Yamaha RY8 Manuel utilisateur
I
IMPORTANT ! PLEASE READ BEFORE PROCEEDING !
The RY8 is a powerful electronic music device featuring sensitive high
technology. To ensure many years of trouble-free use, please take the
important precautions below seriously.
LOCATION
■In order to avoid causing serious damage to the RY8, do not expose the
instrument to direct sunlight, high temperatures, excessive humidity,
excessive dust or strong vibration.
POWER SUPPLY
■Turn the power switch off when the RY8 is not in use.
■The AC power adaptor should be unplugged from the AC outlet if the RY8
is not to be used for an extended period of time.
■Unplug the RY8 during electrical storms.
■Avoid plugging the RY8 into the same AC outlet as appliances with high
power consumption such as electric heaters or ovens. Also, avoid using
multiple-plug adaptors, since these can result in reduced sound quality and
possibly even damage to the RY8.
TURN OFF POWER WHEN MAKING CONNECTIONS
■To avoid causing damage to the RY8 and other devices to which it is
connected (such as a sound system or MIDI instruments), turn off the
power of all related devices prior to connecting or disconnecting audio and
MIDI cables.
ELECTRICAL INTERFERENCE
■Avoid using the RY8 near televisions, radios or other devices which
generate electromagnetic fields, since this may cause the RY8 to malfunction,
and may possibly generate interference noise in the other devices.
PRECOTION.QX99.11.176:47PMページI
PRECAUTIONS
II
HANDLING AND TRANSPORT
■Handle the RY8 with care. Physical shocks caused by dropping or jostling
the instrument, or placing heavy objects upon it, can result in serious damage
to the RY8.
■Never apply excessive force to the controls, pads, or connectors of the
instrument.
■Disconnect all cables before moving the instrument. Always unplug cables
by gripping the plug firmly, and not by pulling on the cable itself.
CLEANING
■Never use chemical solvents or thinners to clean the RY8, since these will
damage the finish or the rubber pads. Wipe the instrument clean with a soft,
dry cloth. If necessary, use a soft, clean cloth slightly moistened with a
diluted, mild detergent. Then wipe the instrument thoroughly with a dry cloth.
Avoid placing vinyl objects on the top of the instrument. Vinyl can stick to and
discolor the surface.
DATA BACK-UP AND STORAGE
■Yamaha recommends that you regularly save your music data using an
external MIDI data storage device (such as the Yamaha MDF2 MIDI Data
Filer), and storing the floppy disks in a safe, cool, dry place. YAMAHA
CANNOT BE HELD RESPONSIBLE FOR THE ACCIDENTAL LOSS OF
IMPORTANT MUSIC DATA! Regarding the User memory, as long as fresh
batteries are inserted in (or an AC power adaptor is connected to) the RY8, the
User pattern, song and drum kit data will be retained, even when the power is
turned off. It will also be retained long enough to exchange an old set of
batteries for a new set. If you have important data in the RY8 which you don’t
want to lose, please take care to keep fresh batteries inserted in (or keep an
AC power adaptor connected to) the RY8, and to regularly save it to an
external MIDI data storage device.
SERVICE AND MODIFICATION
■The RY8 contains no user serviceable parts, so never open the case
or tamper with the internal circuitry in any way. Doing so may result in
electrical shock or damage to the instrument. Refer all servicing to
qualified Yamaha service personnel.
YAMAHA CANNOT BE HELD RESPONSIBLE FOR DAMAGE TO THE RY8
RESULTING FROM IMPROPER HANDLING OR OPERATION !
PRECOTION.QX99.11.176:47PMページII
THANK YOU FOR PURCHASING
THE YAMAHA RY8 RHYTHM PROGRAMMER.
The Yamaha RY8 is a full-featured, high quality, low-priced, hand-held stereo
rhythm programmer with accompaniment backing and guitar input that’s the
perfect “pocket pal” for the guitarist on the go.
With its compact size, friendly user interface, wide variety of preprogrammed
patterns and songs, user programming capabilities, versatile MIDI features and
more, the handy RY8—which easily slips into a guitar case or gig bag—is
ready to plug and play anytime and anywhere. It’s the ideal music practicing
companion and composing sketch pad.
Whether you’re a professional or amateur guitarist, a serious songwriter or
simply a music hobbyist, you’ll find the RY8 a unique and powerful addition to
your arsenal of music tools. You’ll be surprised by its full, dynamic stereo
sound quality when played through a high quality audio monitoring system.
You’ll also appreciate being able to plug in a guitar and headphones and work
in privacy without disturbing others—or better yet, without others disturbing
you!
To take full advantage of the RY8’s many features and music making
capabilities, please read this owner’s manual carefully to familiarize yourself
with the proper operating procedures. Also, keep this manual in a safe place
for future reference.
III
PRECOTION.QX99.11.176:47PMページIII
IV
CONVENTIONS USED IN THIS MANUAL.
In order to keep confusion to a minimum, there are a few basic conventions
used in the feature explanations in this manual, as follows:
■Names of key features are written in the cap-low style; e.g., Pattern Mode,
Song Record Mode, System Mode Sync function, User patterns, etc.
■Names of controls and connectors are written in all-caps within brackets;
e.g., [EXT IN] jack, [VOLUME] slider, [DELETE] button, etc.
■Special prompts or words which appear on the LCD screen during operation
are written in quotes; e.g., “NEXT”, “CHAIN”, “accnt”, “COPY SURE?”, etc.
■Everything else will be written in the lower case style.
PLEASE KEEP THIS MANUAL IN A SAFE PLACE FOR FUTURE
PRECOTION.QX99.11.176:47PMページIV
V
HOW TO USE THIS MANUAL.
The RY8 Owner’s Manual is designed to travel alongside the RY8 itself. It
includes information about all the RY8’s features and operation procedures,
organized in such a way as to permit quick and easy access to any feature you
need to locate. The main sections of the Owner’s Manual are as follows:
A brief overview of the RY8’s capabilities and system structure, as well as
descriptions of all panel features—everything you need to know before you
begin using the RY8 in order to put its many features and capabilities into
proper context.
A step-by-step guide through setting up the RY8, turning on the power, playing
the demo songs and performing basic pattern, song and drum kit operations—
everything you need to get started enjoying the RY8 right away.
An extensive feature reference of the various modes and functions of the
RY8—everything you need to know about all operating procedures.
A collection of technical charts and lists including display messages,
troubleshooting, drum voice and pattern lists, MIDI implementation chart and
more.
An alphabetical list of topics which gives you quick and easy access to any
subject in the manual you want to locate.
PRECOTION.QX99.11.176:47PMページV
BEFORE YOU BEGIN
GETTING STARTED
MODES & FUNCTIONS
APPENDIX
INDEX
1
REFERENCE !
..............................................................................................................2
1. THE RY8......................................................................2
2. RY8 SYSTEM STRUCTURE.......................................4
3. TOP PANEL.................................................................7
4. SIDE & REAR PANELS.............................................10
..............................................................12
5. SETUP & POWER-ON..............................................12
6. PLAYING THE DEMO SONG....................................18
7. PLAYING THE DRUM PADS ....................................19
8. PLAYING THE PRESET PATTERNS .......................21
9. PLAYING THE PRESET SONGS..............................26
....................................................30
10. PATTERN MODE....................................................30
11. SONG MODE ..........................................................41
12. DRUM KIT MODE....................................................54
13. EXTERNAL IN MODE .............................................61
14. SYSTEM MODE......................................................67
15. TEMPO MODE........................................................73
16. MUTE MODE...........................................................74
17. BALANCE MODE....................................................75
18. TRANSPOSE MODE...............................................76
................................................................................77
19. RECALLING THE FACTORY
DEFAULT SETTINGS.............................................77
20. DISPLAY MESSAGES ............................................78
21. TROUBLESHOOTING.............................................79
22. SPECIFICATIONS...................................................81
23. LISTS & CHARTS....................................................82
..........................................................................................94
PRECOTION.QX99.11.176:47PMページ1
TABLE OF CONTENTS
BEFORE YOU BEGIN
GETTING STARTED
MODES & FUNCTIONS
APPENDIX
INDEX
2
1. THE RY8
The RY8 is an easy-to-use yet powerful rhythm programmer with automatic
bass and chord accompaniment backing, an external input for playing along
using a guitar, versatile MIDI capabilities and much more.
Featuring Yamaha’s exclusive AWM (Advanced Wave Memory) tone
generation technology—where voices are high quality digital samples of actual
instruments—the RY8 has a large capacity waveform ROM filled with 128
“drum” voices for the rhythms, and 50 “normal” voices for the backings, plus
200 Preset rhythm patterns with matching accompaniment backing
encompassing many different popular music styles, and 50 Preset songs and
12 Preset drum kits suitable for any type of music situation. The RY8 also
features powerful programming capabilities that let you do the following:
Create Your Own Rhythm Patterns
Record your own one-measure User patterns in step-time or real-time. You can
assign any of the preprogrammed backing accompaniments—consisting of
Bass, Chord 1 and Chord 2 tracks—to your rhythm.
Create Your Own Songs
String together a series of Preset and User patterns to create your own User
song—complete with chord progressions as you specify.
Create Your Own Drum Kits
Assign drum voice sounds to the pads to create your own User drum kits—
complete with drum voice pan positioning, pitch tuning and more.
PRECOTION.QX99.11.176:47PMページ2
