Xtrfy H2 Manuel utilisateur
H2
H2. HEAR WHAT YOU CAN’T SEE.
The H2 is a gaming headset ready for competition. Extra large over-ear cups. Thick
memory foam cushions. Durable, low-weight construction. And a sound signature that
enhances the crucial audio details of the game – developed by some of the most expe-
rienced players in all of esports.
SPECIFICATIONS
Headset type: Closed, over-ear
Headband: Mechanical, aluminium frame
Ear pads: Memory foam and mesh cloth (interchangeable)
Audio drivers: Dynamic Ø 53 mm
Magnet type: Neodymium
Frequency response: 15–25 000 Hz
Nominal impedance: 32 Ohm
Nominal sensitivity: 97±3dBSPL @ 1kHZ, 20mW
Connection: Single or Dual 3.5 mm plug (adapter included)
Connector: Gold plated, single 4-pole/dual 3-pole plug
Cable: Braided, 1.2 m single plug, 2 m Y-adapter, 25 cm Y-adapter
Controls: Speaker and mic volume, mic mute
Microphone: Detachable, cardioid mic
Microphone frequency response: 45–18 000 Hz
Weight: 330 g
Weight incl. microphone and cable: 360 g
Compatible with: PC, Mac®*, Xbox One®**, Xbox One S**, PS4™, PS4 Pro, mobile
devices*** and VR systems***
Warranty EU/US/ASIA: 2/1/1 years
* External sound card required (not included).
** Adapter required for Xbox One controllers without 3.5 mm port (sold separately).
*** Compatible with devices with CTIA standard connectors.
CONNECT TO COMPUTER
Use the included adapter to connect the headset to the audio and microphone ports on
your computer. (For combined audio/mic jacks, no adapter is required.)
ATTACH THE MICROPHONE
Plug the microphone into the port on the left earcup. Make sure it’s in the right
direction (see image below).
THIS SIDE UP
MICROPHONE PLACEMENT
For the best sound quality, make sure that the opening on the microphone is positioned
directly towards you. (You’ll find it by removing the foam windscreen).
AUDIO AND MIC VOLUME
The audio and mic volume can be adjusted by using the controls on the cable. Use the
mute switch to easily turn the mic on and off.
CONNECT TO XBOX
Connect the H2 headset to your controller by using an Xbox® One controller adapter
(not included).
CONNECT TO PS4
Connect the headset to your PlayStation® 4 game controller. Turn on the PS4 and
go to Settings > Devices > Audio Devices and choose ”Output to Headphones”. Select
”All Audio”.
CONNECT TO MOBILE DEVICES
The H2 headset can be connected to smartphones, tablets and other mobile devices
using CTIA standard 3.5 mm connectors.
THANK YOU FOR CHOOSING THE H2
We hope you’ll be as satisfied with it as we are. If any questions arise,
you can always reach us on support@xtrfy.com
Misprints and printing errors reserved.
