1
DT430
Quick Start Guide
2
Copyright
Copyright©2010 Group Sense Mobile-Tech Limited. All rights
reserved.
Product specifications and features are for reference only and are
subject to change without prior notice.
Declaration
This Quick Start Guide is published by Group Sense Mobile-Tech
Limited without any warranty. Improvement and changes to this
Quick Start Guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs
and/or equipment, may be made by Group Sense Mobile-Tech
Limited any time and without notice. Such changes will, however,
be incorporated into new editions of this Quick Start Guide.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
3
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. Changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Radiation Exposure Statement
The antennas used for this transmitter must be installed to provide
aseparation distance of at least 20cm from all persons and must
not be co-located or operating in conjunction with any other
antenna or transmitter.
Important safety information
PLEASE READ THIS CAREFULLY BEFORE USING DT430!
Always treat your product with care and keep it in a clean and
dust-free place.
Do not expose DT430 to moisture or humility.
Do not expose DT430 to extreme high or low temperatures.
4
Do not attempt to disassemble your product.
Use only the chargers and batteries approved by Group Sense
Mobile-Tech Limited. The use of any other type may invalidate
any approval and warranty. No reserve changing with other
chargers, they may have inverse polarity.
Never use the charger if the plug is damaged.
Never touch the charger if your hands/feet are wet.
Do not expose the charger to water, if may cause electrical fires.
Do not repair the charger yourself for your safety.
To reduce the risk of fire or burns, do not disassemble, crush or
puncture the battery.
Recycle or dispose of the battery safely and properly according to
local laws and regulations.
Do not dispose of the battery in fire or water.
Do not let the metal contacts on the battery touch and other metal
object, it could lead to short-circuit and damage the battery.
Important safety information
For DT430 model, only approved batteries, chargers that are
5
designed for the model can be used with DT430 unit.
Do not exchange with wrong model battery, it may occur to
explosion. Please dispose battery following instruction.
6
Contents
Getting to know DT430…………….. .………………….. 7
DT430 overview ………………..…...…………………..7
Battery…………………………..…...…………………..7
Loading/removing battery...…...…………………..7
Charging battery ………………...………………..7
Getting started……………………………………………..7
Turn on/offDT430 ………….………..………………….. 7
Connect / mount hand strap to DT430………..………….7
Wi-Fi connection settings..…………..………………….. 7
Using Bluetooth………….…………..………………….. 7
To enable Bluetooth………...…...…………………..7
Bluetooth settings…………...…...…………………..7
Searching for Bluetooth……………………………..7
DT430 settings….…………………………………………..7
Screen rotation……………….………..………………….. 7
7
Backlight settings…………….………..………………….. 7
System backup….…………….………..………………….. 7
GettingtoknowDT430
DT430 overview
Name Description
1 Left button
2 Mini SD cover
Mini USB cover
8
3 SD card slot Insert external card
4 USB socket Connect to PC for data synchronization
5 ON/OFF button Press to turn on DT430; press and hold
to turn off; if DT430 is on, press to
suspend
6 Bottom cabinet
7 LED light Show the status for Wi-Fi and battery
8 LED light Programmable LED
9 LED light Light sensor
10 Navigation key Move the pointer around on the
screen.
11 Function key Perform certain actions
12 I/O connector Connect cradle to charge
13 Reset key Reset / reboot device
14 Speaker
15 Battery latch Open / close the battery cover
16 Battery cover
17 Stylus
Battery
Installing / removing battery
To install battery
9
1. Turn over the handheld terminal.
2. Slide the battery latch to the left slightly, and then lift the
battery pack cover up in the direction indicated by the arrow.
3. Insert the battery into the battery compartment. Make sure the
end of the battery pack removal tape is put on the above the
battery pack.
4. Put back the battery pack cover to the compartment as
showed, and then slide the battery latch to the right to double
lock it.
To remove battery
1. Make sure that the Handheld Terminal is turned off. If the
power is on, press and hold the power button to turn off.
2. Slide the battery latch to the left slightly, and then lift the
battery pack cover up.
3. Grasp the battery and lift by pulling up the battery pack
removal tape gently.
Charging battery
To charge the battery
10
Single-slot charge cradle
1. Connect the charger to the charging slot (as below).
2. Put DT430 terminal and / or spare battery into the charger
cradle.
3. Plug the charger to the main electrical outlet.
4. The “Be be” sound rings and the LED light turns amber.
5. When charging is complete, the LED light turns green.
Cascade Charge Cradle
1. Connect 2 or 3 (max) charge cradles through charge cable as
showed. It may cause DT430 damage if over 3 charge cradles
are connected.
2. Put DT430 terminal and / or spare battery into the charger
cradle.
3. Plug the charger to the main electrical outlet.
4. The LED light turns amber.
LED light description
There are three LED lights on the front of DT430, the left one has
different status:
