QUICK-CONNECT GUIDE

YHT-500

just add your TV

YHT-500 QUICK-CONNECT GUIDE

INTRODUCTION

Yamaha developed the YHT-500 A/V Home Theater

package to turn your home into a theater. In addition to

enhancing the sound of a video source, like your TV,

DVD, or VCR, the YHT-500 also superbly reproduces

audio sources, such as a CD player or a cassette deck.

This Quick-Connect Guide will help you get started.

Study the speaker system plan (below), and then use

the interconnect diagrams (on the following pages) to

connect the receiver and speakers to your system.

For the video portion, you will need a television or monitor.

Refer to the Yamaha HTR-5540 Ownerís Manual , as well as

those that came with your other components, for comp-

lete instructions and cautions. Be sure to turn off all

power while making connections.

Save this Quick-Connect Guide for future reference.

NOTE: Label the end of each speaker wire (i.e., left rear, right

front, etc.) before connecting them to the A/V receiver. For wire

runs over 30 feet, use larger 18- or 16-gauge speaker wire.

∑Wire strippers (optional)

∑Brackets, toggle bolts, molly anchor screws, or sheet

metal screws (for securing NS-A329 speakers to 

walls)

NOTE: If you are unsure of how to securely and safely fasten

speakers to a wall, please contact a reliable source about the best

type of hardware for your particular wall's construction.

Secure installation is the purchaser's responsibility.

TOOLS AND PARTS

SPEAKER SYSTEM PLAN

NS-A329

(left side, same height as TV)

NS-A329

(right side, same height as TV)

L = Left Channel

R = Right Channel

C = Center Channel

S = Surround Channel

NS-A329

(on stand or wall, at least

ear level or preferably higher)

NS-A329

(on stand or wall, at least

ear level or preferably higher)

8'~10' apart

NS-AC329

(on top or below TV)

6'~8' apart

Couch

Listening Area

Sub

YST-SW005 Subwoofer (on floor)

The YHT-500 Home Theater package consists of

(1) HTR-5540 A/V receiver with (1) remote control,

DV-S5450 DVD Player with (1) remote control, (4) 2-

way NS-A329 front/rear speakers, (1) NS-AC329

2-way center-channel speaker (includes factory

installed rubber feet), (1) 100' of bulk speaker

speaker wire, (1) 0.5m optical cable,(1) 10' RCA

audio cable, (1) YST-SW005 Powered Subwoofer,

and related owner's manuals. You will also need:

DIGITAL

INPUT 6CH INPUT AUDIO

TUNER

ANT

GND

75UNBAL.

VIDEO

MONITOR

OUT

COAXIAL

OPTICAL

DVD

VCR

OUT

D-TV

/CBL

/CD-R

(PLAY)

V-AUX

SUB

WOOFER

SUB

WOOFER

SURROUND

CENTER

MAIN

OUT

(REC)

OUTPUTAUDIO

SWITCHED

120V 60Hz

0.8A MAX. TOTAL

100W MAX. TOTAL

AC OUTLETS

SET BEFORE POWER ON

MAIN

: 8

MIN. /SPEAKER

CENTER

: 8

MIN. /SPEAKER

REAR

: 8

MIN. /SPEAKER

MAIN

: 4

MIN. /SPEAKER

CENTER

: 6

MIN. /SPEAKER

REAR

: 6

MIN. /SPEAKER

SPEAKERS

IMPEDANCE SELECTOR

MAIN REAR

(SURROUND)

CENTER
