HARD TOP ROOF TENT
INSTRUCTION MANUAL
1
SET UP INSTRUCTIONS:
1. INSTALLING YOUR ROOF TOP TENT P2-3
2. SETTING UP YOUR ROOF TOP TENT P4-6
3. PACKING DOWN YOUR ROOF TOP TENT P7-9
4. TIPS & TRICKS P10
IMPORTANT INFORMATION:
1. IF YOUR TENT WON’T OPEN P11
2. TROUBLE SHOOTING P12-13
3. SPECIFICATIONS P14
PARTS LIST:
CONTENTS
Plastic nut
M8x50 outer hexagon bolt
Screw
M5X19
Screw
M5X37
Screw
M5X24
Screw
M5X28
Screw
M5X34
Washer
M8
Washer
M5
Screw
M5X5
Screw
M5
Screw
M5X20
Screw &
Washer
Remote
Control
Two of L shape
hexagonal
wrench
2
1. INSTALLING YOUR ROOF TOP TENT
1. a) You must have roof racks correctly tted to your
vehicle before installling the Roof Top Tent
1. b) We recommend you place the Roof Top Tent in
the load-bearing position
1. c) Adjust the tent to the roofs centre, ensuring the
rear door can be opened/closed
Instructions continued on next page.
SET UP INSTRUCTIONS
3
Instructions continued on next page.
1. d) Slide the M8X50 hexagon bolts into the rails from
both sides ensuring you have positioned 8 in total
(see picture 1)
1. e) Replace the plastic covers of your roof racks
(see picture 2)
1. f) Use the plastic nut to x the M8X50 head hexagon bolt and U-shape stator in place, all four
corners should be mounted with M8X50 hexagon bolts, U-shaped stator and plastic nuts
(see picture 3)
SET UP INSTRUCTIONS
Rail
U-shape stator
Plastic nut
M8X50 outer
hexagon bolt
Picture 2
Picture 1
Picture 3
4
Instructions continued on next page.
2. SETTING UP YOUR ROOF TOP TENT
2. a) Open the tent cover and run the power cord
to your 12V socket
2. b) Release all buckles around the base
(Very important)
2. c) Release the buckle on the ladder
2. d) Ensure that power has ran from your car to the
tent, press “UP” on your remote control to set up
the tent
SET UP INSTRUCTIONS
5
Instructions continued on next page.
2. e) Wait a couple of minutes for the tent to set up
automatically
2. f) Hold the ladder, and then pull down
2. g) The ladder will open slowly
2. h) Pull on the ladder 180 degrees, then it will lock
automatically. Put it on the ground
SET UP INSTRUCTIONS
6
2. i) Push the hard top up from bottom gently
2. j) Once the hard top is open, it will be t to the
right side automatically
SET UP INSTRUCTIONS
7
Instructions continued on next page.
3. PACKING DOWN YOUR ROOF TOP TENT
3. a) Press the hard top from up to down
3. b) Push the ladder lock up
3. c) The ladder will unlock and it can now be
folded down. (Notice: Please do not push
the lock of the ladder when someone is
using it)
SET UP INSTRUCTIONS
8
3. d) Lift up the ladder gently
3. e) Place the ladder onto the hard top
3. f) Ensure the power has ran to the tent from your
car and press the “DOWN” button on the remote
3. g) The whole tent will be folded down
automatically
SET UP INSTRUCTIONS
9
2. h) Lock the buckle on the ladder
2. i) Lock all buckles around the base
SET UP INSTRUCTIONS
