Yamaha EF2000iSv2 Manuel utilisateur

Howtoproperlyconnect2EF2000iSv2

InstructionsvalidregardlessofTwinTechCablemodel

TwinTech

(TerminalforConnectingcablesforparallelOperation)

•ThisistheterminalforconnectingTwinTech cablesfor

parallelrunningoftwoEF2000iS.Theparallelrunning

requirestwoEF2000iSv2andtheTwinTech cables.(The

ratedoutputinparallelrunningis25amps)Maxoutput

isupto30amps.

•Thehandling,operationprocedureandthenoteson

usagearedescribedinthePARALLELRUNNINGKIT

OWNER’SMANUALincludedintheParallelRunning

Kit.

PriortostartingtheGenerators

•BothGeneratorsmustbeoff,allplugsorcordsremovedfromany

outputoutletbeforeconnectingwithparallelcables.

IncorrectIncorrect

Correct!

Connecttheparallelplugsintothegenerator

1. Securelyplugtheconnectorplugsoftheparallelcordintothe

connectorsocketsoneachgenerator.

2. Theconnectorplugscanbeconnectedinanyorder.Itdoesnot

matterwhichsockettheWhiteorBlackconnectorconnectsto.

3. Attachthegreengroundwiretothegroundterminaloneach

generator

StartoneoftheGenerators

•Thiswillbetheprimarygenerator.

•VerifytheGreenACPilotlightisilluminatedandthegeneratoris

functioningproperly

•TheACpilotlightofthenon‐runninggenerator(secondaryunit)will

illuminateonlyafterthefirstgeneratorsensesthesecondoneis

connectedproperly

Primary Generator

StarttheSecondaryGenerator

•Oncethesecondarygeneratorisrunningplugthe30Ampcord

leadingtotheRVordeviceintotheTwinTech 30Amp

receptacle/outletattachedtothehandleoftheprimarygenerator.

•Nodevices/appliancesshouldbeturnedonatthispoint

Primary Generator Secondary Generator

Powershouldnowbeavailable

•Ifthesestepsarefollowedcorrectly,thenpowershouldflowintothe

RVordevicebeingpowered

•ThePrimaryGeneratorwillrevuptohandletheinitialpower

demand.Thesecondarygeneratorwilladdpowerasneeded.Thiswill

beaudiblynoticeable.

Primary Generator Secondary Generator

Tipstoremember

•Donotexceedtheratedoutputofthegenerators– seetheowner’smanualforrated

output

•Theoverloadindicatorlightmaycomeonforafewsecondsatfirstwhenusingelectric

devicesthatrequirealargestartingcurrent,suchasanairconditioningunitorair

compressor

•Thehighertheelevation,thelessoxygenintheatmosphereandcancausethegenerator

tonotrunasefficiently.Re‐jetthecarburetorifnecessary.

•Hidden/vampireloads–

•TherearenumerouselectronicdevicesandequipmentinyourRVthatcandrainthecoachbattery

whenyou’renotusingtheRV.Someexamplesare;theTVantennabooster,theLPgasleak

detector,clocksinradios,orjustleavinga12‐voltlightonbyaccident.IfyourRVisnotequipped

withabatterydisconnectswitchyoucanpurchaseabatterydisconnect,fromanRVdealer,that

canbeinstalleddirectlyonthebatterypost.Whenyouaren’tusingtheRVorhaveno

requirementforthecoachbatteryyousimplyraisealeveranddisconnectthebattery.Abattery

disconnectcanbeinstalledonthechassisbatterytoo.

•UseaAMWatt metertoseewhatloadsarebeingdrawnevenbeforeconnectingthe

generatorstotheRV
