Yamaha NS-AW194BL Manuel utilisateur

NS-AW294 NS-AW194

High performance outdoor speakers with outstanding sound quality and weatherproofing.

The simple design allows them to be installed in many types of locations.

NS-AW Series

•

High Sound Quality

Yamaha’s advanced speaker design combines superior sound quality with excellent weatherproofing

Two-way bass reflex design

- Powerful woofer delivers accurate mid/low frequency response

- Balanced dome tweeter ensures clear high frequency response

Excellent audio performance, weatherproof cabinets that are drip, water and UV resistant

Convenient Design

Simple design looks natural on a home exterior, on a patio or inside a room

Two sizes and two color variations allows you to choose the best match in various installations

Flexible installation options with supplied mounting brackets

Powder-coated grilles provide outstanding weatherproof properties

Push type speaker terminals for easy installation

Surface Mount Speakers

Convenient Design and Features

Simple, Elegant Design

These speakers have a clean, simple design that will look attractive in any location on

the exterior of your house, and even present a tasteful appearance when used in an

interior installation.

Two sizes, Two Colors

Available in two types and in white or black, you can choose the model that best

matches your desired exterior or interior installation location.

Wide Range of Installation Possibilities

The supplied brackets allow you to adjust the speakers to match the installation

location. They can be installed vertically or horizontally, and can be moved through a

range of 81° to the right or left and up or down directions.

NS-AW294

GENERAL SPECIFICATIONS

Type

Woofer

Tweeter

Frequency Response

Nominal Input Power

Maximum Input Power

Sensitivity

Waterproof Characteristics

Cabinet

Movable angle

Grille

Speaker Terminals

Impedance

Dimensions (W x H x D)

Weight

Included accessories

Packaging

2-way bass-reflex

6-1/2" (16cm) waterproof cone

1" (2.5cm) fluid-cooled, coated balanced dome

80 Hz–20 kHz

50 W

100 W

87 dB/2.83 V/1 m

IPx3

HIPS

81° (degree pitch:13.5°)

Powder coated iron

Push-type

8 ohms

7-1/2” x 12-1/8” x 8-1/2”

190 x 308 x 217 mm

4.4 lbs.; 2 kg/unit

U-bracket, Retaining kob

Packaged in pair

DIMENSIONS

unit : mm

• Product designs and specifications are subject to change without notice.

NS-AW194

GENERAL SPECIFICATIONS

Type

Woofer

Tweeter

Frequency Response

Nominal Input Power

Maximum Input Power

Sensitivity

Waterproof Characteristics

Cabinet

Movable angle

Grille

Speaker Terminals

Impedance

Dimensions (W x H x D)

Weight

Included accessories

Packaging

2-way bass-reflex

4" (10cm) waterproof cone

1" (2.5cm) fluid-cooled, coated balanced dome

100 Hz–20 kHz

30 W

80 W

85 dB/2.83 V/1 m

IPx3

HIPS

81° (degree pitch:13.5°)

Powder coated iron

Push-type

8 ohms

6” x 9-5/8” x 6-3/4”

152 x 243 x 171 mm

2.9 lbs.; 1.3 kg/unit

U-bracket, Retaining kob

Packaged in pair

DIMENSIONS

unit : mm

• Product designs and specifications are subject to change without notice.

168

209.2

169.5 372.7

244

239.8 2.12.1

138

118

263.7

215 46

198

178

228 60

2.7
