YASKAWA PROFINET V1000 Manuel utilisateur

安川インバータV1000

小形ベクトル制御

NEMA Type 4X/IP66タイプ設置要領書

形式 CIMR-VA

容量範囲 200 V級（三相電源用）0.1〜18.5 kW

200 V級（単相電源用）0.1〜3.0 kW

400 V級（三相電源用）0.2〜18.5 kW

YASKAWA AC Drive-V1000

Compact Vector Control Drive

NEMA Type 4X/IP66 Installation Manual

Models: 200 V Class, Three-Phase Input: 0.1 to 18.5 kW

200 V Class, Single-Phase Input: 0.1 to 3.0 kW

400 V Class, Three-Phase Input: 0.2 to 18.5 kW

Type: CIMR-VA

To properly use the product, read this manual thoroughly and retain

for easy reference, inspection, and maintenance. Ensure the end user

receives this manual.

製品を安全にお使い頂くために，本書を必ずお読みください。

また，本書をお手元に保管していただくとともに，最終的に本製品をご使用になる

ユーザー様のお手元に確実に届けられるよう，お取り計らい願います。

MANUAL NO. TOBP C710606 35D

2YASKAWA ELEC TR IC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual

transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise,

without the prior written permission of Yaskawa. No patent liability is assumed with respect to the use of the

information contained herein. Moreover, because Yaskawa is constantly striving to improve its high-quality

products, the information contained in this manual is subject to change without notice. Every precaution has

been taken in the preparation of this manual. Nevertheless, Yaskawa assumes no responsibility for errors

or omissions. Neither is any liability assumed for damages resulting from the use of the information

contained in this publication.

YASKAWA ELEC TR IC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual 3

Table of

Contents

1 PREFACE AND SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2 PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3 RECEIVING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

4 COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

5 MECHANICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . .17

6 ELECTRICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . 28

7 CONDITIONS OF ACCEPTABILITY . . . . . . . . . . . . . . . . . . . 35

8 CABLE GLAND SELECTION . . . . . . . . . . . . . . . . . . . . . . . .36

9 DRIVE COOLING FANS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

10 DRIVE REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . .51

11 EMC GUIDELINES COMPLIANCE . . . . . . . . . . . . . . . . . . . 52

12 REVISION HISTORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

4 YASKAWA ELECTRIC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual

1 Preface and Safety

Yaskawa manufactures products used as components in a wide variety of industrial systems

and equipment. The selection and application of Yaskawa products remain the responsibility

of the equipment manufacturer or end user. Yaskawa accepts no responsibility for the way its

products are incorporated into the final system design. Under no circumstances should any

Yaskawa product be incorporated into any product or design as the exclusive or sole safety

control. Without exception, all controls should be designed to detect faults dynamically and

fail safely under all circumstances. All systems or equipment designed to incorporate a

product manufactured by Yaskawa must be supplied to the end user with appropriate

warnings and instructions as to the safe use and operation of that part. Any warnings

provided by Yaskawa must be promptly provided to the end user. Yaskawa offers an express

warranty only as to the quality of its products in conforming to standards and specifications

published in the Yaskawa manual. NO OTHER WARRANTY, EXPRESS OR IMPLIED, IS

OFFERED. Yaskawa assumes no liability for any personal injury, property damage, losses,

or claims arising from misapplication of its products.

1 Preface and Safety

YASKAWA ELECTRIC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual 5

◆

Applicable Documentation

This manual provides instructions on installing the V1000 NEMA Type 4X/IP66 drive. For

more specific information on the operation of this product, refer to the other manuals listed

in the following table:

◆

Terms

Note: Indicates a supplement or precaution that does not cause drive damage.

Drive: Yaskawa AC Drive-V1000 NEMA Type 4X/IP66

◆

Registered Trademarks

Company names and product names listed in this manual are registered trademarks of those

companies.

Yaskawa AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual

Manual No.: TOBP C710606 35

This manual contains basic information required to install the V1000 NEMA Type 4X/IP66

drive. Carefully review this manual along with the Quick Start Guide accompanying the

NEMA Type 4X/IP66.

Yaskawa AC Drive - V1000 Technical Manual

This manual describes installation, wiring, operation procedures, functions, troubleshooting,

maintenance, and inspections to perform before operation.

To obtain instruction manuals for Yaskawa products access these sites:

U.S.: http://www.yaskawa.com

Japan: http://www.e-mechatronics.com

Other areas: contact a Yaskawa representative.

Yaskawa AC Drive - V1000 Quick Start Guide

This guide is packaged together with the product. It contains basic information required to

install and wire the drive. This guide provides basic programming and simple setup and

adjustment.

1 Preface and Safety

6YASKAWA E LE CTR IC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual

◆

Supplemental Safety Information

Read and understand this manual before installing, operating, or servicing the drive. The

drive must be installed according to this manual and local codes.

The following conventions are used to indicate safety messages in this manual. Failure to

heed these messages could result in serious or possibly even fatal injury or damage to the

products or to related equipment and systems.

DANGER

Indicates a hazardous situation, which, if not avoided, will result in death or serious

injury.

WARNING

Indicates a hazardous situation, which, if not avoided, could result in death or

serious injury.

CAUTION

Indicates a hazardous situation, which, if not avoided, could result in minor or

moderate injury.

NOTICE

Indicates an equipment damage message.

1 Preface and Safety

YASKAWA ELECTRIC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual 7

■General Safety

General Precautions

• The diagrams in this section may include drives without covers or safety shields to illustrate details.

Be sure to reinstall covers or shields before operating any devices.

• Any illustrations, photographs, or examples used in this manual are provided as examples only and

may not apply to all products to which this manual is applicable.

• The products and specifications described in this manual or the content and presentation of the

manual may be changed without notice to improve the product and/or the manual.

• When ordering a new copy of the manual due to damage or loss, contact your Yaskawa

representative or the nearest Yaskawa sales office and provide the manual number shown on the

front cover.

DANGER

Heed the safety messages in this manual.

Failure to comply will result in death or serious injury.

The operating company is responsible for any injuries or equipment damage resulting

from failure to heed the warnings in this manual.

WARNING

Fire Hazard

Select the correct main circuit fuse for use with the drive.

Failure to comply could result in death or serious injury due to fire. Refer to the Quick

Start Guide packaged with the drive to select the correct main circuit fuse for UL/CE

compliance.

1 Preface and Safety

8YASKAWA E LE CTR IC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual

NOTICE

Do not expose the drive to halogen group disinfectants.

Failure to comply may cause damage to the electrical components in the drive.

Do not pack the drive in wooden materials that have been fumigated or sterilized.

Do not sterilize the entire package after the product is packed.

YASKAWA ELECTRIC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual 9

2 Product Overview

◆

About This Product

The V1000 NEMA Type 4X/IP66 drive is safe for indoor use and complies with the

following standards:

• UL50E: Enclosures for Electrical Equipment, Environmental Considerations

NEMA Type 4X

• International Standard IEC 60529 Degrees of protection provided by enclosures (IP Code)

IP66

NEMA Type 4X – Enclosures constructed for either indoor or outdoor use to provide a

degree of protection to personnel against incidental contact with the enclosed equipment; to

provide a degree of protection against falling dirt, rain, sleet, snow, windblown dust,

splashing water, hose-directed water, and corrosion; and that will be undamaged by the

external formation of ice on the enclosure.

IP66 – Dust-tight enclosures to do not allow any dust to penetrate. The enclosure guards the

drive against powerful jetting water sprayed from any direction and is protected against

access to hazardous parts with a wire.

The LED operator is located on the outside of the protective case for easy programming

accessibility.

The drive is designed to be mounted as a stand alone unit and is not intended for mounting

inside of another enclosure.

10 YASKAWA ELECTRIC TOBP C710606 35D YASKAWA AC Drive - V1000 NEMA Type 4X/IP66 Installation Manual

3 Receiving

◆

Model Number and Nameplate Check

Please perform the following tasks after receiving the drive:

• Inspect the drive for damage.

If the drive appears damaged upon receipt, contact the shipper immediately.

• Verify receipt of the correct model by checking the information on the nameplate.

Figure 1 shows where the nameplate has been placed on the drive. Remove the front

cover and check the information listed on the nameplate. Refer to Removing the Front

Cover on page 31.

• If you have received the wrong model or the drive does not function properly, contact

your supplier.

■Nameplate

Figure 1

Figure 1 Nameplate Information for Drives without Filter

CIMR-VUBA0001GAA

IP 66

AC1PH 200-240V 50/60Hz

2.0/1.4A

AC3PH 0-240V 0-400Hz 1.2A/0.8A

4.7

5080

MADE IN JAPAN

MAX APPLI.MOTOR:0.2kW/0.1kW REV:A

TYPE 4X INDOOR USE ONLY

PASS

AC drive model

Max applicable motor

Input specifications

Output specifications

Mass

Lot number

Serial number

Software version

Enclosure type
