OWNER’S MANUAL
MODEL: B-8 (115V/60Hz)
XPOWER MANUFACTURE, INC.
240 Clary Avenue
San Gabriel, CA 91776, USA
Tel: 626-285-3301 Fax: 626-285-3302
www.xpower.com
PLEASE READ AND SAVE THESE INSTRUCTIONS
PET DRYER + HEATER
Nozzles included
TABLE OF CONTENTS
Introducon ..........................................................................................................................................
Operaon ..............................................................................................................................................
Specificaons ........................................................................................................................................
Safety Instrucons ................................................................................................................................
Parts List ...............................................................................................................................................
Maintenance .........................................................................................................................................
Warranty / Service ................................................................................................................................
XPOWER PET PRODUCTS ......................................................................................................................
Warranty Registraon Form .................................................................................................................
1
2
2
3-6
7
8
9
10
11
INTRODUCTION
Thank you for purchasing an XPOWER B-8 professional force dryer. Featuring advanced BRUSHLESS
technology, the B-8 will outlast standard brush motor dryers with its 7,000+ hour motor. Enjoy full
control when drying or styling with variable heat and speed controls. Add a stand and staonary
styling arm (sold separately) for convenient hands-free drying.
- 1 -
Special Features:
• 4 HP BRUSHLESS DC Motor
• Powerful and Energy-Efficient
• Super Lightweight and Compact
• Remarkably QUIET Motor
• 8' Flexible Heat Protected PU Hose
• Thermally Protected
• Variable Heat and Speed Control Switches
• Digital temp and speed LCD display
• Durable & Rugged ABS Housing
• 1 Year Limited Warranty
• 3 Nozzle Aachments (included)
1. Place the dryer on a flat surface. Plug the electrical cord into a 3-prong outlet.
2. Connect the hose to the front hose connector and aach the desired nozzle.
3. Turn variable speed switch to desired speed.
4. To use heang element, choose desired heat seng or leave on off seng.
5. To reduce the risk of injury, close supervision is necessary when the unit is used near children.
Do not allow children to play with or around the unit.
- 2 -
OPERATION
SPECIFICATIONS
Model B-8 Unit Weight 12.3lbs
Volts/Cycle 115V/60Hz Unit Dimensions 17.2"x6.3"x9.8"
Power 4 HP Cord Length 10'
Motor
BRUSHLESS DC Filter System
Max AMP 12A Styling Nozzles 3
Rated Airflow 150CFM Housing ABS
Speeds Variable Thermal Protecon
Heang Element
Variable
- 3 -
SAFETY INSTRUCTIONS
WARNING: IMPORTANT SAFETY PRECAUTIONS!
When using electrical appliances, especially when children or animals are present, basic
safety precauons should always be followed to reduce the risk of fire, electric shock, and
personal injury, including, but not limited to the following:
•DO NOT use aachments not intended for use with the dryer. Only use aachments recommended
or sold by the manufacturer.
•DO NOT aempt to perform any service or maintenance not outlined in instrucon manual.
• WARNING – To Reduce The Risk Of Electric Shock – Use Indoors Only. DO NOT use outdoors.
•WARNING: This Pet Dryer is not intended for use by children. Adult assembly and operaon required.
To reduce the risk of injury, close supervision is necessary when an appliance is used near children.
•DO NOT use as a toy.
•DO NOT leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
•DO NOT use extension cords with dryer.
•DO NOT unplug unit by pulling on cord, to unplug, grasp the plug, not the cord.
•WARNING: Never use dryer with a damaged cord or plug, or aer the appliance malfuncons or is
dropped, damaged in any manner. Return to an Authorized Service Center for service, examinaon,
repair, or electrical or mechanical adjustment.
•To disconnect, turn all controls to the off (“O”) posion, then remove plug from outlet.
- 4 -
•DO NOT pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp
edges or corners. DO NOT run appliance over cord. Keep cord away from heated surfaces.
•DO NOT handle plug or appliance with wet hands.
•Use extra care when cleaning on stairs.
•DANGER: DO NOT expose dryer to rain or water.
•DO NOT use or store dryer where it can fall or be pulled into tub or sink or standing water. If dryer
falls into water unplug it, DO NOT reach into the water. Keep units out of baths and DO NOT operate
on a wet floor, or wet surface.
•DO NOT use to pick up flammable or combusble liquids, such as gasoline, or use in areas where they
may be present. DO NOT pick up anything that is burning or smoking, such as cigarees, matches, or
hot ashes.
•Unplug before connecng nozzles and hose.
•WARNING: DO NOT put any object into dryer openings. Keep loose clothing, jewelry and hair away
from dryer openings. DO NOT use with
any opening blocked; keep free of dust, lint, and anything that may reduce air flow.
•WARNING: DO NOT allow any material to clog or block air intakes as this may cause units to overheat
and result in a fire or electrical hazard. Regularly clear hair or other substances from air intakes.
DO NOT contact moving parts.
•Connect to a properly grounded outlet only. See Grounding Instrucons.
- 5 -
Grounding Instrucons
•DANGER – Improper connecon of the equipment-grounding conductor can result in a risk of electric
shock. The conductor with insulaon having an outer surface that is green with or without yellow
stripes is the equipment-grounding conductor. If repair or replacement of the cord or plug is necessary,
do not connect the equipment-grounding conductor to a live terminal. Check with a qualified
electrician or serviceman if the grounding instrucons are not completely understood, or if in doubt as
to whether the appliance is properly grounded. Do not modify the plug provided with the appliance
– if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
•This appliance must be grounded. In the event of malfuncon or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock. This appliance is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must
be plugged into an appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
•A qualified electrician should be consulted if there is any doubt as to whether an outlet box is properly
grounded.
- 6 -
•This appliance is for use on a nominal 115V circuit (NEMA 5-15R), and has a grounding
plug (NEMA 5-15P) as illustrated below. Make sure that the appliance is connected to an
outlet having the same configuraon as the plug. No adapter should be used with this appliance.
SAVE THESE INSTRUCTIONS
HOUSEHOLD AND COMMERCIAL USE
TEST
TEST
RESET
RESET
NEMA 5-15R NEMA 5-15P
Grounding Pin
1
Le housing
2
Right housing
3
Switch panel
4
5
6
7
Heater
8
Motor rubber sleeve
9
Motor
10
11
12
13
Motor filter
14
Rear cover
15
16
Crossed cover
17
18
Inlet filter
19
Hose
20
Cone nozzie
21
Flat nozzle
22
Round nozzie
23
Baffle board cover
Baffle board 1
PCB board 1
PCB board 2
Baffle board 2
Heater cover
PCB board 3
PCB board 4
Speed switch knob
Power cord
Heat switch knob
Switch
- 7 - 1
2
3
4
5
6
7
8
9
15
10
11
14
12
13
17
18
19
20
21
22
26
16
24
25
26
PART LIST
25
24
23
MAINTENANCE
IMPORTANT!
Always turn off the unit and disconnect from electrical outlet before maintenabce or cleaning.
Product Maintenance:
1. To keep the Pet Dryer, use a damp cloth to wipe the surface of the housing. Removable part(s)
and filters may be cleaned with water and dried thoroughly before reassembling.
2. When not in use, unplug and store the Pet Dryer in a dry place indoors and keep out of reach of
children.
Cleaning Filters and Rear Cover:
The B-8 Pet Dryer has two washable filters - Inlet Filter and Motor Filter. The Inter filter is located on
one side of dryer (rather than the side with hose). Open the rear cover to find motor filter. Both
filters should be kept clean regularly. If the filters are coated with too much hair or dirt, the air
output of the Dryer will be reduced, and this may cause damage to the motors or cause the motors
to overheat. You should never operate the dryer without filters in place.
