PPC-200W Technical Manual

YCO-1049-02-03

YAMATO CORPORATION

1775 S. Murray Blvd.

Colorado Springs, CO 80916 USA

Tel (719) 591-1500 Fax (719) 591-1045

YAMATO TECH CORPORATION

#112-19425 Langley By-Pass

Surrey, B.C. V3S 6K1 Canada

Tel (604) 533-2338 Fax (604) 533-0827

YCO-1049-02-03

PPC-200W Technical Manual

Table of Contents

Before using the scale, carefully read, understand and follow the “Safety Instructions” described in this manual. Observe the advice given

in the “Operations” section to ensure proper operation. Keep this operation manual handy for reference.

1) This scale is not an explosion-proof model. Do not use the scale in an atmosphere containing ﬂammable gases or explosive fumes. A

ﬁre or an explosion can result.

2) Do not operate the scale if there is smoke or a burned smell coming from the scale. Unplug the scale immediately. After making sure that

there is no danger, consult your dealer. Never try to repair the scale by yourself.

3) Never step on or sit on the scale. Not only will the scale be damaged, but you may also be injured.

4) Place the item to be weighed in the center of the platform. Items placed on the edge of the platform may fall off and cause injury.

5) When weighing a heavy, large or unbalanced item, make sure the item is stable on the platform, otherwise, an accident may occur.

6) When carrying or moving the scale, be sure to hold it by the bottom of the base with both hands. If you hold it by the platform, the plat-

form or the platform support may become detached causing the scale to fall. This will damage the scale. The platform is designed for

easy removal and cleanup.

7) Do not insert your ﬁnger into the gaps or holes in the scale. You may be injured.

SAFETY INSTRUCTIONS

I. Introduction 1

II. Set-up Procedures 1

A. User Mode 1

B. Test Mode 2

C. System Parameter Mode 3

D. Calibration Mode 4

E. Factory Parameter Mode 5

III. Troubleshooting 6

IV. Parameter Lists 7

A. User Parameters 7

B. System Parameters 8

C. Factory Parameters 8

D. Standard Factory Parameter Settings 11

V. Wiring Diagram 14

VI. Parts List 15

YCO-1049-02-03

PPC-200W Technical Manual

I Introduction

The PPC-200W is available in four capacities. It displays units of either kilograms and one of the fol-

lowing three: continuous pounds, continuous ounces, or pounds and ounces. The speciﬁcations for

each capacity are in the following table.

Additional speciﬁcations are provided in the operator’s manual. It is important to note that various fac-

tory parameter settings depend upon the mode (continuous pound, continuous ounce, or pound and

ounce) option selected when the scale was purchased. See section IV.D for the standard settings

for each mode.

The PPC-200W is not washdown with the optional AC adaptor or the analog meter.

Remove the batteries when operating the scale with the AC adaptor. Use only the AC adaptor supplied

or an adaptor of the same output characteristics.

Capacity Increment Accuracy Maximum Tare

4 lb 2 kg 0.002 lb 0.001 kg 0.002 lb 0.001 kg 3.990 lb 1.995 kg

10 lb 4 kg 0.005 lb 0.002 kg 0.005 lb 0.002 kg 9.975 lb 3.990 kg

20 lb 10 kg 0.01 lb 0.005 kg 0.01 lb 0.005 kg 19.95 lb 9.975 kg

40 lb 20 kg 0.02 lb 0.01 kg 0.02 lb 0.01 kg 39.90 lb 19.95 kg

II Set-up Procedures

1. Turn scale on. Press and to enter User Parameter

Mode. The scale will indicate a keyword followed by it’s value.

2. To select the desired keyword, use the keys as follows:

- increase keyword by one

+ - decrease keyword by one

Note: Use the User Parameter List in Section VII to locate the

function to be changed and it’s standard value.

Example: To select lb/kg priority at power on press

nine times.

3. To change a parameter value, use the keys as follows:

- increase value by one

+ - increase value by ten

- decrease value by one

II.A User Mode

Keyword Parameter Value

YCO-1049-02-03

PPC-200W Technical Manual

II.B Test Mode

II Set-up Procedures

1. Remove the scale platform.

2. Remove the ﬁve screws and one lead wire seal screw from the

undercarriage of the scale.

3. Gently lift and remove the scale cover and replace the scale plat-

form.

4. Turn the scale on and short the two “TEST” jumpers on the left of

the PCB above the LCD.

5. Once the scale is in Test Mode, the display can be rotated through

the following functions by pressing :

Internal Count

Initial Count

Direct Raw Count

Average Raw Count

Battery Check, A/D Conversion

ROM Version

Display Segment Check

6. Exit Test Mode by pressing .

+ - decrease value by ten

4. Press to save changes and press to exit User

parameter.

I Set-Up Procedures

II.A User Mode (con’t)

YCO-1049-02-03

PPC-200W Technical Manual

II Set-up Procedures

II.C System Parameter Mode

1. Enter Test Mode (see section II.A for details.)

2. Press and to enter System Parameter Mode. The

scale will indicate a keyword followed by it’s value.

3. To select the desired keyword, use the keys as follows:

- increase keyword by one

+ - decrease keyword by one

Note: Use the System Parameter List in Section IV.B to locate

the function to be changed and it’s standard value.

Example: To select zero tracking time press eight

times.

4. User parameters are also set in the System Parameter Mode.

Press to cycle through system keywords 30 through 40.

After system keyword 40, user keyword 01 is displayed. Pressing

will continue to cycle through user keywords 01 through 09

and then return to system keyword 30.

Note: Use the User Parameter List in Section IV.A to locate the

function to be changed and it’s standard value.

5. To change a parameter value, use the keys as follows:

- increase value by one

+ - increase value by ten

- decrease value by one

+ - decrease value by ten

Keyword Parameter Value

YCO-1049-02-03

PPC-200W Technical Manual

II Set-up Procedures

II.C System Parameter Mode

6. Press to save a change and to progess to the next keyword.

7. Press and to return to test mode, or press then

to return to normal operating mode.

II.D Calibration Mode

1. Enter Test Mode (see section II.A for details.)

2. Press and to enter Calibration Mode. The scale will

indicate three-point or two-point span adjustment mode and the

fraction (i.e. - 0/2, 1/2 or 2/2 for three-point) of full-scale, in kilo-

grams, that should be placed on the platform.

3. If the scale is in two-point span adjustment mode, press to

enter three-point mode.

4. Clear the platform and press .

5. Place one-half of the full scale weight (in kilograms) on the plat-

form.

Example: If the scale capacity is 5 kg/10 lb, place 2500 g on the

platform.

6. Press .

7. Add sufﬁcient weight to the platform to bring the total to the full-

scale weight in kilograms.

Example: If the scale capacity is 5 kg/10 lb, place an-

other 2500 g on the platform for a total of 5 kg.

YCO-1049-02-03

PPC-200W Technical Manual

8. Press to save the new calibration points and return

to Test Mode. Internal counts should read 20000 +/- 3.

9. Press at any time in the span-adjustment to exit to

Test Mode without saving any new calibration points.

10. Press then to return to normal operating

mode.

II Set-up Procedures

II.D Calibration Mode

II.E Factory Parameter Mode

1. Enter Test Mode (see section II.A for details.)

2. Enter Calibration Mode (see section II.C for details.)

3. Press and to enter Factory Parameter Mode.

The steps are the same as in System Parameter Mode

(see Section II.B) with the exception that the keywords

progress from 51 through 99.

Note: Use the Factory Parameter List in Section IV.C

to locate the function to be changed. Use the Standard

Factory Parameter Settings List in Section IV.D to de-

termine the appropriate parameter value to enter.

YCO-1049-02-03

PPC-200W Technical Manual

III Troubleshooting

Problem

The scale will not power on.

The display continues to ﬂash

all 8s after the scale is turned

on.

“-----H” appears upon power up.

“-----L” appears upon power up.

The displayed weight ﬂuctuates

excessively.

Possible Cause

Batteries dead or incorrectly

installed.

AC adapter loose or malfunc-

tioning.

CPU board malfunction.

Vibration or an unstable po-

sition or platform.

Platform weight too high.

Platform weight too low.

Material between the platform

and the scale body.

Weighing assembly in contact

with wires or case.

Load cell connector loose or

damaged.

Power board malfunction.

CPU board malfunction.

Solution

Test batteries. Reinstall if

needed.

Reseat adapter. Replace if

needed.

Replace CPU board.

Remove source of vibra-

tion or place scale on stable

platform.

Clear platform and restart.

Remove platform, clear

away any debris and rein-

stall platform.

Remove material.

Reposition wires, case or

platform.

Reconnect or replace the

load cell connector.

Replace power board.

Replace CPU board.

YCO-1049-02-03

PPC-200W Technical Manual

IV Parameter Lists

IV.A User Parameters

Key Std Function Description

Word Value

01 015 Auto-off timer 000 Disables auto-off.

001~240 Number of minutes unused to activate auto-off.

02 000 Display hold timer 000 No display hold for changes less than four divisions.

001~030 Display hold duration, in seconds, for changes less

than four divisions.

031 No display hold.

03 001 Communication 000 No serial interface.

001 Speciﬁed commands acceptable.

002 Sends zero detection.

003 Sends motion detection.

004 Sends continuously.

04 000 Communication data 000 Net weight (1 batch)

001 Net weight, tare weight, gross weight (1 batch)

002 Net weight, tare weight, gross weight (3 batches)

003 Display content (1 batch)

004 Serial printer format (1 batch)

05 000 Communication speed 000 9600 bps

001 600 bps

002 1200 bps

003 2400 bps

004 4800 bps

005 9600 bps

006 19200 bps

007 38400 bps

06 000 Character length 000 8 bits

001 7 bits

07 002 Parity 000 Non

001 Odd

002 Even

08 001 Stop bit length 000 1 bit

001 2 bits

09 001 Default mode 000 kg

001 lb/oz

YCO-1049-02-03

PPC-200W Technical Manual

IV Parameter Lists

IV.B System Parameters

IV.C Factory Parameters

Key Std Function Description

Word Value

30 018 System ID 018 Do not change.

31 010 Gravity compensation 000 No compensation.

001~016 Compensation for a speciﬁed area (Japan only.)

017~150 Acceleration due to gravity formula, (mm/s2 )-9700.

32 000 Linearity compensation 000 No compensation.

001~127 Positive compensation.

128~255 Negative compensation.

33 004 Steady-state sampling count 000~255

34 012 Steady-state count 000~255

35 008 Polarity steady-state count 000~255

36 020 Steady-state collapse count 000~255

37 004 Steady-state average count 000~255

38 010 Zero tracking timing 000 Disable zero tracking

001~255 Zero tracking at speciﬁed counts

39 001 Neglectable change count 000~010 Number of counts

40 000 Simple test mode 000 User parameter valid

001 User parameter invalid

002 User parameter and simple test mode valid

Key Function Description

Word

51 Scale mode 000 Fixed single increment.

001 Multi-increments.

002 Do not use.

003 Do not use.

004 Change-over / gram mode - decimal pound mode.

005 Change-over / gram mode - lb/oz mode.

006 lb/oz mode.

007 Change-over / gram mode - continuous ounce mode.

52 Multi-increments, 000 Fixed single increment.

complex increment mode 001 Fixed accuracy, 3 increments.

002 Fixed accuracy, 2 increments.

003 Increment change at 50% full scale, 2 increments.

004 Increment change at 80% full scale, 2 increments.

005 Increment change at 64% full scale, 2 increments.

006 Increment change at 40% full scale, 2 increments.

53 Weighing capacity base value 000~099

54 Weighing capacity index value 001~004

55 Increment for lighter range 000 1

001 2

002 5

003 10

004 20

005 50

006 100

007 200

Table des matières

Autres manuels Yamato Échelle

Yamato

Yamato BC-10 Manuel utilisateur

Yamato

Yamato BC-10 Manuel utilisateur

Yamato

Yamato PPC-300WP Manuel utilisateur

Yamato

Yamato AW-WPS Manuel utilisateur

Yamato

Yamato SPC - Solar Manuel utilisateur

Yamato

Yamato DSR-400 Manuel utilisateur

Yamato

Yamato AW-WLG Series Manuel utilisateur

Yamato

Yamato Accu-weigh PPC-200W Manuel utilisateur

Yamato

Yamato CPC-2000 Manuel utilisateur

Yamato

Yamato DSR-200 Manuel utilisateur

Yamato

Yamato DSY-1100 Manuel utilisateur

Yamato

Yamato DP-6900 Manuel utilisateur

Yamato

Yamato DP-5602 Manuel utilisateur

Yamato

Yamato DP-6100GP Manuel utilisateur

Yamato

Yamato DSR-400 Manuel utilisateur

Yamato

Yamato Just NAVI J-101W Manuel utilisateur

Yamato

Yamato PPC-200 Manuel utilisateur

Yamato

Yamato DP-6200 Manuel utilisateur

Yamato

Yamato Accu-weigh PPC-200 Manuel utilisateur

Yamato

Yamato CPC-2000 Manuel utilisateur

Yamato

Yamato PPC-101 Manuel utilisateur

Yamato

Yamato DKS-3002 Manuel utilisateur

Yamato

Yamato DP-6900 Manuel utilisateur

Yamato

Yamato SPC Series Manuel utilisateur

Manuels Échelle populaires d'autres marques

AWS

AWS ZEO-50 Manuel utilisateur

Gima

Gima Glass Body Fat Analyzer Manuel de la liste des pièces

Seca

Seca 374 Manuel utilisateur

TEC

TEC TEC SL59 SERIES Manuel utilisateur

Axis

Axis B/E Series Manuel utilisateur

Alecto

Alecto ACW-40 Manuel utilisateur

Rice Lake

Rice Lake MSI-4260 IS Manuel utilisateur

IKA

IKA RCT basic safety control Manuel utilisateur

ADE

ADE M20011 Manuel utilisateur

Duronic

Duronic KS3000 Manuel utilisateur

Digi

Digi SM-720 Manuel utilisateur

Cardinal

Cardinal CS Series Manuel utilisateur

Korona

Korona Kastella Manuel utilisateur

A&D

A&D FC-50Ki Manuel utilisateur

BDA

BDA CAMARGUE Manuel utilisateur

Tanita

Tanita HD-357 Manuel utilisateur

Leifheit

Leifheit 03173 Manuel utilisateur

Lumme

Lumme LU-1340 Manuel utilisateur
