Set Up Door Sensor

Follow the steps below to set up your Door Sensor via YoLink App.

Tap the “ ” in YoLink App. Scan the

QR Code on the QSG or the device.

Remove the tab o n your door sensor

and it is ready to go.

Add To YoLink App Power On and Enjoy

Installation

Please keep the default distance between sensor and magnet within 18mm when closed.

Please use the double side tape to stick the sensor and magnet to wherever you want to

monitor.

Note

Please add door sensor to YoLink App before you install it.

While installing, try to stick the sensor to the ﬁxed part of your door or window.

Please align the half circle on sensor with the half circle on magnet.

Using YoLink App with Door Sensor

Details

Name - Set a name for your YoLink Plug.

Room - Choose a room for your YoLink Plug.

Favorite - Click to add to/remove from Favorite.

You can customize the name, set the room, alert mode, open remind, add to/ remove from

favorite, check device history.

Tap the Door Sensor's icon in App to go to its controls.

Tap the Details icon at the top-right corner.

Tap the icon for each of the settings you want to

personalize.

History - Check history log for the plug.

Delete – The device will be removed from your account

and YoLink App.

Alert Mode - Choose an alert mode for your Door Sensor.

Open Remind - Set a time and you will receive an alert

once your door has been open for that long.

Automation allows you to set up IFTTT rules so the devices could act automatically.

Automation

Tap “Smart” to switch to Smart screen and tap

“Automation”.

To set an Automation, you will need to set a trigger

time, local weather condition, or choose a device

with certain stage as a triggered condition. Then set

one or more devices, scenes to be executed.

Tap “ ” to create an automation.

YoLink Control is our unique “device to device” control technology. Under YoLink Control,

the devices could be controlled without internet or Hub.

YoLink Control

You will need to physically set it up.

Devices which send out command is called controller(Master). Devices which receive

command and act accordingly is called responder(Slave).

Find a door sensor as controller(Master). Hold the

set button for 5-10 seconds, the lights will ﬂash

green quickly.

After pairing is done, the light will stop ﬂashing.

Find an action device as responder(Slave). Hold

the set button for 5-10 seconds, the device will

enter pairing mode.

When the door is detected to be opened, the

responder will be turned on as well.

SET Button

Pairing

Find a controller(Master) door sensor . Hold the set

button for 10-15 seconds, the lights will ﬂash red

quickly.

The above two devices will unpair by themselves

and after unpairing is done, the light will stop

ﬂashing.

Find a responder(Slave) action device. Hold the

set button for 10-15 seconds, the device will

enter unpairing mode.

When the door is detected to be opened, the

responder will no longer turned on.

SET Button

Unpairing
