AES820 D6

SERVICE MANUAL

EG 011619

ELECTRIC GUITAR

HAMAMATSU, JAPAN

CONTENTS

PARTS LIST.............................................................................. 2

SPECIFICATIONS..................................................................... 2

This document is printed on chlorine free (ECF) paper with soy ink.

0.768K-66 Printed in Japan ’02.01

The AES820 D6 service manual provides a listing of

only the differences as compared with the AES820.You

must have a AES820 service manual (EG 011618 )

before servicing this unit.

WARNING : CHEMICAL CONTENT NOTICE!

The solder used in the production of this product contains LEAD.In addition, other electrical/

electronic and/or plastic (Where applicable) components may also contain traces of chemicals

found by the California Health andWelfare Agency (and possibly other entities) to cause cancer

and/or birth defects or other reproductive harm.

DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS INYOUR

MOUTH FOR ANY REASON WHAT SO EVER!

Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not

inhale solder fumes or expose eyes to solder/flux vapor!

If you come in contact with solder or components located inside the enclosure of this product,

wash your hands before handling food.

AES820 D6

PARTS LIST

REF NO.

PART NO. DESCRIPTION REMARKS

QTY

: New Parts RANK: Japan only

RANK

OVERALL ASSEMBLY AES820 D6

A01 Neck Assembly (BL)

A01a Seal (QC66520)

E34 Strings D’addario #59200 1set (QC59200)

AAX33290

SPECIFICATIONS

STANDARD SPECIFICATIONS

Scale Length.............................. 666.8mm

Body-Neck Construction ......... Bolt On

Length........................................ 1033.8mm

Width ......................................... 343.6mm

Net Weight ................................ 3.7kg

COLOR

Body

BL ............................................. Black

LBM .........................................Light Brown Metallic

FLB........................................... Flat Blue

Neck

BL ............................................. Black

BODY

Material...................................... Alder

Body Depth ............................... 44mm

FINGERBOARD

Material...................................... Rose

Fingerboard Width...................0-F 44.0mm, 12-F 52.5mm

No. of Frets................................ 24

NECK

Material...................................... Maple

Neck Thickness ........................ 1-F 21.9mm, 12-F 23.9mm

PARTS

Hardware ................................... Chrome Plated

Nut.............................................. Urea

Bridge ........................................Ping Well: TP6-05Y (Chrome)

Strings........................................ D’addario: #59200

CONTROLS

Volume ....................................... 15A 500KΩx 2

Rotary Switch............................2 pole 3 position

Pickup Switch............................ 3 position Toggle Switch

PICKUPS

Front/Rear ................................ Humbucking

Magnet

Front/Rear .............................. Ferrite
