Yamato SPC - Solar Manuel utilisateur

YCO-130607

SPC - Solar Operation Manual

YAMATO CORPORATION

1775 S. Murray Blvd.

Colorado Springs, CO 80916 USA

Tel (719) 591-1500 Fax (719) 591-1045

YAMATO TECH CORPORATION

#112-19425 Langley By-Pass

Surrey, B.C. V3S 6K1 Canada

Tel (604) 533-2338 Fax (604) 533-0827

www.YamatoCorp.com

Solar Powered

Portion Control Scale

SPC - Solar

Operation Manual

Read this manual before use and keep it handy

YCO-130607

SPC - Solar Operation Manual

Model Lower Range High Range Maximum Tare

SPC-Solar 2 0 - 2.2 lb x 0.002 lb

0 - 2 lb 3 oz x 0.05 oz

0 - 35 oz x 0.05 oz

0 - 1000 g x 1 g

2.2 - 4.4 lb x 0.005 lb

2 lb 3 oz - 44 lb 6oz x 0.1oz

35 - 70 oz x 0.1 oz

1000 - 2000 g x 2 g

2.190 lb

2 lb 2.75 oz

34.75 oz

995 g

SPC-Solar 5 0 - 5.5 lb x 0.05 lb

0 - 5 lb 8 oz x 0.1 oz

0 - 88 oz x 0.1 oz

0 - 2500 g x 2 g

5.5 - 11 lb x 0.01 lb

5 lb 8 oz - 11 lb 2 oz x 0.2 oz

88 - 178 oz x 0.2 oz

2500 - 5000 g x 5 g

5.475 lb

5 lb 7.5 oz

87.5 oz

2490 g

System Parameter

Operation Display

Press and hold the key and press + keys to

go to system parameter mode under the weighing mode.

The

indicator blinks during system parameter

indicator lights up

2 The operation under system parameter mode is as follows

: Move parameter No. forward (+1)

: Move setting value forward (+1)

: Move setting value backward (-1)

* Be sure to set the setting value among available

parameter values shown on the parameter list. When

the setting value you desire has passed, press the

key to move backwared (-1).

Long Press the key to turn off the power to save the

setting value in the memory

Product Specicatons

YCO-130607

SPC - Solar Operation Manual

Parameter List

( # 01 - 04: User parameter, # 05 - 09: System parameter)

Parameter Description Available parameter

01 Power Select 000:

001:

002:

Solar-powered operation (Default)

Battery-powered operation (Quick response)

Hybrid (Solar + Battery) operation

(The response speed is the same as 000)

02 Weighing units

at power on

000:

001:

002:

003:

lb (Default)

lb.oz

03 Checkweighing

function

000:

001:

Disabled

Enabled (Default)

04 Auto-off timer 000:

001-009:

Disabled

Set by one minute (5 minute: Default)

05 Gravity

compensation

000:

001-029:

030-210:

Disabled

Prohibited to set

(Acceleration of Gravity (m/s2) - 9.7600) x 10000/5 + 30

(offset)

Setting range: 9.7600 to 9.8500 m/s2

Minimum setting unit: 0.0005 m/s2

06 Capacity 000:

001:

2000 g

5000 g

07 Zero tracking 000:

001:

Disabled

Enabled (Default)

08 Not used

09 Not used

YCO-130607

SPC - Solar Operation Manual

Calibration

Prepare "kilogram" check weights (more than OIML M1 class) corresponding to the capacity. It is not

possible to calibrate the SPC-Solar with either "pound" or "ounce" check weight. Be sure to calibrate the

scale under battery-powered mode.

Operation Display

1 Install batteries.

Set the user parameter No. 01 (power select) at 001

(battery-powered operation)

Press and hold the key and press the key to go

to user parameter mode.

Press and hold the key and press the key to go

to calibration mode

After conrming, the stable indicator lights up, press

the key.

4 Place a check weight corresponding to the scale

capacity.

SPC - Solar 2: 2,000 grams

SPC - Solar 5: 5,000 grams

When the stable indicator lights up, press key.

If the display shows as right gures, calibration has been

completed successfully

If there is the following differences for the values in the

right gures, turn off the power and try to calibrate it

again

SPC - Solar 2: more than +/- 5 counts

SPC - Solar 5: more than +/- 10 counts

After calibration, turn off the power. Turn on the power

again and conrm that correct weight value is displayed

Capacity 2 kg

Capacity 5 kg

YCO-130607

SPC - Solar Operation Manual

Error Messages

When one of the following error messages appears on the display, follow the troubleshooting instructions.

Contact the retailer from which the product was purchased, if other messages than the following appear,

or an error is not recovered after following the troubleshooting.

Display Cause Troubleshooting

Out of batteries

Batteries are running out. Replace all of the batteries

with new one. Do not use old

and new batteries or alkaline

and magnesium batteries at

a time.

The weight below zero

This message appears when

the weighed value is less

than - 5 divisions (- 5 g for the

weighing capacity of 2000 g).

Press the key.

If the pan has been removed,

set it on the scale again.

Overloading

This message appears when

the weighed value is over

+5 divisions (2010g for the

weighing capacity of 2000g).

When the item is removed,

the display returns to the

weighing screen. Make sure

to use the scale within the

capacity.

The initial error (A)

Turned on the scale while a

heavy item was placed

Remove the item from the

pan, and then press the

key

The initial error (B)

Turn on the scale while a

foreign material was stuck

between the main body and

the pan

Check if a foreign material is

not stuck or does not contact

the pan. Then press the

key.

The initial error (C)

Pressed the key while a

heavy item was on the pan in

the middle of the operation

The weight of the item is

beyond the level where the

key is operative.Remove

the item from the pan, and

then press the key.

The initial error (D)

Turned on the scale while

the item was left on a pan.

Remove the item and press

the key

Make sure that nothing is left

on the pan and turn on the

scale again.

YCO-130607

SPC - Solar Operation Manual

Wiring Diagram

YCO-130607

SPC - Solar Operation Manual

Parts List

YCO-130607

SPC - Solar Operation Manual

Parts List

Item Part # Description Qty / Unit

1 63910024 Platform Cover, S.S. 1

2 63910028 Plate, Platform Support 1

3 63910025 Cushion Rubber 4

4 63910020 Upper Housing 1

563910102 Load cell + PCB Assembly, 2 kg 1

63910103 Load cell + PCB Assembly, 5 kg 1

6 63911031 Battery Box 1

7 63900031 Battery Box Holder 1

8 63900032 Battery Lid with sponge 1

9 63900023 Holding Plate / CPU Board 1

10 63901034 Solar Panel 2

11 63900037 Membrane Key Switch 1

12 63900035 Front Mask, SPC - Solar 2 1

63910036 Front Mask, SPC - Solar 5 1

13 63910034 Solar Glass 2

14 63910033 Display Glass 1

15 63910021 Base 1

16 63910022 Rubber Foot 4

17,18,20,23,25 63911001 Hex Bolt & SW, M3X6, S.S. 17

19 63911002 Screw & Washer, M2X6 / Battery Box 2

21 63911003 Hex Bolt, M4X8, S.S. / Battery Lid 2

22 63911004 Screw & Washer, M3X6 / CPU Board 4

24 63911005 Hex Nut M4 / Rubber Foot 4

YCO-130607

SPC - Solar Operation Manual

YAMATO CORPORATION

1775 S. Murray Blvd.

Colorado Springs, CO 80916 USA

Tel (719) 591-1500 Fax (719) 591-1045

YAMATO TECH CORPORATION

#112-19425 Langley By-Pass

Surrey, B.C. V3S 6K1 Canada

Tel (604) 533-2338 Fax (604) 533-0827

www.YamatoCorp.com
