User Manual
US-QUAD v2.0
You are now the proud owner of one of the most advanced media systems
on the market. In order to get the most from your XUUM box, please read
this manual carefully
Preface
Statements
We have made every eort to provide the most current information about the product
We do not grant guarantees as to the contents of the present instructions manual and
disclaim any implied guarantees concerning market value or suitability for specic purposes.
The information contained herein is an instructions intended to enable the correct usage
and maintenance of the receiver
We reserve itself the right to introduce ammendments or changes to the user manula without prior notication
thereof. For this reason, we recommend that you regularly visit our website in order to obtain the latest
information available for this product.
This manual and future manual updates can be downloaded from our website
www.xuum.com/manuals
Manual Version US-QUAD 2.0 September 2015
Chapter 1 System Introduction
1.1 Key Features.........................................................................................................................
1.2 Environment for System..................................................................................................
1.3 Package Contents..............................................................................................................
Chapter 2 Remote Controller
2.1 Introduction of Remote...................................................................................................
Chapter 3 System Connection
3.1 AV Connection.....................................................................................................................
3.2 HDMI Connection.............................................................................................................
3.3 Initial Setup............................................................................................................................
Chapter 4 Main Menu Items
4.1 Videos............ .......................................................................................................................
4.2 Social......................................................................................................................................
4.3 Settings..................................................................................................................................
4.4 AllApps ...............................................................................................................................
4.5 Music.....................................................................................................................................
4.6 Kodi Media Player ...............................................................................................................
4.7 Shortcuts......................................................................................................................................
4.8 Using OTA Updater...............................................................................................................
Chapter 5 Playback of Media
5.1 The OSD...................................................................................................................................
5.2 Video Options.......................................................................................................................
5.3 Audio Options.......................................................................................................................
Chapter 6 Troubleshooting....................................................................................................
Chapter 7 Specication...........................................................................................................
01
01
01
02
03
03
04
05
05
05
08
09
09
11
11
13
13
13
13
14
15
01
1
1
Chapter 1 System Introduction
1. 1 Key Features
Supports many kinds of IPTV and OTTTV programmes.
Supports FHD H.265, VC-1, H.264, MPEG-2 and many other formats such as MPEG-1
,
MPEG-2,MPEG-4,DIVX,REALMEDIA and so on.
Video formats include hevc,avi,mpg,vob,rmvb,mkv,m2ts,ts and so on.
Photo formats include JPEG,BMP and PNG up to 80M pixels.
Audio formats include MP3,WMA,WAV,AC3,AAC and so on.
Support SD/SDHC/MMC cards.
Support four USB 2.0 host connectors with maximum output current of 1.5A/5V
.
Support standard RJ45 cable network connection and wireless network connection.
Support infrared remote controller operation.
Operation : Temperature limitation: 0--40℃; Humidity limitation: 20--80%.
Storage: Temperature limitation: -20--50℃; Humidity limitation: 10--90%.
1. 2 Environment for System
1. 3 Package Contents
Accessories Quantity
Power adaptor
Remote control
1
1
HDMI cable
User manual
02
Chapter 2 Remote Controller
MUTE:Press to turn down the volume.
SETUP:Fast key to go to system setup.
POWER:Press to standby.
APP:Fast key to go to android application.
MENU:Press to choose function menu of corresponding
application in video,music,photo and website.
Navigation:Press to navigate left/right/up/down.
Press OK to confirm your choice.
Number keypad 0-9:Press to input Arabic number.
RETURN:Press to return back to previous menu.
HOME:Fast key to go back to main menu.
VOL:Press to increase/decrease the volume.
CURSOR:Press to use the navigation button as cursor.
Backspace:Press to backspace the input.
2. 1 Introduction of Remote
SETUP
APP
SETUP
APP
TV CONTROL AREA:Press to learn from the TV IR remote to control TV.
03
ENGLISH
Amplifier
USB-3
USB-2
USB-1
SD/MMC
a. Connect the supplied AV cable to the AV input on your TV using the colored connections as a guide
(RED/WHITE/YELLOW)
b. Power on your TV and choose the respective AV input channel
a. Connect the supplied HDMI cable into the rear HDMI port at the back of the XUUM box
b. Power on your TV and select the respective HDMI input channel
04
ENGLISH
3.3 Initial Setup
Step 1 - At the welcome screen choose Next
Step 3 - Choose the method of connection to your network router, either by Wifi or ethernet.
For Wifi, select and choose your network name and then highlight the password box
and press ‘ok’ on your remote to reveal the virtual keyboard. Once you have finished
using the virtual keyboard, press the ‘return’ button on your remote.
Once connected, press FINISH
Step 2- Fit the display output by pressing the up and down direction buttons on your remote
until you see the white border appear around the edge of your TV set
The Social Icon contains the most popular social media apps such as Facebook and Pintrest
05
The Video Icon contains popular video platforms such as Youtube and Vimeo
4.2 Social
4.3 Settings
The Settings Icon is where all setting for the box are configured.
Chapter 4 Main Menu Items
4.1 Video
06
Pressing the Settings Icon brings up the main device settings window.
The NETWORK tab gives you control over Ethernet and Wifi connections
The DISPLAY tab allows you to change the output resolution and is set to auto detect by default.
You can also change the display position as carried out in the initial setup (chapter 3.3)
The ADVANCED tab gives control over Miracast and the sound output
