Xylem Rule Rule-Mate Manuel utilisateur

Rule-Mate

INSTRUCTION MANUAL

Manuel d’utilisation de Rule-Mate

Bedienungsanleitung für Rule-Mate

Manuale delle istruzioni per Rule-Mate

Manual de instrucciones de Rule-Mate

Användarhandledning för Rule-Mate

Handleiding Rule-Mate

DANGER: Failure to follow this instruction manual may lead to signiﬁcant property

damage or may result in serious injury or death.

About safety messages

It is extremely important that you read,understand and follow the safety messages and regulations

carefully before handling the product.They are published to help prevent these hazards:

WARNING:

• The operator must be aware of safety precautions to prevent physical injury.

• Operating, installing or maintaining the unit in any way that is not covered

in this manual could cause death, serious personal injury or damage to the

equipment.This includes any modiﬁcation to the equipment or use of parts

not provided by Xylem.If there is a question regarding the intended use of

equipment, please contactXylem representative before proceeding.

• Do not change the service application without the approval of a authorized

Xylem representative.

• Personal accidents and health problems

• Damage to the product

• Product malfunction

NOTICE: Save this manual for future reference, and keep it readily available at the

location of the unit.

SAFETY

SAFETY TERMINOLOGY AND SYMBOLS

Hazard Level:

DANGER

WARNING

CAUTION

NOTICE

Indication:

Ahazardous situationwhich,if not avoided,will result indeath orserious injury.

Ahazardous situationwhich,if not avoided,could result indeath orserious injury.

Ahazardoussituationwhich,if notavoided,could result in minorormoderateinjury.

Apotential situationwhich,if not avoided,could result in undesirable conditions.

Apracticenot relatedto personalinjury.

CAUTION: Read this manual carefully before installing, using or servicing this

product. Failure to follow the instructions within this manual could result in explosion,

property damage, severe personal injury and/or death.

ELECTRICAL HAZARD:

These are examples of other categories that can occur.They fall under the ordinary hazard

levels and may use complementing symbols:

• Crush hazard

• Cutting hazard

• Arc ﬂash hazard

General safety rules

These are safety rules apply:

• Always keep work area clean

• Pay attention to the risks presented by gas and vapors in the work area

• Avoid all electrical dangers. Pay attention to the risks of electric shock or arc ﬂash hazards

• Always bear in mind the risk of drowning, electrical accidents and burn injuries

USER SAFETY

Safety equipment

Usesafety equipmentaccording tothe companyregulations.Usethis safetyequipment withinthe workarea:

Electrical connections

Electrical connections must be made by certiﬁed electricians in compliance with all

international, national,state and local regulations. For more information about requirements,

see sections dealing speciﬁcally with electrical connections.

• Hard hat

• Safety goggles, preferably with side shields

• Protective shoes

• Protective gloves

• Gas mask

• Hearing protection

• First-aid kit

• Safety devices

NOTICE: Never operate a unit unless safety devices are installed.

Precautions before work

Observe these safety precautions before you work with the product or are in connection with the product:

• Make sure that you have a clear path of retreat

• Make sure that the product cannot roll or fall over and injure people or damage property

• Allow all system and pump components to cool before you handle them

• Make sure that the product has been thoroughly cleaned

• Disconnect and lock out power before you service the pump

Waste and emissions regulations

Observe these safety regulations regarding waste and emissions:

Wash the skin and eyes

Followtheseprocedures for chemicals or hazardousfluids thathave comeinto contactwith youreyes orskin:

• Appropriately dispose of all waste

• Handle and dispose of the processed liquid in compliance with applicable

environmental regulations

• Clean up all spills in accordance with safety and environmental procedures

• Report all environmental emissions to the appropriate authorities

ENVIRONMENTAL SAFETY

Electrical installation

For electrical installation recycling requirements, consult your local electric utility

Recycling guidelines

Always follow local laws and regulations regarding recycling

WARNING: Radiation Hazard.Do NOT send the product toXylem if it has been

exposed to any nuclear radiation

Condition

Chemicals or

hazardous ﬂuids

in eyes

Chemicals or

hazardous ﬂuids

on skin

Action

1. Hold your eyelids apart forcibly with your ﬁngers

2. Rinse the eyes with eyewash or running water for al least 15 minutes

3. Seek medical attention

1. Remove contaminated clothing

2.Wash the skin with soap and water for a least 1 minute

3. Seek medical attention, if necessary

DANGER: This product is not intended for damage control or to deal with ﬂooding result-

ing from hull damage.This product is intended to be used in Bilge Pumping Systems for small

craft with a hull length up to 79 feet (24 meters), as described within the introduction and

scope of ISO 15083. Bilge Pumping Systems,as speciﬁed in ISO 15083,are limited to normal

amounts of water in an intact boat due to spray, rain, seepage, spillage, and occasional small

amounts of watershipped fromboat movementsin heavyweather.Use of product inany other

way could result in ﬂooding, catastrophic damage to craft,serious personal injury, or death.

WARNING: This pump is designed for use with fresh water and salt water ONLY. Use with

any other hazardous, caustic,or corrosive material could result in damage to the pump and

the surrounding environment,possible exposure to hazardous substances and injury.

WARNING: Check the function of all bilge pumps at regular intervals. Clear pump

inlets from debris. If seacocks are ﬁtted in the fore and aft peak bulkheads,they shall be

kept closed and shall only be opened to let water drain into the main bilges.

Rule-Mate Intelligence

Rule-Mate Bilge pumps have built-in programming that can sense when the pump is running

but not pumping water to protect the pump, vessel, and the vessel’s batteries. If debris covers the

sensor or the pump becomes air-bound,the pump will stop running and begin to “check” for water

every 2.5 minutes. Once the debris is removed,the pump will revert to its normal operation, turn-

ing on when the water reaches approximately 2-3/4” (70mm) and shutting off at approximately

5/8” (16mm).

Our Rule-Mate bilge pumps contain a fail-safe back-up program that measures the amount of

work the motor is performing and the length of time the motor is running. If debris, such as

a wet paper towel or leaves, became lodged against the pump, it could “trick” the pump into

thinking water remained in the bilge which could deplete the vessel’s battery.

If the circuit board senses the motor is running but doing little work (not pumping water) for

longer than ﬁfteen seconds,the pump will enter into a cycling mode in the same fashion as the

computerized pumps.The pump will sense water every 2.5 minutes and if it senses water, it will

continue to run until the water has been removed from the bilge.

After the debris is removed,the pump will automatically revert to the level sensing mode.

Rated Flow Open Flow

Output @ 0ft (0m)

(0 kPa) GPH (LPH)

Open Flow

Output @ 3.35ft (1m)

(10 kPa) GPH (LPH)

Open Flow

Output @ 6.7ft (2m)

(20 kPa) GPH (LPH)

Débit nominal

Débit libre

Sortie à 0 pied (0m)

(0 kPa) GPH (LPH)

Débit libre

Sortie à 3.35 pieds (1m)

(10 kPa) GPH (LPH)

Débit libre

Sortie à 6.7 pieds (2m)

(20 kPa) GPH (LPH)

Gemessener

Durchﬂuss

Offener Durchﬂuss

Pumpleistung

bei 0m

(0kPa) GPH (LPH)

Offener Durchﬂuss

Pumpleistung bei 1m

(10kPa) GPH (LPH)

Offener Durchﬂuss

Pumpleistung bei 2m

(20kPa) GPH (LPH)

Flusso nominale

Flusso aperto

Uscita @ 0ft (0m)

(0 kPa) GPH (LPH)

Flusso aperto

Uscita @ 3.35ft (1m)

(10 kPa) GPH (LPH)

Flusso aperto

Uscita @ 6.7ft (2m)

(20 kPa) GPH (LPH)

Nominaal debiet

Open debiet

Uitvoer @ 0ft (0m)

(0 kPa) GPH (LPH)

Open debiet

Uitvoer @ 3.35ft (1m)

(10 kPa) GPH (LPH)

Open debiet

Uitvoer @ 6.7ft (2m)

(20 kPa) GPH (LPH)

Nominellt ﬂöde

Öppet ﬂöde

Effekt @ 0ft (0m)

(0 kPa) GPH (LPH)

Öppet ﬂöde

Effekt @ 102.11cm (1m)

(10 kPa) GPH (LPH)

Öppet ﬂöde

Effekt @ 204.22cm (2m)

(20 kPa) GPH (LPH)

Caudal Nominal

Caudal Abierto

Salida @ 0 pies (0 m)

(0 kPa) GPH (LPH)

Caudal Abierto

Salida @ 3.35 pies (1m)

(10 kPa) GPH (LPH)

Caudal Abierto

Salida @ 6.7 pies (2m)

(20 kPa) GPH (LPH)

1500 1500 (5678) 1200 (4542) 680 (2574)

2000 2000 (7570) 1620 (6132) 1300 (4921)

Note: Output is based on 10 hour break-in period and at 13.6V (12Vmodels) or 27.2V (24V models).

Note: Les données proviennent d’une période de rodage de 10heures et d’essais à 13,6V (modèles 12V)

ou 27,2V (modèles 24V).

Hinweis: Die Pumpleistung richtet sich nach der zehnstündigen Einlaufzeit und danach,ob 13,6V (12V-

Modelle) oder 27,2V (24V-Modelle) anliegen.

Nota bene: l’uscita è basata su un periodo di rodaggio di 10 ore a 13,6V (modelli a 12V) o 27.2V (modelli a 24V).

Opmerking: De uitvoer is gebaseerd op een inloopperiode van 10 uur en bij 13,6 V (12V-modellen) of 27,2 V

(24V-modellen).

Obs: Uteffekt baseras på en 10 timmar lång inkörsperiod med 13.6V (12V-modeller) eller 27.2V (24V-modeller).

Nota: La salida se basa en un período de reposo de 10 horas y a 13.6V (modelos de 12V) ó 27.2V (modelos de 24V).

GPH (LPH)

G/H (L/H)

G/S (L/S)

G/O (L/O)

G/U (L/U)

G/T (L/T)

G/H (L/H)

Model

Modèle

Modell

Modello

Model

Modell

Modelo

Volts

Volt

Voltios

Amps (Volts)

Amp. (Volts)

Ampere (Volt)

Amp (Volt)

Ampere (volt)

Amperios (Voltios)

Amps (Volts)

Amp. (Volts)

Ampere (Volt)

Amp (Volt)

Ampere (volt)

Amperios (Voltios)

Fuse Size

Taille de fusible

Sicherungsstärke

Dimensione fusibile

Zekering

Säkringsstorlek

Tamaño del fusible

A B C D E F

1500 (5678) RM1500A 12DC 4.8 (12v) 7.0 (13.6v) 10

2000 (7571) RM2000A 12DC 8.4 (12v) 12.0(13.6v) 15

2000 (7571) RM2000A-24 24DC 4.0 (24v) 6.0 (27.2v) 7.5

2 3/4"

(69.85mm)

5/8"

(15.88mm)

STOP

ARRÊT

STOPP

ALTO

Pump 1500 & 2000 GPH
