XPower P-100A Manuel utilisateur
Model: P-100A / P-130A
(115V / 60Hz)
XPOWER Manufacture, Inc.
240 Clary Avenue
San Gabriel, CA 91776, USA
Tel: 626-285-3301, Fax: 626-285-3302
website: xpower.com
OWNER’S MANUAL
Index
Introduction .................................................................................................................................
Operation ...................................................................................................................................
Safety Instructions ......................................................................................................................
Maintenance Instructions/ Troubleshooting ................................................................................
Specification ...............................................................................................................................
Warranty / Service ......................................................................................................................
Parts List .....................................................................................................................................
Warranty Registration Form ........................................................................................................
2
3
4
5
6
7
8
10
- 1 -
Introduction
XPOWER Mini Air Movers P-100A and P-130A are certified professional level multifunctional
utility blower fans with the most efficient engineering design for retail market.
Features:
• Low power draw with high velocity air flow from 500
to 700 CFM.
• Super quiet motor and super lightweight.
• Easy carrying handle and stackable up to 4 units high.
• Easy and quick to disassemble for thorough cleaning
and service.
• Safety certified 10' power cord.
• Easy cord wrap on handle.
• 3-speed switch.
• Durable and rugged housing.
• 4 air flow positions (0°, 20° Kickstand, 45° and 90°).
- 2 -
45°
AIR MOVER
STORAGE:
Air Movers can
be stacked
(up to 4) on
their sides for
storage.
NOTICE:
Stacking feature
is not secure for
transportation.
Operation
XPOWER Mini Air Movers are intended to move air and to dry small areas where the large air
mover is not applicable such as crawl spaces, inside cabinets, under counters, inside ceilings,
basements, etc. The Mini Air Mover can also be used as a high velocity fan for household use.
1. XPOWER air movers are shipped ready-to-use. Prior to plugging the unit into the power
source, inspect completely for any shipping damage.
2. Plug the electrical cord into the power outlet.
3. Carefully place the Air Mover on a stable, flat, dry surface.
4. The unit is capable to be used at 4 different angles to direct airflow.
5. Turn the switch to select desired speed, while making sure the unit operates normally.
6. To reduce the risk of injury, close supervision is necessary when the appliance is used near
children. Do not allow children to play with or around an air mover at any time.
- 3 -
Daisy-chain Feature
If utilizing the Daisy-chain feature, only allow up to two additional air
movers or other devices running together on total 12 AMPs circuit.
P-100A & P-130A air movers have an on-board circuit breaker. If the
auxiliary outlet overloads, the circuit breaker will trip. If the breaker
does trip, unplug the units and press the circuit breaker Reset button.
Plug the units back into the power source and turn on the switch.
Safety Instructions
1. To prevent electric shock, do not operate the unit in standing water. Never plug in or unplug the
unit with wet hands or while standing in water.
2. To avoid risk of injury, do not direct air flow at face or body.
3. To reduce the risk of fire or electric shock, do not use the Mini Air Mover with any solid-state
speed control device.
4. Use only with GFCI protected receptacles. Please contact a qualified electrician for verification
and / or installation of a GFCI receptacle if necessary.
5. Do not operate the Mini Air Mover with a damaged cord or plug. Discard the unit or return it to
an authorized service facility for examination and/or repair.
6. Unplug the Mini Air Mover from the power supply before servicing or cleaning. Do not run the
power cord under carpeting. Do not cover the power cord with throw rugs, runners, or similar
coverings. Place the power cord away from traffic area to prevent tripping.
7. Do not allow children to play with or around the Mini Air Mover at any time.
8. Do not move or carry the Mini Air Mover while the unit is operating.
9. To reduce the risk of injury, close supervision is necessary when an appliance is used near
children.
10. An electronic instruction manual can be obtained through manufacture’s website: xpower.com.
- 4 -
Maintenance Instructions
1. Always disconnect the air mover from its power source before performing any maintenance or
cleaning.
2. Never clean the unit with water directly.
3. When not in use, unplug and store the air mover in a dry indoor place out of reach of children.
4. To keep the Mini Air Mover clean, use a damp cloth to wipe the surface of the housing.
Troubleshooting
For any problems not listed below, call your local distributor or contact our Service Department at
1-855-855-8868
- 5 -
Air Mover
vibrates
- 6 -
Specifications
Model P-100A P-130A
Volt / Frequency 115V / 60Hz 115V / 60Hz
Power 1/8 HP 1/5 HP
Amp 1.5 Amps 2.0 Amps
Rated Airflow (On High)500 CFM 700 CFM
RPM (Low / Medium / High)650 / 950 / 1200 1000 / 1250 / 1500
Speeds Three Three
Built-In Power Outlet / Daisy Chain Yes Yes
Positions 4 (0°, 20°Kickstand, 45°, 90°) 4 (0°, 20°Kickstand, 45°, 90°)
Unit / Box Weight 9.5 Lbs. / 11.2 Lbs. 9.3 Lbs. / 11.0 Lbs.
Unit / Box Size (L x W x H)10.7”x12.4”x13.3” / 13.6”x12.8”x11” 10.7”x12.4”x13.3” / 13.6”x12.8”x11”
Power Cord (Length/Size)10’/14AWG 10’/14AWG
Overheating Protection Thermally Protected Thermally Protected
Housing Injection Mold / Polypropylene (PP)Injection Mold / Polypropylene (PP)
Safety Certificates ETL / C-ETL ETL / C-ETL
XPOWER Limited Warranty (USA)
XPOWER’s Limited Warranty covers the unit (excluding POWER CORD) from defects in material
and craftsmanship. The Warranty covers normal use for a term of one year from the original date
of purchase including parts, labor and one way shipping. Non-contiguous states must pay for
roundtrip freight. A purchase receipt must be provided.
Important!
This warranty does not cover or apply to defects due directly or indirectly to misuse, abuse,
disassembly, alteration, corrosive chemicals, improper voltage, fire, flood, negligence, accident,
improperly or incorrectly performed maintenance or repair, or failure to perform necessary
maintenance or repair, or if the use of this product is not in compliance with the instructions and
specifications for its use.
Service
For Warranty service and parts replacement (US users only), you must:
A. Call 1-855-855-8868 for a RMA (Return-Merchandise-Authorization) number.
B. Have original proof of purchase.
C. Use the original undamaged packaging or an industrial certified packaging method.
End user will be responsible to ship the unit (with RMA Number showing on the shipping label) to
the XPOWER Service Department. XPOWER will inspect, assess and advise the repairs needed
and the applicable cost, if any. For users outside the US, please contact an XPOWER Distributor
in your country or region for Warranty service and parts replacement.
- 7 -
100 Series Parts List
- 8 -
Capacitor
1
3
7
9
11
13
15
2
6
8
10
12
14
Switch Plate
4
Switch Knob
5Switch
4
5
15
Airrow Pro Multi-Use Duster: A-2
Pet Dryers: B-2, B-53, B-55
Air Pump: AP-1031A, AP-1131, AP-138A, AP-145A
Air Movers: P-100A, P-130A, P-200AT, P-230AT
Scented Air Movers: P-150N, P-250AT, P-250NT, P-260AT, P-260NT
Inflatable Blowers: BR-2C01A, BR-201A, BR-232A, BR-252A
- 9 -
XPOWER Retail Product Line
A-2
B-55
AP-1031A
BR-2C01A
