Xo XOU24BCOFL Manuel utilisateur
I worked really hard
on this manual -
so please read it...
XOU24BCGO
PANEL READY BEVERAGE CENTER
WATCH THE INSTALLATION
VIDEO ON OUR CHANNEL
2
UNDERCOUNTER
When buying any XO appliance
you can be confident you have chosen a
high quality, innovative and stylish product
from a company that cares about you!
If you require service or have questions,
Help is only a phone call away -
call: 973-403-8900
Talk to one of our undercounter experts.
CONGRATULATIONS
on purchasing your XO.
Before you proceed, take just
a moment to register your XO at:
Ensuring warranty coverage should you need service
Providing ownership verification for insurance purposes
Let’s XO notify you in the event of product changes or recalls.
www.xoappliance.com/register-your-product/
REGISTRATION HELPS YOU BY -
Before You Get Started
Safety Instructions
Electrical and Grounding Instructions
Care and Cleaning
Helpful Hints
Cleaning the Interior / Exterior
Changing the Carbon Air Purification Filter
FAQ’s
Before You Call For Service
Warranty
4 - 7
Installation Instructions
Sizes and Installation Dimensions
Leveling Your XO
8 - 13
21 - 22
23 - 24
3
where things are
please read and follow
all safety instructions
It’s for your
own good...
Honest.
Installer Checklist
Find Your Model
Operating Instructions
Control System Overview
Setting the Temperature
Functions
Wine and Beverage Storage
Shelf Instructions
14
- 20
Integrated Panel Dimensions
Product Overview
4
the job isn’t done until
To ensure that the installation process is successfully completed,
here are few things to review...
Is the unit plugged in?
Are the controls on? (Panel will illuminate.)
Are the controls operating correctly?
Has the unit been properly leveled - both side to side and front to back -
with all 4 leveling feet securely making contact with the floor?
This is an OVERLAY unit - have the panels been securely attached and properly aligned?
Is the door sealing properly?
Is the handle secure?
Have you thoroughly inspected all surfaces for any imperfections?
Have you reviewed this manual with the customer and explained the unit’s operation and care?
Has the customer received copies of the literature and keys?
Have you properly disposed of all packing materials properly (recycle, please)?
Is the customer satisfied?
O
O
O
O
O
O
O
O
O
O
O
O
After installation, does the door open sufficiently to fully extend the shelves?
O
RISK OF CHILD ENTRAPMENT!
An empty refrigerator is a very dangerous attraction to children.
Remove door gaskets, latches, lids, lock and/or doors from unused or discarded appliances,
or take other actions to guarantee them harmless.
Always dispose of old appliances in accordance with local laws and regulations.
5
BEVERAGE CENTERS
XOU24BCGOR
XOU24BCGOL
2
these are the models
covered in this
book
take a minute to circle your model above
and record your serial number
here in case you need it later
Please read through completely before using your XO Unit
To prevent damage to the door gasket, the door must be opened all the way before pulling shelves out.
The appliance must be positioned so that the plug is accessible.
Empty your XO unit before attempting to move the appliance. Moving while loaded may damage or
distort the frame.
The compressor will get HOT during operation / touching it may cause injury.
During installation follow all safety tips provided in this manual / appropriate safety equipment such as
safety glasses and work gloves should be worn.
Two people should move or lift your XO unit to prevent injury or damage.
Remove all interior and exterior packing materials prior to installation and dispose of properly.
Never cover the bottle racks with foil or other material which will impede internal air circulation.
For maximum efficiency, keep the door tightly shut unless loading or unloading and never overload your
XO unit.
Before installing, allow your XO unit to sit upright for 2 hours at the install site. This will allow the cooling
system to stabilize after transportation. Failure to follow this step may cause problems.
Location
Your XO unit should be located away from direct sunlight and heat sources (stove, heaters, etc.) which may
increase electrical consumption. High or low ambient temperature may cause units to work improperly.
The floor must be strong enough to support your XO unit fully loaded.
Your XO unit must not be installed in areas of where water or e
xcessive moisture are present.
Your XO unit’s final installation must observe the correct minimum air clearances around and behind the
unit to ensure adequate ventilation. In addition, all ventilation openings must be kept clear and free of
obstructions, failure to do so will result in damage to the unit.
WARNING
NEVER use external heat sources to accelerate defrosting
NEVER permit unauthorized service or modifications to your XO unit
NEVER tamper with the sealed refrigerant system - this unit uses R600A Refrigerant which is flammable.
It should never be used in the vicinity of any flammable or explosive ignition sources.
ALWAYS FOLLOW THE ELECTRICAL SAFETY INSTRUCTIONS OUTLINED IN THIS MANUAL.
6
your safety matters
Never store perishable food products such as meat or cheese in your wine cooler or beverage center.
Your XO unit must not be installed near
where flammable, corrosive or hazardous materials are present.
Failure To Follow All Electrical Safety Measures May Result in Serious Injury,
Fire Or Death
All electrical work should only be performed by an
experienced, licensed electrician.
All XO units MUST be grounded for safe operation and
come equipped with a
3 Prong molded cord/plug for that
purpose.
NEVER remove or disable the 3rd prong with an adapter.
NEVER use an extension cord to operate your XO unit.
Your XO unit is built to operate on 115V 60Hz and
should be plugged directly into a dedicated 15 amp
3 prong outlet. If you are uncertain as to the
voltage, amperage capacity or if the 3rd prong is
properly grounded - consult a licensed electrician.
To maximize the depth of the installation recess -
your outlet should be mounted flush with the wall.
Your XO unit should not share the circuit with any other
electrical devices as this may cause overloading,
overheating, blown fuses or tripping circuit breakers.
In a worst case this can pose a fire hazard.
NEVER handle your XO unit in wet conditions as this
can pose a severe danger of electric shock.
Exercise care when moving your XO unit to avoid
damage to the electrical cord. If the electrical cord of
your XO unit becomes worn or damaged it must be
replaced immediately by a qualified technician.
NEVER unplug your unit by pulling on the cord.
Unplug by gripping the plug firmly and pull out
straight from the outlet.
INDOOR USE ONLY:
This model is intended for indoor/interior
applications only and is not to be used in
installations that are open/exposed to natural
elements.
This unit is designed to operate between 60 F and
90 F. Higher ambient temperatures may reduce
the unit’s ability to reach low temperatures and/or
reduce performance.
For best performance, keep the unit out of direct
sunlight and away from heat generating equipment.
In climates where high humidity and dew points are
present, condensation may appear on outside surfaces,
particularly in non air conditioned spaces.
This is considered normal. The condensation will
evaporate when the humidity drops.
CAUTION
Damages caused by ambient extremes are not
covered by the warranty
SERVICE 115V - 60 Hz - 1 phase
AMPS 15 Amp Circuit Breaker
Requires a Dedicated Outlet
All electrical work must be performed by
a licensed electrician
7
Serious injury, fire or death...
Okay -
o
o
8
a perfect fit
use free standing - or - install under counter
when installing an overlay door unit,
you might use a recessed outlet or
cut the adjoining cabinet wall to
reach an outlet there...
ALL XO UNDERCOUNTER
UNITS ARRIVE PRE-WIRED
WITH LOW PROFILE PLUGS
FOR EASY INSTALLATION
4"
7"
34 1/4” MIN
24”
90°
Door Swing
WALL
Clearance
Gap
IF THE DOOR CAN’T OPEN FULLY - YOU CAN’T PULL THE SHELVES OUT.
WHEN INSTALLING WITH
THE HINGE SIDE NEXT TO A WALL -
LEAVE ADEQUATE SPACE FOR
CABINET HANDLES
DOOR MUST BE ABLE TO OPEN
A MINIMUM OF 90 .
o
THE DOOR STOP IS SET AT 110 - BUT CAN BE RESET TO 90 OR 140 IF NEEDED.
oo o
9
a perfect fit
your xo is this big (
or small, as the case would be
)
XOU24BCGOR & XOU24BCGOL 24” BEVERAGE CENTER
34
HIGH
1/8”
W
H
height & width
MODELS WITH OVERLAY DOORS
depth
D
CUSTOM OVERLAY PANELS MAY ADD UP TO 3/4” IN OVERALL DEPTH
Y
REQUIRE CLEARANCE SPACE IF INSTALLED NEXT TO A WALL TO OPEN.
OUR CHOICE OF CABINET HANDLES WILL ALSO ADD DEPTH AND
23 7/8” WIDE
90o
110o
140o
SHELF
EXTENDED
WITH THE DOOR
OPEN AT 90
THE UNIT HAS A
DEPTH OF 46 1/2”
o
23 3/4” (including 3/4” panel)
MAXIMUM PANEL THICKNESS 3/4”
PANEL MAXIMUM WEIGHT: 20 lbs.
* FOR CABINET DOORS LONGER THAN 30” - CONSULT XO.
10
AFTER INSTALLATION UNDERCOUNTER, OVERLAY DOOR MUST BE ABLE TO OPEN 90 .
o
23 3/4” (603mm)*
3 1/4” (82mm) min
5” (127mm) max
3 1/4” (82mm) min
5” (127mm) max
2 7/8”
(73mm)
min
5”
(127mm)
max
29 3/4”
(756mm)
min
30”
(762mm)
max**
overlay panel dimensions xou24bcgo
Drill a hole at least 5/16” in diameter and
1” deep into the top and bottom of the
frame in the location shown.
TO ACCOMMODATE THE HINGE PINS
ON THE HINGE SIDE OF THE PANEL
2 7/8”
(73mm)
min
5”
(127mm)
max
* IF FRAME WIDTH EXCEEDS 23 3/4”
WHEN MOUNTING TO THE DOOR
ALIGN THE FRAME EVEN WITH THE
HINGE SIDE, LETTING THE EXCESS
OVERHANG THE HANDLE SIDE TO
AVOID INTERFERENCE WITH THE
ZERO CLEARANCE HINGE.
3/8”
13/32”
5/16” Dia. OUTSIDE
DOOR SIDE
3/4” FRAME
3/4” FRAME
COPY AND CUT OUT
THESE HANDY
HOLE TEMPLATES
