Yellowtec iXm Manuel utilisateur
iXm Recording Microphone
(V1.2)
Manual
Operations
www.facebook.com/yellowtec www.twitter.com/yellowtec
2
www.yellowtec.com Iinfo@yellowtec.com
3
www.yellowtec.com Iinfo@yellowtec.com
Thank you
iXm is a broadcast quality recording microphone created by
broadcasters for broadcasters. With intuitive operation and robust
construction, iXm delivers pristine sound quality without the need to
monitor levels or make other adjustments.
iXm oers true simplicity – just turn it on, press record and you’re good
to go! No need to watch level displays and constantly readjust your
settings. The quality of our intelligent Auto-Levelling algorithm (LEA)
ensures perfect recordings for true professional broadcast use, making
the product ideal for recording in the eld with any interviewer, even
those with no audio knowledge at all.
Plus, iXm is completely exible, with interchangeable microphone
capsules that allow you to choose the perfect recording method for any
setting. Plus, the included software provides even greater versatility for
a more customized experience.
Thank you
for purchasing the Yellowtec iXm
Recording Microphone
4
www.yellowtec.com Iinfo@yellowtec.com
Table of Contents
iXm was designed to be the superior choice,
providing:
• LEA Engine for pristine, hassle-free auto leveling
• Interchangeable microphone capsules (omni-directional,
cardioid and super-cardioid)
• Mic head recognition for automatic DSP adjustments (e.g. lter,
phantom power)
• Two buttons operation for safe recording
• Silent marker setting on the y
• Up to 14 hours of operation time
• Dual power system with intelligent management of built in Li-
Ion battery and/or 3 x AA batteries
• Removable, universal SD/SDHC memory cards for memory of
up to 16 GB
• Selectabele audio formats: WAV, BWF, MP2
• Balanced line input for line level recording
• Headphone output for live monitoring
• Voice messaging system for easy playback navigation
• Playback Keypad for intuitive navigation
• User and Admin software for enhanced setup and parameter
settings
5
www.yellowtec.com Iinfo@yellowtec.com
Table of Contents
6
7
8
10
12
15
18
20
21
23
24
25
26
27
28
30
WHAT’S IN THE BOX
SAFETY INSTRUCTIONS
BASIC FUNCTIONS
LAYOUT OF CONTROLS
DASHBOARD INDICATORS
RECORDING
PLAYBACK
POWER MANAGEMENT
MEMORY
MIC HEADS
LINE IN
LINE OUT
SOFTWARE
USB CONNECTION
INSTALLATION
USER SOFTWARE
32 ADMIN SOFTWARE
6
www.yellowtec.com Iinfo@yellowtec.com
What‘s in the box
Mic Head
Recorder
Wall Charger
SD-Card
USB Cable (Type-A to Mini USB)
International Main Adapters
1
2
3
4
5
6
5
4
3
2
1
6
7
www.yellowtec.com Iinfo@yellowtec.com
Safety instructions
Reading the instructions is essential to prevent the prdocut from any
damage. It helps to avoid false operation and secures successful and
long lasting use of your product.
Never use the iXm without having a Mic Head installed. It helps
to prevent damage to the mounting thread and the electronic
contacts.
When twisting the Mic Head onto the Recorder hold the head
straight and do not use excessive force. Twist the Mic Head
gently tight. The ne thread will prevent the Mic Head going
loose.
Before you start to use the iXm charge the internal Li-Ion
battery for a minimum of 4 hrs. The Battery Indicator will stop
ashing when the Li-Ion Battery is fully charged.
Important!
When using batteries make sure you use quality AA batteries
of the same make. Make sure you discard used batteries in
compliance with environmental regulations.
Never leave batteries inside the iXm‘s battery compartment for
a long period of time. Used batteries may leak and terminate
warranty claims.
When using the wall charger make sure the international mains
adapter heads are always installed to the charger. Never use the
charger’s adapter heads separate from the charger!
8
www.yellowtec.com Iinfo@yellowtec.com
Basic functions
In order to operate the iXm in various recording environments you have
a choice of dierent Mic Heads. Mic Heads can be exchanged easily by
the TOTO mount (twisting-o-twisting-on).
In order to protect the thread and the electronic contacts always make
sure that you never use the Microphone Recorder without a Mic Head
installed! Always hold the Mic Head straight and twist it gently tight. Do
not risk cross-threading.
Charge Internal Li-Ion Battery
Before using iXm for the rst time, charge the
internal Li-Ion battery until the amber BAT indicator
stops ashing. Use the provided USB cable to
connect iXm with the wall charger, car adaptor or
personal computer.
Insert SD Memory Card
Insert an SD memory card with its label facing up
until it latches. Should the Memory Indicator quick
ash red, the SD card is not usable. Read more at
`Use of SD-Cards‘ .
9
www.yellowtec.com Iinfo@yellowtec.com
Basic functions
Recording great audio with iXm is easy. There is no need to monitor a
display as our amazing LEA Engine will always deliver a perfect level-
ling. iXm takes care of this automatically for you, producing broadcast-
ready recordings at the touch of a button. Try it now - here‘s all you
need to do:
Power On
Press and hold the RECORD Button and simultaneously
press the STOP Button on the Playback Keypad. When
the boot sequence starts you can release the buttons.
Wait until the REC LED stops quick ashing. Your iXm is
now ready to record. (See table of indicators)
Record
To start a recording simply hit the RECORD button.
Once the REC LED shows red you are capturing every
word. During a recording simply press the RECORD
button again to set track markers on the y, at any
time.
Stop and Save
To nish your recording, hit the STOP Button on the
RECORD Keypad. The REC LED will quickly ash to
indicate correct data transfer to the SD card memory.
Once the quick ashing ends your iXm is ready for your
next recording.
Playback
To check recorded audio in the eld use the Playback
Keypad to navigate through your recording. Connect a
headphone to the 3.5mm Mini Jack on the Port Panel.
Voice announcments will guide you through your
tracks as you listen.
10
www.yellowtec.com Iinfo@yellowtec.com
Basic functions
Adjust Playback Level
During playback, you can adjust the volume of your
headphone. To increase the headphone level press and
hold the STOP Button on the dashboard and press FOR-
WARD, to decrease your level hold the STOP button
and press REWIND. Each hit will cause a change of 3dB.
NOTE: Before using headphones, make sure that you
carefully set your playback level to an appropriate level
to avoid temporary or permanent hearing damage. It
is advised to set a maximum output level in the user
software.
Power O
To switch the iXm o press and hold the STOP Button of
the Dashboard and hit the STOP Button of the Playback
Keypad simultaneously. All LEDs will turn o and the
unit will power down.
Record Keypad / Dashboard
REC LED
MEM LEDBAT LED
REC
STOP
