Mi 23.8’’ Desktop Monitor 1C User Manual 1
小米23.8型電腦螢幕1C 使用說明書 9
Manual de usuario de Mi 23.8’’ Desktop Monitor 1C 18
Mi 23.8" デスクトップモニター 1C 取扱説明書
26
Read this manual carefully before use,
and retain it for future reference.
Product Overview
5-way Navigation
Indicator
Monitor
Accessories
Stand
Base
HDMI Port
Power Port VGA Port Security Slot
DC HDMI VGA
HDMI Cable×1AC Adapter×1 Stand×1
Base×1 Base Screw×1
User Manual×1 Warranty Notice×1
Stand Screw×2L-shaped Screwdriver×1
1
Installation
1. Install the stand onto the back of the monitor, then fix firmly with the stand
screws.
2. Connect the stand to the base, then tighten the base screw securely.
3. Adjust the angles forward or backward based on your needs.
Note: When adjusting the angles, it is recommended to use one hand to hold down
the base and use the other hand to adjust the monitor. Otherwise, the monitor may
fall down.
Forward 5° Backward 15°
2
Stand Screw
Base Screw
3. VGA Port:
4. Security Slot:
Output Device: Computer, DVD player, etc.
1. Power Port:
Input
1 2 3 4
DC HDMI VGA
How to Use
Port Description
Note: When the AC adapter or HDMI cable is damaged, it must be replaced
with a genuine AC adapter or HDMI cable purchased from the manufacturer
2. HDMI Port:
Version: 1.4
Output Device: Computer, DVD player, camera, etc.
Signal Formats: 480p, 720p, 1080i, 1080p
Maximum Refresh Rate: 1080p/60 Hz
Maximum Refresh Rate: 1080p/60 Hz
Suitable for 3 × 7 mm cable lock (not included and sold separately).
3
DC
Result
Operation
Switch between menu options/
Select
Open menu Switch between menu or
submenu options/Adjust values
Return
Press right
Press up/down
How to Use
Indicator Status
Press and hold the
middle of the 5-way
2 seconds
Turn the
monitor off
Press the middle
of the 5-way Turn the
monitor on
Lit On
Dimmed Off
Blinking In sleep mode
Turning On/Off
4
When menu is not displayed
on the monitor
When menu is displayed on
the monitor
Only one signal source
can be selected at a time /
VGA Set to VGA signal source
Image Auto-adjust Adjust the image automatically
when using the VGA signal source //
Color Auto-adjust Adjust the color automatically when
using the VGA signal source //
/ /
HDMI Set to HDMI signal source
Mi Monitor
Back Enter/Select Move/Adjust
Off/Level 1/Level 2/
Level 3
Standard
Mode
Off
OK/Cancel Cancel
Overdrive
How to Use
Brightness
Contrast
Information
Menu Description
Color
Temp
Smart
Modes
Input
Standard Mode
ECO Mode
Game Mode
Movie Mode
Low Blue Light
Mode
Language
Reset
Set to standard mode
Set to eco mode
Set to game mode
Set to movie mode
Set to low blue light mode
Select the menu language
Decrease the monitor's response time
Restore the monitor to the factory
Display monitor related information
SubmenuMain Menu Description Adjustable Range Default
Off
80
75
Adjust
0–1000–100
0–100
Standard
Cool
Warm
Custom
DCR
Adjust the monitor's brightness
Adjust the monitor's contrast
Dynamic contrast function
Set to the standard color temperature
Set to the cool color temperature
Set to the warm color temperature
Manually adjust RGB color temperature
On/Off
Only one color
temperature can be
selected at a time
Standard
Only one display
mode can be selected
at a time
Standard Mode
Input
Smart Modes
Color Temp
Contrast
Brightness
5
English/繁體中文/
Español/日本語 English
Precautions
Issue Solutions
Possible Cause
Image is dark
Brightness/
Contrast not
adjusted properly
Adjust the brightness and contrast.
Unable to turn on No power ·
·
Make sure the AC adapter is plugged in properly.
Interference Keep the monitor away from electronic devices that may
cause electrical interference.
Select the Image Auto-adjust from the menu to adjust the
image.
Indicator is lit,
but no image No signal
·
·
·
Turn on the computer.
Make sure the computer's graphics card is working properly.
Make sure the HDMI or VGA cable is properly plugged in.
Monitor displays:
Out of range
Resolution is
incorrect
The image is not in the
middle or out of range
when using the VGA
signal source
Image is not
adjusted
Do not use this monitor in damp or humid environments such as bathrooms,
kitchens, basements, or near swimming pools.
Make sure the monitor is placed on a stable surface. When the monitor falls
down or is knocked over, it may cause personal injuries or damage.
Store and use the monitor in a cool, dry, ventilated place. Keep the monitor away
from radiation and heat sources. Do not cover or block the heat dissipation vents
on the back of the monitor.
Do not place the monitor on a bed, sofa, or blanket, etc.
The monitor's operating voltage range is indicated on a label on the back of the
monitor. If you are unsure what voltage your power supply is, please contact the
monitor's distributor or local power company.
When you do not plan to use the monitor for a long period of time, unplug it from
the electrical outlet so as to prevent possible damage from power surges or
lightning strikes.
Do not overload electrical outlets, as this may cause a fire or an electric shock.
Do not insert any foreign objects into the monitor, as this may cause a short
circuit which can lead to a fire or an electric shock.
Do not excessively pull, twist, or bend the AC adapter's cord.
tear it off. Any damage caused by the user will void the warranty.
assistance.
Troubleshooting
6
by
RMMNT238NF
23.8”
60.5 cm
0.275 × 0.275 mm
250 cd/m
2
(TYP)
1000:1 (TYP)
16.7 M
16:9
6 ms (GTG)
1920 × 1080
539.2(L)×181.2(W)×419.5(H) mm
2.7 kg
1920 × 1080
24 W Max.
20–90% RH
0°C to 40°C
86–106 kPa
12 V 2 A
Model
Input
Rated Power
Screen Size
Dot Pitch
Brightness
Contrast
Color Gamut
Aspect Ratio
Response Time
Recommended Resolution
Maximum Resolution
Item Dimensions
Net Weight
Operating Temperature
Operating Humidity
Atmospheric Pressure
Viewable Image Size (Diagonal)
Specifications
7
The Adopted Trademarks HDMI, HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc. in the United States and other countries
External AC Adapter Specifications
12.0 V DC
2.0 A
24.0 W
86.80%
80.64%
0.1 W
50/60 Hz, 0.7 A
100–240 V AC
Input voltage
Input AC frequency
Output voltage
Output power
Average active efficiency
Efficiency at low load (10 %)
No-load power consumption
Output current
Eye Health
Low Blue Light Description
wavelength of harmful blue light is 415–455 nm. This monitor has a function to help
reduce your exposure to the blue light emission. You can enable the low blue light
To avoid eyestrain, or neck, arm, elbow, and shoulder pain caused by using the
computer for a long time, please follow the suggestions listed below:
Keep the monitor at a distance of 20–28 inches (approx. 50–70 cm) from your eyes.
Take your eyes off the monitor and look at something a certain distance away for
at least 20 seconds.
Stretch your body to help relieve tension on the neck, arms, back, and shoulders.
8
