YASKAWA G2 Manuel utilisateur
Quick Guide for Ethernet Network Card G2
06/01/2019
Revision 8
Introduction
Page 1
The Ethernet Network Card is used for monitoring and controlling purposes. The Ethernet Net-
work Card supports industry standard Modbus RS485 communication and TCP/IP protocol.
When used with an Internet connection, it can send data to an online portal from where up to 32
inverters can be monitored. It can also be used to remotely update the inverter firmware.
Capabilities
● Remote inverter firmware upgrade support by Yaskawa Solectria Solar (YSS).
● Remote diagnostics by YSS Technical Support & Service.
● Direct customer data from the Ethernet Network Card via a programmable Ethernet XML
Sunspec Data Exchange connection for customers who want to manage their own data directly.
● Pass-thru Modbus communications to a third-party gateway.
General data
Voltage supply
Connections
Communicate to
Modbus daisy chain
Third-party data logger
Cloud service
Third-party server
Raw data client
RS485 port A
RS485 port B
Pass-thru
Ethernet
WiFi module
Isolated RS485, Max. 32 devices
Pass-thru port, Isolated 3 Pin RS485
Ethernet port, MQTT
Ethernet port, HTTPS
Ethernet port, Modbus/TCP
Internal installation, RS485+DC Input, 6 Pin
External installation, RS485+DC Input, 5 Pole 3.5 mm pitch EDG
Only one effective at the same time between port A and B
RS485, 3 Pole, A+ / B- / G
RJ45, 10Base-T / 100Base-T
4Pin connector
Input voltage
Power consumption
9 ~ 24 Vdc
< 1 W, Max. 5 W
Ambient conditions
Degree of protection
Ambient temperature
Relative humidity
Installed in inverter wire-box or 3rd party enclosure
-40√ to +85√, Natural convection
< 85%, Non-condensing
Dimensions ( W/H/D)
Weight
Status display
140 mm / 70 mm / 15 mm
50 g
LEDs for Activity, Cloud, RS485 and Power
Page 2
Ethernet Port
WiFi Module Port
Switch
Pass-through Port
Reboot Button
RS485 Port B
Switch
RS485 Port A
Internal installation option
Activity
Cloud
RS485
Power
External installation option
A
A+ B- G
Vin GND A+ B- G
Ethernet Network Card (ENC) G2
Interface & Indicators
B
Page 3
Activity
Cloud
RS485
Power
Caution:
The termination switch should always be ON if it is the last device in a daisy chain.
If the length of the cable connecting to RS485 port or Pass-through port of
the ENC is over 1000 meters, the termination switch button must be set to ON.
Activity
Fast Blink: Executing Command
Blink: Gateway Heartbeat
Cloud
ON: Connected
Fast Blink: Communication with Cloud
Blink: LAN Activity
OFF: Disconnected
RS485
Blink: Device R/W
OFF: No Activity
Power
ON
OFF
Contents Note
ENC G2 DC 9~24V, Max. 5 W
WiFi Module
Accessories D2XH Cable, 3 Standoffs with Screws,
3-Pin Connector, 5-Pin Connector
ENC Enclosure 80mm * 92.5mm * 35mm
Scope of Delivery
Terminating Resistance
Switch
Terminating Resistance
Switch
Page 4
A
Installation Option
Internal in Wire-Box of the Inverter
Inverter Inverter
Inverter
Wire Box
RS485
3rd Party Server
HTTPS
YSS Server
MQTT
WiFi Module + APP
Router
When the inverters are monitored via the ENC, a unique RS-485 address for each
inverter can be set up through the LCD interface.
Up to 32 inverters can be connected together in the communication network.
Page 5
The Communication Board of Inverter
RS485 Port
1
Inverter Wire-Box
Remove the (3) screws that attach
the inverter communication board
in the Wire-Box using a #2 Phillips
bit.
2Replace the screws with the (3)
standoffs included in the ENC Kit.
6-PIN Header
6-PIN Connector
3
Install the ENC by carefully aligning
the 6-PIN connector in the upper
left-hand corner of the communication
board.
Install the (3) screws into the stand-
offs to secure the ENC in place.
Install the 3 screws and torque to 7
in-lbs using a #2 Phillips bit.
Page 6
Ethernet Port
Connect the 3rd party Datalogger to the Pass-Through in the bottom left-hand corner
of the ENC using the 3-Pin Connector provided in the ENC Kit.
Connect the RS485 inverter daisy chain to the inverter communication board using
the 5-Pin Connector provided in the ENC Kit.
NOTE: The 5-Pin Connector is installed on the port on the bottom of the inverter
communication board (behind the ENC) .
The RJ45 LAN cable is inserted into
the Ethernet port of the ENC.
The LAN cable must be able to access
the Internet without port filtering behind
the firewall.
5
A+ B- G
Vin GND A+ B- G
RS485 of 3rd Party Data Logger
RS485 Inverter Daisy Chain
4
Optional wire
Optional wire
A + / B - / G
A + / B - / G
Page 7
RS485 Daisy Chain
Pass-through
D2XH Cable (Provided)
WiFi Module
Ethernet Port
Internet
WiFi
Inverter
3rd Party
Data
Logger
6
The WiFi module is connected to the WiFi port of ENC via the D2XH cable provided.
Download and install the “Yaskawa Connect ” app from the Apple Store and
Google Play.
RS485 & A+ / B- '
RS485 & A+ / B- '
Page 8
1
The ENC may be installed in an enclosure as shown.
The ENC Enclosure includes a DIN rail mounting clip for installation in
a NEMA4 communication box.
Screw M3*8
Screw M3*6
Installation Option
ENC in external enclosure
B
92.5 mm 80 mm
35 mm
Page 9
Ethernet
RS485
Data logger
Ethernet
Cellular
Fiber
Meter
RS485
Weather Station
Ethernet
RS485
Modbus/TCP Converter
AC/DC
Power
- +
Inverter
ID:101
Inverter
ID:102
Inverter
ID:117
Switch
Third-party DAS
Example
RS485
Surge
S
S
- +
- +
Pass-through
Ethernet
RS485
2Typical
Don’t use the Modbus ID 160.
It is reserved for broadcast
commands.
Ground wire diameter is 1 mm2
